Pyle PDWR35BL User Manual

2-Way Indoor/Outdoor Speaker System
MOUNTING THE BRACKET
1. Remove the bracket knobs and the bracket from the speaker
2. Hold the bracket up to the mounting surface.
"PDWR" can be mounted either horizontally or vertically, hold the
bracket so that the speaker wire ts through the large, circular wire
hole in the bracket, align the bracket to be square with the
surrounding (Use A level for accuracy)
3. Mark the locations of the three shaped screw holes, use all of the
holes
4. Drill pilot holes into the mounting surface
5. Gently pull the speaker wire through the wire hole in the center of
the mounting bracket, the bracket so that the holes all line up.
6. Use your hardware to attach the bracket to the mounting surface.
FINAL ADJUSTMENTS
1. After checking that the speaker is in-phase and works correctly,
angle the speaker for the best sound.
2. Hand tighten the bracket knobs only, power tools may over-tighten
the knob, and strip the threads of the insert.
3. Check that the entire installation is safe and secure.
