Pyle PDWRBT56BK User Manual

Pyle PDWRBT56BK User Manual

2-way indoor/outdoor wireless bt speaker system

Advertisement

Quick Links

2-Way Indoor/Outdoor Wireless BT Speaker System
Wireless BT Connection Diagram
Built in Wireless BT power ampli er
1
A
Aux in
3.5mm
As shown in diagram, will be the rst two speakers docking, red lead to the positive, black lead to the negative.
As shown in diagram 1, A port is 3.5mm AUX IN, B port is DC12V, the connection is complete.
Wireless BT Connectivity:
Built-in Wireless BT Streaming Receiver
Simple & Hassle-Free Connection Works with All of Today's Latest Devices
(Smartphone, Tablet, Laptop, Computer, etc.)
Wireless BT Version: 4.0
Wireless BT Network Name: 'Pyle'
Wireless BT Network Password: '0000' (4 Zeroes)
Wireless Range: 30'+ ft.
www.PyleUSA.com
B
-
+
2
DC12V
Speaker Cable
-
+
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: support@pyleusa.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the PDWRBT56BK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pyle PDWRBT56BK

  • Page 1 (Smartphone, Tablet, Laptop, Computer, etc.) Questions? Issues? • Wireless BT Version: 4.0 We are here to help! • Wireless BT Network Name: ‘Pyle’ Phone: (1) 718-535-1800 • Wireless BT Network Password: ‘0000’ (4 Zeroes) Email: support@pyleusa.com • Wireless Range: 30’+ ft.
  • Page 2 Power Size Response PDWRBT56WT 500 Watt 250 Watt 5.25'' 1.75'' 1.0'' 50-21 kHz 40 Oz 8 Ohm DC12V White PDWRBT56BK 500 Watt 250 Watt 5.25'' 1.75'' 1.0'' 50-21 kHz 40 Oz 8 Ohm DC12V Black Yellow PDWRBT56YL 500 Watt 250 Watt 5.25''...
