ProCon — TB550 Series
®
Turbidity Sensor
Sensor Calibration Address | Function Code 0x03 Read | Function code 0x10 Fix
Add
100 First Calibration Point
102 Fifth Calibration Point
104 Eighth Calibration Point
106 Tenth Calibration Point
108 First Voltage
110 Fifth Voltage A
112 Fifth Voltage B
114 Eighth Voltage A
116 Eighth Voltage B
118 The Tenth Voltage
120 Dynamic Correction
122 Linear Compensation
124 Temperature Correction
126 Temperature Setting
128 Second Calibration Point
130 Third Calibration Point
132 Fourth Calibration Point
134 Sixth Calibration Point
136 Seventh Calibration Point
138 Ninth Calibration Point
140 Second Voltage
142 Third Voltage
144 Fourth Voltage
146 Sixth Voltage
148 Seventh Voltage
150 Ninth Voltage
200 Factory Calibration
