- Page 1 3x360°Line Laser User Manual Please read these instructions before operating the product. Model: F94T-XG Questions, problems, missing parts? Before returning to your retailer, contact us by email: support@Firecoretools.com.
-
Page 2: Table Of Contents
Table of Contents ..........Safety Instructions ..........Product Overview ........... Operating Modes ............Specifications ............Maintenance ............ Troubleshooting ............Warranty... -
Page 3: Safety Instructions
Safety Instructions Working safely with the measuring tool is possible when the operating and safety information are read completely and the instructions contained therein are strictly followed. Never make warning labels on the measuring tool unrecognizable. Save these instructions for reference. WARNING LASER RADIATION. - Page 4 hazardous laser radiation exposure. • Do not operate the laser around children or allow children to operate the laser. Serious eye injury may result. • Do not remove or deface warning labels. If labels are removed user or others may inadvertently expose themselves to radiation. •...
-
Page 5: Product Overview
Product Overview Control Panel V/Anti-shock---- Control the vertical lines/anti-shake mode H/Manual---Control the horizontal lines/manual mode Receiver---Pulse mode... - Page 6 Battery Charging / Installation Warning • The battery may explode or leak, and as a result, it may cause personal injury and fire. • To reduce such risks, please strictly follow all instructions and warnings on the battery label and plug. •...
-
Page 7: Operating Modes
3 seconds. Pulse Mode How to use the Firecore laser receiver with F94T-XG laser level? First, turn on laser level's pulse mode——Press the "Receiver" button, the straight laser line stops flashing and then enters the pulse mode. -
Page 8: Specifications
Specifications Model F94T-XG Laser Line 12 Green Lines Leveling Type Gravity Pendulum IP Rating IP65 Class 2 (IEC/EN 60825-1:2014)， Laser Class <1mW power output Overall Accuracy ±3mm/10m (±1/9 inch/33Ft) Leveling Range ±4° Working Distance Used with Receiver 2-60m Laser Wavelength... -
Page 9: Maintenance
Maintenance This 3x360° Self-leveling Line Laser has been designed to be a low- maintenance tool.However, in order to maintain its performance, you must always follow these simple directions: • Avoid exposing the tool to shock, continuous vibration or extreme hot or cold temperature. -
Page 10: Troubleshooting
Troubleshooting PROBLEM CAUSE SOLUTION The laser tool is too far Move the tool closer to the from the target. target. The laser line is hard to see. The surrounding is too Switch to receiver(pulse) bright. mode and find the laser line with FD30 laser receiver (sold separately). -
Page 11: Warranty
Warranty We are confident in the quality of our products and offer outstanding guarantee for professional users. This statement is in addition to and in no way prejudices your contractual rights as a professional user to your statutory rights as a private non-professional user.
