Motor City Wash Works DRY N'SHINE V SINGLE WHEEL Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TABLE OF CONTENTS
Equipment Specifications
Equipment Features
Suggested Tools and Installation Materials
Installation Instructions
Electrical Installation
Pneumatic Installations
Plumbing Installations
Operations and Startup
Maintenance
Troubleshooting.......................................................................................................................Page: 56
Support Documents..................................................................................................................Page: 64
Warranty.................................................................................................................................Page: 91
Equipment Requirements
ELECTRICAL
PNEUMATICS
WATER
Notes and Safety Symbols
Where necessary, important points will be highlighted in this manual, using the following symbols:
STOP!
Always follow all notes, warnings, and instructions. Failure to do so may have serious consequences on the
overall performance of the equipment and/or the safety of the people working on the equipment!
© Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A.
8MANULDNSINS005 1-16-2023
TOP WHEEL ONLY
(NON CRUZ)
POWER:
208V SYSTEM: ONE 40 AMPS 3PH CIRCUIT
480V SYSTEM: ONE 20 AMPS 3PH CIRCUIT
CONTROL:
1 TOP WHL READY SIGNAL CW CONTROLLER
1 E-STOP OK SIGNAL CW CONTROLLER
3 SCFM
10 GPM @ 40 PSI
NOTE:
PROVIDES FURTHER INFORMATION!
PRECAUTION TO TAKE TO AVOID EQUIPMENT
MALFUNCTION OR ERROR!
WARNING!
DANGEROUS SITUATION WHICH MAY CAUSE
EQUIPMENT DAMAGE, PERSONAL INJURIES OR FATALITIES!
SINGLE AND THREE BRUSH DRY N' SHINE Rev 5
Phone: 248.313.0272 ▪ Fax: 248. 313.0271
www.motorcitywashworks.com
INSTALLATION MANUAL
TOP WHEEL AND SIDE WHEELS
(NON CRUZ)
POWER:
208V SYSTEM: ONE 40 AMPS 3PH CIRCUIT
480V SYSTEM: ONE 20 AMPS 3PH CIRCUIT
CONTROL:
1 TOP WHL READY SIGNAL CW CONTROLLER
1 SIDE WHLS READY SIGNAL CW CONTROLLER
1 SIDE WHLS BUMP READY SIGNL CW CONTROLLER
1 E-STOP OK SIGNAL CW CONTROLLER
3 SCFM
10 GPM @ 40 PSI
Page: 1
Page: 1
Page: 2
Page: 4
Page: 21
Page: 31
Page: 33
Page: 34
Page: 54
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DRY N'SHINE V SINGLE WHEEL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Motor City Wash Works DRY N'SHINE V SINGLE WHEEL

Summary of Contents for Motor City Wash Works DRY N'SHINE V SINGLE WHEEL

  • Page 1 Always follow all notes, warnings, and instructions. Failure to do so may have serious consequences on the overall performance of the equipment and/or the safety of the people working on the equipment! Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 2 Introduction: The Motor City Wash Works DRY N’SHINE will consistently produce dry cars, one after another, all day long while using less HP than conventional blower dryers. Your new DRY N’SHINE V is built off the backbone of all previous versions before with excellent improvements made to ensure the best possible drying performance.
  • Page 3 CRUZ CONTROL Enabled Panels do not require the “READY SIGNAL” or “ESTOP – OK” signals fed from the Car Wash Controller to the DNS-V panel. Tying in the ESTOP circuitry to an existing ESTOP is still necessary. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 4 Verify that the area is sufficiently large for the DRY-N-SHINE™ WHEELS PHYSICAL ENVELOPE and DIMENSIONS (see Pic #1 though #20). Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 5 Pic #5: Physical Envelope to Exit Wall for Sngl. D/S Top Wheel Pic #6: Equipment Location with Super Shiner Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 6 Pic #11: Working Envelope to CV Trap Door for Sngl. P/S Top Wheel Pic #12: Equipment Location with Super Shiner Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 7 Pic #17: Working Envelope to Exit Wall for P/S Top Wheel Pic #18: Equipment Location With High Side Wheels and Super Shiner Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 8 TILT SIDE NOZZLES TOWARD ENTRANCE INTERFERENCE WITH DRY N'SHINE CLOTH TO PREVENT AIR FLOW INTERFERENCE WITH DRY N'SHINE CLOTH Pic #21: Dryer Interferences Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 9 IN STREAKING ON THE SIDE OF THE VEHICLE DUE TO EXCESS MOISTURE BUILD-UP ON THE LOWER SIDE WHEEL CLOTH. Pic #21-A Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 10 BASE PLATES AND SECURE WITH 5/8X6” WEDGE ANCHOR BOLTS Pic #24: Level Frame (1) Pic #25: Level Frame (2) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 11 Pic #27: Passenger Side Adaptor Plate Assembly PASSENGER SIDE TOP WHEEL: MOUNT THE ADAPTOR PLATES JUSTIFIED TOWARD THE CENTER LINE AS SHOWN IN PIC #27 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 12 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 13 THE USE OF ANY AFTERMARKET WASHING/DRYING MATERIAL NOT SUPPLIED BY MOTOR CITY WASH WORKS WILL VOID THE PRODUCT WARRANTY. MOTOR CITY WASH WORKS DOES NOT PERMIT THE USE OF ANY AFTERMARKET WASHING/DRYING MATERIAL ON MOTOR CITY WASH WORKS’ MANUFACTURED EQUIPMENT. THE USE OF SUCH MATERIAL MAY CAUSE PREMATURE EQUIPMENT WEAR, IMPROPER PERFORMANCE, AND/OR DAMAGE TO EQUIPMENT AND VEHICLES.
  • Page 14 IN THE TOP SLOT AND 5 IN THE BOTTOM SLOT). Test if the top is sufficiently counter-balanced from the counter weights. Add one or two 1/4" COUNTERWEIGHTS to the counterweight arm box (see Pic #32 and Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 15 Locate the crossbeam and secure to the top wheel frame (see Pic #34). Mount the crossbeam leg on the other end of the crossbeam. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 16 Pic #5 through #12. Cut the conveyor outside guide rail following the Super Shiner installation manual recommendations. Secure and level the Super Shiner with anchor bolts. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 17 Locate the driver side BEATER BAR and mount to the driver’s side High Boy (see Pic #38). Locate the SPLASH GUARD and mount to the beater bar. Repeat the same procedure for the passenger side. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 18 (See Pic #39-B.) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 19 THE USE OF ANY AFTERMARKET WASHING/DRYING MATERIAL NOT SUPPLIED BY MOTOR CITY WASH WORKS WILL VOID THE PRODUCT WARRANTY. MOTOR CITY WASH WORKS DOES NOT PERMIT THE USE OF ANY AFTERMARKET WASHING/DRYING MATERIAL ON MOTOR CITY WASH WORKS’ MANUFACTURED EQUIPMENT. THE USE OF SUCH MATERIAL MAY CAUSE PREMATURE EQUIPMENT WEAR, IMPROPER PERFORMANCE, AND/OR DAMAGE TO EQUIPMENT AND VEHICLES.
  • Page 20 Beater Bar outward away from the brush. The ideal amount of penetration of cloth onto the beater bar should be 2”. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 21 Pic #42: Loosen Back Head bolts Pic #43: 5 Degree Tilt Pic #21-B (Optional) Back Shot Profiler Dryer Setup Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 22 SOURCE WILL CAUSE EQUIPMENT DAMAGE, PERSONAL INJURIES AND/OR FATALITIES! DO NOT PUNCH HOLES ON TOP OF ENCLOSURE. DOING SO WILL VOID YOUR WARRANTY! Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 23 Pic #45: Electrical Supply For 208VAC Control Panel (NON CRUZ SHOWN) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 24 Pic #46: Electrical Supply For 480VAC Control Panel (NON CRUZ SHOWN) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 25 Pic #47: Field Wiring GEN2 DNS-V Non Cruz Control Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 26 PUSHED. The signal has to be always ON and then turns OFF if any of the emergency stop buttons are pushed. The signal can be any voltage between 24 to 240 VOLTS AC or DC. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 27 Pic #49: DNS V 3 Wheel System Terminal Connections Pic #50: DNS V 1 Wheel System Terminal Connections Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 28 Pic #51: 3 Wheel System Terminal Strip Connections Pic #52: 1 Wheel System Terminal Strip Connections Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 29 YOU HAVE ANY QUESTIONS CONCERNING THE REQUIREMENT FOR THE DRY N’ SHINE E-STOP OK SIGNAL. MOTOR CITY WASH WORKS TEL: 866.FOAMERS (8:00-17:00 ET) 248.313-0272 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 30 2- THE TOP WHEEL CONTROL W/50 FEET OF 9C/18AWG CABLE 3- THE E-STOP/BEEPER ASSEMBLY W/50 FEET OF 5C/18AWG CABLE 4- FINALLY, THE SIGN W/10’ CABLE Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 31 Pic #48), pull into the enclosure. The control box mounted on your top wheel is used as a junction box for three air valves (TOP WHEEL DOWN, COUNTER BALANCE and HIGH HOOD) as well as two indicator Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 32 TO THE MOTOR LEADS FOLLOWING THE APPROPRIATE CONNECTION DIAGRAM BELOW OR ON THE MOTOR PLATE (PIC #54) AND FOR PROPER VOLTAGE. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 33 Pic #55 Control Box Field Connection Layout (Non Cruz Control shown) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 34 ON THE MOTOR PLATE (PIC #54) AND FOR PROPER VOLTAGE. Pic #56 Motor Connections Pic #57 Top Wheel Connection Box TOP WHEEL MOTOR MAIN CONNECTION BOX 1.5HP/208-460VAC Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 35 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 36 Pic #58: Loosen Head Bolt Pic #59: Remove Head Bolt Pic #60: Loosen Head Bolts Pic #61: Tilt Head Down Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 37 Pull and connect ONE 3/8” BLACK AIRLINE TUBE from the 4-WAY SOLENOID AIR VALVE to the wash bay, BETWEEN THE TWO BRUSHES and tee off to EACH BRUSH’S rod end cylinders. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 38 Pic #63-A: Air Lines Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 39 8 D C A L P N L R K R 0 0 0 1 MOTOR CITY D RY N' SHINE Pic #64-B Water Lines Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 40 N’SHINE™ system. The third and fourth versions do not require discrete wires for Output signals, but virtual programming through the Cruz Control enabled versions. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 41 Your Dry N’ Shine HMI comes already with default values already programmed sufficient for initial start-up: Your Dry N’ Shine control is ready to go “out-of-the-box”! Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 42 This is the first screen you will see when booting up your brand new DNS-V. Pressing Config will bring you to the Main HMI Screen. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023...
  • Page 43 Ready Signals, High Hood, Open Bed, ESTOP OK and Fault displays. • Displays time and date. The FAULT CODE LIST can be referenced at the end of this manual! Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 44 ADVANCED. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 45 Pic #70 HMI Advanced Wash Config Screen We here at Motor City Wash Works pre-ship your DNS-V with the most up to date washing configuration, though if you desire the customizability, you can do so through this screen. If you feel at any time after customization that things are out of whack you can always press SET TO DEFAULT to return to Factory Default Values for the Wash/Rinse Final Spin cycles.
  • Page 46 TOPWHEEL and the SIDE WHEELS along with the acceleration and deceleration profiles. These are the motor RPMs generated by the onboard VFDs and do not reflect the final RPM per the gearbox. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 47 NON-CRUZ CONTROL ENABLED DNS-Vs so that the timing is perfect for operation. In CRUZ CONTROL ENABLED DNS-Vs this is automatically handled by the Network driving. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 48 V out of “Online” mode. To use the SPIN feature, first turn on SPIN and then use the TOPWHEEL or SIDEWHEEL SPEED SELECTION entry boxes to then select a corresponding Speed profile. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 49 Setting the time is pivotal for your WASH SCHEDULES to run correctly at the appropriate times. You must enter the HOUR, MINUTE, MONTH, DAY and YEAR to properly set the new clock time. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 50 Retract Top Wheel for Vehicles with Tall Front End and/or Steep Vertical Windshield (like Jeep ® Pic #75 Vehicle Restrictions Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 51 THE SIDE BRUSHES MORE OFTEN THAN THE TOP BRUSH. WARNING ENSURE THAT ALL PERSONNEL ARE CLEAR FROM THE EQUIPMENT BEFORE FORCING ANY OUTPUT ON! Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 52 Enter the correct time and date. Enter the new time on the right and verify it is correct on the left under CURRENT TIME  Pic #77 HMI Clock Settings Screen Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 53 Test a car and check for light penetration of the TOP WHEEL from the front of the vehicle to beyond the wiper area. [for small cars 1” brush material penetration.] Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 54 THE CLOTH MATERIAL HAS TO BE WASHED! PROCEED WITH BREAK-IN PROCESS BY PRESSING THE ‘START’ BUTTON UNDER ‘WASH’ IN AUTO/MANUAL MODE. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 55 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 56 Arm & Hammer with Oxi-Clean or comparable product. SEE MANUAL FOR SETUP AND ADJUSTMENT. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 57 Side Wheel Rotation Top Wheel Rotation Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 58 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 59 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 60 Perform daily maintenance. GREASING GREASING POINTS POINTS Pic #79 Top Wheel Axle Bearing Pic #80 Top Wheel Arms Bearings Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 61 Pic #81 Top Wheel Pilot Bearing Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 62 > https://store.motorcitywashworks.com/Team360/Dry-N-Shine/Documents/Media%20Links%20Dry-N-Shine.pdf For all of MCWW current manuals, videos, bulletins and information click the below link. <MCWW Documentation Hub> Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 63 Ensure manual air valve button is not locked into the “on” position. Ensure cloth is not saturated with water. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 64 90PSI. brush. Ensure air valve restrictor is not closed too much at cylinder fitting. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 65 Ensure pulley belts are not too tight or roller assembly binding. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 66 > https://store.motorcitywashworks.com/Team360/Dry-N-Shine/Documents/Media%20Links%20Dry-N-Shine.pdf For all of MCWW current manuals, videos, bulletins and information click the link below. <MCWW Documentation Hub> Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 67 Check that air cylinder Retract. is not leaking. Check that MAC valve is energized allowing air to flow to the correct port. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 68 DNS Side Wheel Main Panel Fault light Check VFD for fault on and beeping. code. Check HMI for E-Stop. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 69 8ELECCNTBLK0006 DNS E- E-STP 0VDC (Two 0VDC- wires) 24VDC- X03 E- Panel Door E-Stop Connections (New – ‘Push/Pull’ Style) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 70 Support Documents: Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 71 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 72 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 73 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 74 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 75 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 76 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 77 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 78 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 79 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 80 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 81 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 82 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 83 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 84 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 85 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 86 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 87 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 88 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 89 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 90 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 91 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 92 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 93 Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 94 [External fault com.] (EPF2) [Internal Error 8] (INF8) [Brake feedback] (BRF) [PC com.] (SLF2) [Encoder Coupling] (ECF) [Torque/current lim] (SSF) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 95 [AI3 4-20mA loss] (LFF3) [AI4 4-20mA loss] (LFF4) [Cards pairing] (HCF) [Load fault] (DLF) [Bad conf] (CFI2) [AI5 4-20 mA loss] (LFF5) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 96 [Program Loading Error] (PGLF) [Program Running Error] (PGRF) [Lead Pump Error] (MPLF) [Low Level Error] (LCLF) [High Level Error] (LCHF) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 97 [Internal Error 30] (INFU) [AFE IGBT over-heat error] (TJF2) [AFE contactor feedback error] (CRF3) [Pre-settings Transfer Error] (CFI3) [Circuit Breaker Error] (CBF) Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 98 SIDEWHEELS) This has to do with the internal communications of the PLC and can be ignored as the Networking service is doing a master reset when trying to communicate to a VFD. Phone: 248.313.0272 ▪ Fax: 248. 313.0271 © Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A. 8MANULDNSINS005 1-16-2023 www.motorcitywashworks.com...
  • Page 99 Warranty and Return Procedure: Motor City Wash Works warrants this product to be free of defect in material and/or workmanship for a period of one year from the date of purchase. During the warranty period MCWW will at its discretion, at no charge to the customer, repair or replace this product if found defective, with a new or refurbished unit, but not to include costs of removal or installation.
