Motor City Wash Works 7AXISAIRPNL0002 Installation Manual

TABLE OF CONTENTS
Equipment Utilities
Equipment Specifications
Suggested Tools and Installation Materials
Installation Instructions
Maintenance
Troubleshooting.......................................................................................................................Page :14
Warranty................................................................................................................................Page: 17
Equipment Utilities
Three & Six Nozzle Pivoting Wheel Blaster, 120 VAC / 24 VAC / 24 VDC Air Panels
ELECTRICAL
PNEUMATICS
WATER
Equipment Specifications and Features

Leg Weldment:

Height: 18-1/4"

Slot: From the Floor, the Height is 4-3/16" (H), Slot Length is 10" (L), Traveling Distance is 5-1/2"

Integrated Aluminum H

Integrated Pneumatic Air Cylinder, Mechanically Pivots the Manifold

Three Positions to Set Desired Pivoting Angle:

Furthest: Approx. ± 15°

Middle: Approx. ± 20°

Inside: Approx. ± 25°
Suggested Installation Tools and Materials

Safety Goggles

Measuring Tape

Torpedo Level

Hammer Drill with Required bits

Standard Allen Wrenches

Set of Standard Combo Wrenches
© Motor City Wash Works, Inc. 48285 Frank, Wixom Michigan 48393 U.S.A.
8MANULWPBRINS01 11-18-20
PIVOTING WHEEL BLASTER INSTALLATION MANUAL
Part #:7AXISAIRPNL0002, 3, 4 & 7WHELBLSTRDRV01, 02 & 7WHELBLSTRPAS01, 02
POWER:
25-50 PSI OPERATING PRESSURE
RECLAIMED OR FRESH:
THREE NOZZLE: 9 GPM
SIX NOZZLE: 18 GPM
O Filter
2
www.motorcitywashworks.com
REV 1.0
120 VAC / 24 VAC / 24 VDC

Hammer

Wedge Anchor Bolts 1/2"

Amp Meter/Volt Meter

Wire Stripper

Teflon Tape

1/4" OD Polyflow Tubing
Phone: 248.313.0272 ▪ Fax: 248. 313.0271
Page: 1
