  • Page 1 WALLMOUNTED RANGEHOODS INSTRUCTION MANUAL Installation / Operation / Maintenance WM LIN9S KLS ALBW9S KLS ALBB9S (10.2021 / V3)
  • Page 2 INDEX Welcome Important Safety Information Description Operation Cleaning and Maintenance Installation Condensation Information Troubleshooting Technical Speci cations Disclaimer Page 2...
  • Page 3 WELCOME Thank you for purchasing this Schweigen IN appliance. IMPORTANT! To achieve the optimal performance from your The appliance should only be appliance, and to avoid the risk of accident or operated when you have read and damage, it is essential to read this manual before understood this manual thoroughly.
  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION Please read the instructions carefully. Only then Flames beneath the pan must be contained at all will you be able to operate your appliance safely times and cannot exceed the width of the pan in and correctly. Retain the instruction manual for use.
  • Page 5: Before Installation

    We recommend this appliance be installed or that fail to heed the applicable legislation on repaired by a quali ed Schweigen Home Appliances electrical safety. technician. The electrical technical data can be found inside Please see our website www.schweigen.com.au...
  • Page 6: Product Use

    IMPORTANT SAFETY INFORMATION PRODUCT USE MAINTENANCE AND SERVICE This product is designed for household use and The rangehood surface should be cleaned with soft should not be used for commercial applications. cloth and non-corrosive detergent. Do not leave the rangehood wet after cleaning or use, please After use, always ensure that all controls are in keep rangehood dry.
  • Page 7 DESCRIPTION Rangehood 1. Flue Wall Mounting Bracket 2. Extension Flue 3. Main Flue 4. Single Outlet 200mm 5. PCB (computer) Board 6. Connect to the Isodrive ® motor system 7. Male Plug (Connect to Mains Power 240V 10 Amp) 8. Reducer (For Isodrive ®...
  • Page 8: Operation

    OPERATION Electronic Controls Model WM-LIN9S. The rangehood has a 4-speed electronic keypad. Speed control usage suggestions: • Low speed for simmering. • Medium speed for light cooking. • High speeds for heavy frying or heavy cooking. To obtain the best performance, switch the D.- Reduce speed: This button reduces the...
  • Page 9 OPERATION Electronic Touch Controls Models KLS-ALBW9S and KLS-ALBB9S. The rangehood has a 4-speed electronic keypad. Speed control usage suggestions: • Low speed for simmering. • Medium speed for light cooking. • High speeds for heavy frying or heavy cooking. To obtain the best performance, switch the F.- Timer: When the timer mode is in operation, rangehood on a few minutes prior to cooking and the timer button light will remain on.
  • Page 10: Cleaning And Maintenance

    CLEANING AND MAINTENANCE WARNING Always switch o and disconnect power to the rangehood before cleaning. The manufacturer is exonerated from all responsibility in the event of re due to poor maintenance of the lters and rangehood. Cleaning and user maintenance shall not be made by children without supervision. FILTERS •...
  • Page 11 CLEANING AND MAINTENANCE SURFACES Do not pour any liquid directly onto the rangehood, apply to a soft cloth rst. The surface of the rangehood can be cleaned with The cloth must have no buttons, zips or fasteners warm soapy water and a soft sponge / cloth. that can scratch the surface.
  • Page 12: Replacing The Led Bulb

    CLEANING AND MAINTENANCE WARNING Always switch o and disconnect the power cord before replacing any light bulbs. Failure to do so may cause serious injury. Please be aware that the light bulb will retain heat for a short period of time after being switched o . Your rangehood may have multiple light types, please refer to the pictures below for light replacement instructions.
  • Page 13 CLEANING AND MAINTENANCE TYPE 3 (Halogen G4HD, LED G4): Type 3 — Halogen G4 HD, LED G4 REPLACING THE HALOGEN OR LED BULB MAX 20W, 12V 1. Press on the indicated zone “push” (1) 2. Open the light cover to an angle of 90º, DO NOT force past 90º.
  • Page 14: Installation

    INSTALLATION RANGEHOOD SIZE VS COOKTOP SIZE In addition to the size, the height of the rangehood above the cooktop is important to obtain the best performance. INADEQUATE ADEQUATE OPTIMAL Rangehood smaller than Rangehood same size as Rangehood larger than cooking zone cooking zone cooking zone Page 14...
  • Page 15: Mounting Instructions

    Note: If the instructions for the gas cooktop specify a greater distance, this must be taken into account. RECOMMENDED INSTALLATION HEIGHT FOR INDUCTION COOKTOP To help avoid condensation, particular to cooking with an induction cooktop, Schweigen recommends a height of 700-750mm. Refer to page 22 for further information.
  • Page 16 INSTALLATION ATTACHING THE COMPUTER BOARD AND WIRING BRACKET CERTAIN MODELS ONLY Before you install the rangehood, you may need to connect the computer board and wiring bracket to the main body of the rangehood. 1. Attach the computer board to the outlet box using the screws provided.
  • Page 17: Installing The Rangehood

    INSTALLATION INSTALLING THE RANGEHOOD A — Rangehood levelling screw points B — Main support bracket, wall screw points C — Second rangehood screw points D — Main support bracket NOTE: Some models might need the computer board and wiring bracket to be attached, see page 10 .
  • Page 18 INSTALLATION Step 3 Using a leveller, level the rangehood using screws (A). Once levelled, secure it rmly to the wall (C) using the appropriate screws. Step 4 Feed through and secure the exi ducting from the rangehood outlet to the Isodrive motor. Step 5 Inner ue cover Place ue covers onto the rangehood and adjust...
  • Page 19 INSTALLATION Step 6 Figure 2 Install the wall ue bracket. 1. Fold both ends to 90° as shown gure 1. 2. Install the bracket to the wall at the correct height, see gure 2. 3. Attach ue cover to the bracket, see gure 3. Figure 1 Fold along these lines Figure 3...
  • Page 20 INSTALLATION Please DO NOT crush or kink the ducting. 1. Crushed or kinked ducting creates sharp corners that creates turbulence. This reduces the size and e ciency of the ducting, lowers extraction and may cause excessive noise. 2. Sweeping curves and taut ducting reduces resistance and turbulence.
  • Page 21: System Overview

    INSTALLATION SYSTEM OVERVIEW 1. Isodrive ® Motor 2. Roof Seal Kit (Dektite) (Not Supplied)* 3. Support Straps (Not Supplied)* 4. Attach Flexi Duct to Bell-Mouth Adaptor using ring clamp. Please DO NOT rip the ducting. 5. Isodrive ® Motor Power Lead (Male Plug) 6.
  • Page 22: Troubleshooting

    TROUBLESHOOTING COOKING WITH INDUCTION How to reduce the possibility of condensation forming: COOKTOPS • Ensure the rangehood is installed by a quali ed Cooking with an induction (or similar) cooktop, professional, carefully following the installation may produce condensation on the rangehood. guide.
  • Page 23 TROUBLESHOOTING Before you contact the technical service department, make sure that the product IMPORTANT is plugged in and power is supplied. Never attempt to repair this • Do not take any action that will damage appliance by yourself. Always the product. refer to a quali ed Service Technician.
  • Page 24: Faulty Installation

    0800 200 510 FAULTY INSTALLATION It is not the responsibility of Schweigen to rectify any incorrect installations. A service call out fee will be charged for any Schweigen technician that attends a call, whereby it is established that the fault is due to an incorrect installation or non-manufacturing fault.
  • Page 25: Technical Specifications

    TECHNICAL SPECIFICATIONS KLS ALBW9S, KLS ALBB9S Model: KLS-ALBW9S, KLS-ALBB9S Feeding Voltage: 220-240V 50Hz Max Lamp Power: 2 x GLED Square 55 x 55mm 2.1 Watts 12V 4000k 1 x Fluorescent Tube Double 860mm Capped 21W 12V Page 25...
  • Page 26 TECHNICAL SPECIFICATIONS WM-LIN9S Model: WM-LIN9S Feeding Voltage: 220-240V 50Hz Max Lamp Power: 2 x GLED Square 55 x 55mm 2.1W 12V 4000k Page 26...
  • Page 27: Disposal Of Old Appliances

    All pictures used in own determination as to its suitability for their the guide are for illustrative purposes only. purpose/s prior to use. In no event will Schweigen Although our information and marketing states Home Appliances be responsible for damages of the term ‘Silent’...
  • Page 28 © Schweigen Home Appliances Pty Ltd. 2021. Australia Unit 4/1-5 Lake Drive, Dingley Village, Victoria 3172 Phone: 1300 881 693 Email: sales@schweigen.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610 Phone: 0800 200 510 Email: info.parex@emerson.com www.schweigen.com.au...
