- Page 1 48in (1.22m) PORTABLE BASKETBALL SYSTEM 92004X 92004C1X ITEM NUMBERS: www.franklinsports.com/92004X Made In China Franklin Sports Inc. Stoughton, MA 02072...
-
Page 2: We're Here For You
CUSTOMER SERVICE COMMITMENT Thank you for purchasing this Franklin product! In the event that ® the product you've purchased has missing or damaged parts, please contact us at: parts@franklinsports.com www.franklinsports.com Visit our website at: If possible, please include product part number and parts description so we can best assist you. -
Page 3: Safety Instructions
Most injuries are caused by misuse and/or not following instructions. Use caution when using this system. PARTS LIST Upper Handle Bar Bottom Pole Middle Pole Top Pole Bottom Pole Brace Lower Handle Bar Rep. Part: 92004X-R1 Rep. Part: 92004X-R2 Rep. Part: 92004X-R3 Backboard Base Short Backboard Connecting Tube Long Backboard Connecting Tube M8* 45mm... - Page 4 Then, insert Base Pole Axle (#19) through the holes in the bottom of both Base (#12) and Bottom Pole (#1). This will secure Bottom Pole (#1) to Base (#12). For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 5 (#22) into Wheel (#21). Insert Wheel Axle and Wheels into Base (#12). Push with force to push wheel axle into position.These will click into place once they are secured. For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 6 M8 25mm Bolt, Washer & Screw Set (#16). Then attach Bottom Pole Brace (#4) to Bottom Pole (#1) using M8 90mm Bolt, Washer & Screw Set (#17). For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 7 To attach Middle Pole Mounting Plate (#20) to Middle Pole (#2) use M8 90mm Bolt, Washer & Screw Set (#17). NOTE: Ensure middle pole mounting plate is attached to back. For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 8 STEP 5 PARTS NOTE To join Top Pole (#3) with Middle Pole (#2) use M8 85mm Bolt, Washer & Screw Set (#25). For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 9 STEP 6 PARTS NOTE To attach Middle Pole (#2) to Bottom Pole (#1) use M8 85mm Bolt, Washer & Screw Set (#25). For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 10 M8 90mm Bolt, Washer & Screw Set (#17), Cup Washer (#27), Large Spring (#26), M8 60mm Bolt, Washer & Screw Set (#29) & Short Spring (#28) as shown. 29 28 For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 11 STEP 8 PARTS NOTE Attach Backboard Connecting Plate (#13) to backside of Backboard (#19) using M10 40mm Bolt, Washer & Screw Set (#15) as shown. For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 12 PARTS NOTE Attach both Short Backboard Connecting Tube (#7) & Long Backboard Connecting Tube (#8) to Top Pole (#3) using M12 160mm Bolt, Washer & Screw Set (#18). For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 13 Short Size (#23) between Upper Handle Bar (#6) and Long Backboard Connecting Tube (#8). Secure these parts together with M12 160mm Bolt, Washer & Screw Set (#24) as shown. For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 14 Sand. When the base is filled with sand, player must check the leakage of the base to prevent the base instability, leading to injury. Wrap pole cover #30. For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
-
Page 15: Height Adjustment
3. Carefully rotate basketball system upright. 4. Check system for stability Do not adjust height of system in upright position. System must be in down position to adjust. For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649... - Page 16 HEIGHT NOTE Adjust height as shown to players desired height. Height 10 feet (3.0m) Position 7ft 6in (2.3m) For replacement parts: Visit: www.franklinsports.com/92004X ITEM#: 92004X 92004C1X Email: parts@franklinsports.com Call: 1-800-225-8649...
- Page 17 During play, do not wear jewelry (rings, watches, necklaces, etc.). POSITION IF THE BASE IS NOT Objects may entangle in net. PROPERLY FILLED WITH SAND. YOU ARE NOW READY TO PLAY! For replacement parts: Visit: www.franklinsports.com/92004X Email: parts@franklinsports.com Call: 1-800-225-8649...
