SKYDANCE ES-DP(WT) Manual

ES-DP(WT)
Dual Push Button WiFi SPI LED Controller
● Dual push button input RGB or white light SPI LED controller, Tuya smart APP cloud control.
● Voice control, support for Amazon Alexa, Google Assistant,
Tmall Genie and Xiaodu smart speakers.
● Two groups same SPI(TTL) signal output, drive 28 kinds IC digital RGB or white LED strip,
IC type and R/G/B order can be set.
Compatible ICs:




TM1804, TM1809, TM1812, UCS1903, UCS1909, UCS1912,
UCS2903,UCS2909, UCS2912, WS2811, WS2812, TM1829,
TM1914A, GW6205,GS8206,GS8208,LPD6803, LPD1101,
D705, UCS6909, UCS6912, LPD8803,LPD8806, WS2801,
WS2803, P9813, SK9822, SM16703P.
● When applied to stair light, supports four output modes:
color ow, white ow, color step, white step.
● Sequential switching control is realized when multiple SPI controllers
are connected to a single self-resetting push switch button.
●

Multiple light colors and change types are selectable with adjustable speed and brightness.
● APP painted segment color mixing: full color lling, color pencil segment painting,
eraser segment light off.
● APP custom rich dynamic effects: 44 default and 10+ custom dynamic scenarios, 16 variations.
● 3 APP music rhythms.
Technical Parameters
Input and Output
Input voltage
5-24VDC
Input current
15A
Output signal 2
X
SPI(TTL)
Max 960
Pixel number
Input signal Push button +WiFi
Mechanical Structures and Installations
UP Push switch
DW Push switch
Push switch COM
Installation rack
System
wiring
3G/4G/5G
RGB-SPI
Mobile Phone
Note:

1
he
. T above
distance
is
measured
in
spacious
(no
obstacle)
environment, please
refer
to
the
actual
test
distance
before
installation.
2.
Please
check
if
the
WiFi router
net
in
2.4G
band, the
5G
band is
not
available, and do
not
hide
your
router
network.
3. Please
keep
the
distance
between
ES-DP(WT) devices
and
router
close, and
check
the
WiFi
signals.
4. WiFi signal strength detection:
User Manual Ver 1.0.0
2024.5
Environment
Operation temperature
Case temperature (Max.)
IP rating







Package
Size
Gross weight
UP ES-DP(WT)
WiFi SPI LED Controller
DW
Uin=5-24VDC
Uout=2 x SPI Signal
GND
Temp Range:
-30℃~+55℃
0.5-2.0mm²
M
4-5mm
Digital display
Setting key
Tuya Cloud
WiFi
WiFi 15m
WiFi
Router
open the main interface of social security,
O O
Ta:
-30 C ~ +55 C
O
Tc :
+65 C
IP
20
L175 x W54 x H27mm
0.127kg
2 groups SPI
(DATA+CLK)
CLK2
signal output
DATA2
CLK1
Installation rack
DATA1
V Power output -
V
Power Input -
V+
V+
Power output +
Power Input +
M
ES-DP(WT)


click enter the device interface
Stair Light Controller
Safety and EMC
ETSI EN 301 489-1 V2.2.3
EMC standard (EMC)
ETSI EN 301 489-17 V3.2.4
Safety standard
EN 62368-1:2020+A11:2020
Certification CE, EMC
Warranty
Warranty 5 years



























170mm
50mm
23mm
RGB pixel LED strip
, click " check device network " for testing.
Wired
connection
Wireless
connection
Page 1
