Contents
Working Techniques ......................... 3
Handle and Harness ....................... 18
(CombiTools) .................................. 20
Split Drive Tube .............................. 21
Mounting the Bike Handle .............. 21
Mounting the Loop Handle ............. 23
Fitting the Carrying Eye* ................ 24
Mounting the Deflector ................... 25
Fuel ................................................ 30
Fueling ............................................ 31
Fitting the Harness ......................... 31
Balancing the Brushcutter .............. 32
the Engine ...................................... 33
Operating Instructions .................... 36
Cleaning the Air Filter ..................... 36
Motor Management ........................ 37
Adjusting the Carburetor ................ 37
in Muffler ......................................... 39
Checking the Spark Plug ................ 39
Lubricating the Gearbox ................. 40
and Rewind Spring ......................... 40
Storing the Machine ........................ 43
Replacing the Nylon Line ............... 44
*
see "Guide to Using this Manual"
STIHl
FS 80, FS 85, FS 85 T
Maintenance Chart ......................... 48
Parts and Controls ......................... 49
Specifications ................................. 52
Special Accessories ....................... 53
Maintenance and Repairs .............. 54
STIHL Incorporated Federal
and California Emission Control
Warranty Statement ........................ 55
english / USA
Allow only persons who understand this
manual to operate your brushcutter.
To receive maximum performance and
satisfaction from your STIHL brush-
cutter, it is important that you read and
understand the maintenance and safety
precautions, starting on page 3, before
using your brushcutter.
Contact your STIHL dealer or the STIHL
distributor for your area if you do not
understand any of the instructions in this
manual.
!
Warning!
Because a brushcutter is a high-speed
cutting tool some special safety pre-
cautions must be observed to reduce
the risk of personal injury.
Careless or improper use may cause
serious or even fatal injury. Make sure
your unit is equipped with the proper
deflector, handle and harness for the
type of cutting attachment being used.
Always wear proper eye protection.
STIHL's philosophy is to continually
improve all of its products. As a result,
engineering changes and improve-
ments are made from time to time. If the
operating characteristics or the appear-
ance of your brushcutter differs from
those described in this manual, please
contact your STIHL dealer for informa-
tion and assistance.
1
