Summary of Contents for Stihl FS 235
- Page 1 STIHL FS 235 Instruction Manual...
-
Page 3: Table Of Contents
English Contents 7.1 Fitting and Adjusting the Carrying System ..18 Introduction ......... 2 7.2 Balancing the Trimmer . -
Page 4: Introduction
STIHL product. 19.1 STIHL FS 235 Trimmer ......30 19.2 Noise and Vibration Data. -
Page 5: Symbols Used With Warnings In The Text
English 3 Overview Symbols used with warnings in the text 3 Overview WARNING Trimmer This symbol indicates dangers that can cause serious injuries or death. ► The measures indicated can avoid serious injuries or death. NOTICE This symbol indicates dangers that can cause damage to property. -
Page 6: Deflectors And Cutting Attachments
Blocks shaft while cutting attachment is being mounted. 8 Starter Grip 25 Screw Plug Serves to crank the engine. Closes filler opening for STIHL gear grease. 9 Carburetor Adjusting Screws # Rating Label with Serial Number For tuning the carburetor. -
Page 7: Carrying Systems
English 3 Overview Symbols 4 Line Limiting Blade Trims mowing line to correct length. Meanings of symbols that may be on the trimmer and the deflector: 5 Skirt Extends universal deflector for use with a mowing head. This symbol marks the fuel tank. 6 Mowing Head The mowing head contains the mowing line. -
Page 8: Safety Precautions
English 4 Safety Precautions Maintain safe distance. 4 Safety Precautions 15m (50ft) Warning Signs Do not touch hot surface. 4.1.1 Warning Symbols Meanings of warning signs on the trimmer: 4.1.2 Universal Deflector and Skirt Observe safety notices and take the necessary precautions. -
Page 9: Intended Use
Intended Use supervision of or as instructed by a responsible The STIHL FS 235 trimmer is designed for the following person. applications: – The user is able to recognize and assess the risks –... -
Page 10: Work Area And Surroundings
English 4 Safety Precautions ￭ The user can come into contact with the cutting ► Wear close-fitting safety glasses. Suitable attachment or line limiting blade during cleaning and safety glasses that have been tested and maintenance work. This can result in personal injury. labeled in accordance with EN 166 or national standards are available from ►... - Page 11 ► Work only with an undamaged trimmer. ► If you have any queries: Contact your STIHL servicing dealer. ► If fuel is leaking from the trimmer: Do not use the trimmer and contact a STIHL dealer for assistance.
-
Page 12: Fuel Mixture And Refueling
► Deburr the cutting edges with a file. ￭ Clothing that has been in contact with fuel or gasoline is ► Have the metal cutting attachment balanced by a STIHL more easily flammable. This can result in serious or fatal servicing dealer. -
Page 13: Operation
► Use a mixture of gasoline and two-stroke engine oil that ► Work calmly and carefully. is not older than 30 days (STIHL MotoMix: 2 years). ￭ The user will not be able to control the trimmer properly if it is operated with the slide control in position Operation This can result in serious injuries. -
Page 14: Reactive Forces
￭ In an emergency, the user may panic and not put the can result in serious injuries and damage to property. carrying system down. This can result in serious injuries. ► Stop work and contact your STIHL dealer for ► Practice removing and putting down the carrying assistance. -
Page 15: Transporting
English 4 Safety Precautions WARNING 4.11 Storing WARNING ￭ These situations can abruptly decelerate or stop rotation of the cutting attachment and cause the cutting ￭ Children are not aware of and cannot assess the dangers attachment to be thrown to the right or in the direction of of a trimmer and can be seriously injured. -
Page 16: Preparing Trimmer For Operation
► If you cannot carry out these steps: Do not use your trimmer and contact your STIHL dealer for assistance. ￭ The user can be cut by the sharp cutting edges while cleaning or maintaining cutting attachments. This can result in personal injury. -
Page 17: Mounting The Bike Handle
English 6 Assembling the Trimmer ► Insert and tighten down the screw (3) firmly. The carrying ring need not be removed again. Mounting the Bike Handle ► Shut off the engine. ► Position the control handle (7) and throttle cable (11) over and along the drive tube (5) –... -
Page 18: Fitting And Removing The Skirt
English 6 Assembling the Trimmer ► Slide the guide slot in the skirt (2) onto the deflector (1) – ► Push the deflector (1) into the guides on the gear housing it must snap into position. as far as stop. ►... -
Page 19: Removing And Installing Metal Cutting
English 6 Assembling the Trimmer Removing and Installing Metal Cutting Attachment 6.6.1 Mounting the Metal Cutting Attachment ► Shut off the engine. ► Place the thrust plate (2) on the shaft (3) so that its smaller diameter faces up. ► Fit the mowing head (1) on the shaft (3) and turn it counterclockwise. -
Page 20: Adjusting Trimmer For User
English 7 Adjusting Trimmer for User Balancing the Trimmer ► Rotate the metal cutting attachment (4) counterclockwise until the stop pin (7) engages in position. The unit is balanced differently depending on the cutting The shaft (6) is now blocked. attachment used. -
Page 21: Adjusting The Bike Handle
STIHL recommends you use STIHL MotoMix. Adjusting the Bike Handle If you mix the fuel yourself, use only STIHL two-stroke The bike handle can be set to different positions to suit the engine oil or another high-performance engine oil in accordance with JASO FB, JASO FC, JASO FD, ISO-L- height and reach of the user. -
Page 22: Fueling The Trimmer
English 9 Starting and Stopping the Engine ► Make sure that the octane number of the gasoline is at least 90 RON and the ethanol content is not more than NOTICE 10%. Bright light, sunlight and extreme temperatures can cause the fuel mix to separate much faster. -
Page 23: Preparing Engine For Start
English 9 Starting and Stopping the Engine ► Prepare engine for start and then start the engine. When can the engine be started without preparation? The engine can be started without preparation if it has been running for at least 1 minute and only shut down for a short work break. -
Page 24: Stopping The Engine
► Press the trimmer against the ground with your left hand. The engine stops. ► Pull the starter grip slowly with your right hand until you ► Do not use your trimmer and contact your STIHL dealer feel it engage. for assistance. -
Page 25: Operating The Trimmer
► Move the choke lever to position delivers optimum power. The engine stops. ► Do not use your trimmer and contact your STIHL dealer 11.2 Holding and Controlling the Trimmer for assistance. There is a malfunction in the slide control. -
Page 26: Mowing
English 11 Operating the Trimmer 11.4 Sawing ► Hold the trimmer firmly with your right hand on the control handle – wrap your thumb around the handle. ► Support the left side of the deflector against the stem. ► Hold the trimmer firmly with your the left hand on the left ►... -
Page 27: After Finishing Work
13 Transporting 15.1 Cleaning the Trimmer ► Shut off the engine. ► Allow trimmer to cool down. 13.1 Transporting the Trimmer ► Clean the trimmer with a damp cloth or STIHL resin ► Shut off the engine. solvent. 0458-507-0121-A... -
Page 28: Cleaning The Deflector And Cutting Attachment
Monthly ► Have fuel tank cleaned by a STIHL servicing dealer. 15.3 Cleaning the Spark Plug ► Have pickup body (filter) in fuel tank cleaned by a STIHL ► Shut off the engine. servicing dealer. ► Allow trimmer to cool down. -
Page 29: Adjusting The Throttle Cable
STIHL recommends you have metal cutting attachments resharpened and balanced by a STIHL servicing dealer. ► Sharpen the metal cutting attachment as described in the instructions and on the packaging supplied with the cutting attachment you are using. -
Page 30: Troubleshooting
English 18 Troubleshooting 18 Troubleshooting 18.1 Troubleshooting Trimmer Most malfunctions have the same causes. ► Perform the following operations: ► Replace air filter. ► Clean or replace the spark plug. ► Carry out the standard setting. ► Adjust idle speed. ►... -
Page 31: Replacing The Air Filter
English 18 Troubleshooting 18.3 Standard Setting ► Shut off the engine. 18.2 Replacing the Air Filter The air filter cannot be cleaned. The air filter must be replaced if there is a loss of engine or the air filter is damaged. -
Page 32: Clearing The Combustion Chamber
9,000 rpm – Idle speed: 2,800 rpm – Max. output shaft speed: 7,900 rpm – Approved spark plug: Bosch WSR 6 F from STIHL – Electrode gap: 0.5 mm ► Pull off the spark plug boot (1). – Dry weight without cutting attachment and deflector: ►... -
Page 33: Noise And Vibration Data
– Vibration level ahv, eq measured according to ISO 22867 – Control handle: 2.9 m/s². – Left handle: 4.3 m/s² Information on compliance with Vibration Directive 2002/44/EC is available at www.stihl.com/vib. 19.3 REACH REACH is an EC regulation and stands for the Registration, Evaluation, Authorisation and Restriction of Chemical substances. -
Page 34: And Carrying Systems
English 20 Combinations of Cutting Attachments, Deflectors and Carrying Systems 20 Combinations of Cutting Attachments, Deflectors and Carrying Systems 20.1 Combinations of Cutting Attachments, Deflectors and Carrying Systems Cutting Attachment Deflector Carrying System – AutoCut C 26-2 mowing head – Universal deflector with –... -
Page 35: Spare Parts And Accessories
The measured and guaranteed sound power levels were accessories. determined according to Directive 2000/14/EC, Annex VIII. STIHL recommends the use of original STIHL replacement – Measured sound power level: 111 dB(A) parts and accessories. – Guaranteed sound power level: 113 dB(A) Original STIHL replacement parts and original STIHL accessories are available from STIHL servicing dealers. - Page 36 0458-507-0121-A englisch www.stihl.com *04585070121A* 0458-507-0121-A...
