air conditioning fan heaters with ec motor
PLUS
» Low sound levels
» Wide operating range (up to 65 °C intake air)
» Axial fan with blades with an aerodynamic profile (Hy-
Blade® technology)
» Electric motor, class F, approved for continuous
operation
» Fan and motor are integrated to provide considerably
increased reliability
Technical manual
AREO i
11 -118 k W
EC Motor
2 pipes systems
Vertical
Heating
installation
EN
Cooling
Advertisement
Table of Contents
Related Manuals for Galletti AREO i
Summary of Contents for Galletti AREO i
- Page 1 Technical manual AREO i air conditioning fan heaters with ec motor 11 -118 k W EC Motor 2 pipes systems Vertical Heating Cooling installation PLUS » Low sound levels » Wide operating range (up to 65 °C intake air) » Axial fan with blades with an aerodynamic profile (Hy- Blade®...
- Page 2 Dear Customer, Thank you for placing your trust in one of the products of Galletti S.p.a This product is the result of our work and our commitment to design, research, and production and has been made from the finest materials, employing state-of-the-art components and production technology.
-
Page 3: Table Of Contents
TABLE OF CONTENTS MAIN FEATURES p 4 CONFIGURATOR p 4 MAIN COMPONENTS p 4 STRUCTURE p 4... -
Page 4: Main Features
The AREO i range consists of 35 models to be wall mounted. of the rotation speed and maximum adaptability to real-time AREO i is ideal for both heating and cooling due to an innova- thermal load. tive system for collecting condensate and additional insulation innovative inverter technology makes it possible to achieve an inside the cabinet. -
Page 5: Accident Grill P
ACCIDENT GRILL made of electrogalvanised steel wire, it supports the motor and is fixed to the cabinet by means of vibration-damping supports. EXPLODED VIEW » 31 Legend 1) Cover cabinet: side panel 5) Accident grill (fan) motor support 9) Top cover of heat exchanger 2) Cover cabinet: upper panel 6) Adjustable louvers 10) Air conveyor duct... -
Page 6: Installation Requirements
Ū Water temperature: 7 °C ÷ 95 °C Ū Air temperature: -10 °C ÷ 60 °C rated +/-10% Ū Supply voltage: Ū Max. water pressure during operation: 10 bar Ū Limit of room air relative humidity: RH<95% not condens- AREO i TECHniCAL MAnuAL... -
Page 7: Installation
INSTALLATION provided in the technical catalogue, according to the num- Remove the fan heater from the packing container and check that no damage has occurred during transport. ber of motor poles and type of air flow of the unit. The maxi- Before starting to install the unit, make sure that the instal- mum installation height is shown in figure p. 7. - Page 8 » 51 AREO i 1400 1400 AREO HV (m) LV (m) HV (m) LV (m) HV (m) LV (m) HO (m) LO (m) HO (m) LO (m) HO (m) LO (m) 11,0 10,0 15,5 12,0 15,0 12,0 14,5 12,0 19,0...
- Page 9 from forming within the heat exchange coil, and in the case of operation in the cooling phase, to ensure proper drainage of the condensate. if the unit is to be ceiling mounted (for vertical air flow), make sure it is installed in a perfectly level position. On completing installation, open and direct the louvers.
-
Page 10: Electric Motors Features
Power input (1) absorption (1) Mod. V-ph-Hz AREO33iMDF 230-1-50 2,10 AREO34iMDF 230-1-50 2,10 AREO43iMDF 230-1-50 4,90 AREO43iTDC 400-3-50 1,80 AREO63iMDF 230-1-50 5,00 AREO63iTDF 400-3-50 1,70 AREO63iMDC 230-1-50 5,00 AREO63iTDC 400-3-50 1001 1,70 1. Referred to maximum speed AREO i TECHniCAL MAnuAL... -
Page 11: Available Accessories
AVAILABLE ACCESSORIES Electronic microprocessor control panels with display DIST MY COMFORT controller spacer for wall mounting EVO-2-TOUCH 2.8” touch screen user interface for EVO control EVOBOARD Circuit board for EVO control EVODISP User interface with display for EVO controller MCLE Microprocessor control with display MY COMFORT LARGE MCSWE Water sensor for MYCOMFORT and EVO controllers... -
Page 12: Rated Technical Data
RATED TECHNICAL DATA » Available versions AREO i Single-phase - Supplier 1 - Maximum speed Three-phase - Supplier 1 - Maximum speed Single-phase - Supplier 2 - Reduced speed 1 Three-phase - Supplier 2 - Reduced speed 1 Single-phase - Supplier 2 - Maximum speed Three-phase - Supplier 2 - Maximum speed »... - Page 13 » Technical data - Cooling mode AREO i 12MEC 13MEC 14MEC 22MEC 23MEC 24MEC 32MEC 33MEC Power supply V-ph-Hz 230-1-50 Air flow rate max cooling m³/h 1538 1616 1570 2409 2362 Heating capacity 5,26 7,43 8,73 9,10 12,8 14,2 16,5...
- Page 14 » Technical data - Cooling mode AREO i 33MDF 34MDF 43MDF 43TDC 63MDF 63TDF 63MDC 63TDC Power supply V-ph-Hz 230-1-50 230-1-50 230-1-50 400-3-50 230-1-50 400-3-50 230-1-50 400-3-50 Air flow rate max cooling m³/h 2601 2414 3848 4164 4107 4471 5746...
-
Page 15: Performances
PERFORMANCES Galletti has developed on its www.galletti.com web-area the new On-LinE integrated platform for product selection, configuration and the making of the economic offer. The software, whose use is easy and intuitive, allows the identification of the desired products by calculating their performances based on real working conditions and their configuration helping the user in choosing options and accessories. -
Page 16: Sound Power Levels
77,2 74,0 73,6 69,7 AREO63iMDC 76,2 78,7 74,6 72,2 69,0 68,6 64,7 AREO63iTDC 85,2 80,7 83,6 81,2 71,0 77,6 73,7 1. Total sound power level, weighted A 2. Sound power level by octave band, not weighted AREO i TECHniCAL MAnuAL... -
Page 17: Electrical Wiring Diagram Legend
11 ELECTRICAL WIRING DIAGRAM LEGEND Make the electrical connections with the power supply disconnected, in accordance with current safety regulations. Check that the mains electricity supply is compatible with the voltage shown on the unit rating plate. The electrical connections indicated must be made by the installer Ū... -
Page 18: Electrical Connection Diagrams
12 ELECTRICAL CONNECTION DIAGRAMS » Wiring diagram AREO 1-2-3 singlephase for control MYCOMFORT LARGE (supplier 1) » 121 AREO i TECHniCAL MAnuAL... - Page 19 » Wiring diagram AREO 4-6 singlephase for control MYCOMFORT LARGE (supplier 1) » 122 AP66001026-01 All copying, even partial, of this manual is strictly forbidden...
- Page 20 » Wiring diagram AREO 5 singlephase for control MYCOMFORT LARGE (supplier 1) » 123 AREO i TECHniCAL MAnuAL...
- Page 21 » Wiring diagram AREO 4 three-phase for control MYCOMFORT LARGE (supplier 1) » 124 AP66001026-01 All copying, even partial, of this manual is strictly forbidden...
- Page 22 » Wiring diagram AREO 5-6 three-phase for control MYCOMFORT LARGE (supplier 1) » 125 AREO i TECHniCAL MAnuAL...
- Page 23 » Wiring diagram AREO 3-4-6 singlephase for control MYCOMFORT LARGE (supplier 2) » 126 AP66001026-01 All copying, even partial, of this manual is strictly forbidden...
- Page 24 » Wiring diagram AREO 4-6 three-phase for control MYCOMFORT LARGE (supplier 2) » 127 AREO i TECHniCAL MAnuAL...
-
Page 25: Overall Dimensions
13 OVERALL DIMENSIONS » 131 AREO i “ “ 12MEC - 13MEC - 14MEC 19-19-20 22MEC - 23MEC - 24MEC 25-26-27 32MEC - 33MEC - 34MEC - 33MDF - 34MDF 33-34-36 42MEC - 42TEC - 43MEC - 43TEC - 44MEC -... - Page 26 13.1 INSTALLATION DISTANCE » 132 13.2 ACCESORIES DIMENSIONAL » 133 GR dimensional - rainproof rain Frame A (mm) B (mm) C (mm) AYGR1 AYGR2 AYGR3 AYGR4 AYGR5 AYGR6 AREO i TECHniCAL MAnuAL...
- Page 27 » 134 Dimensional drawing PAE Frame Intake air (mm) Hole on wall (mm) AYPAE1 392 X 392 400 x 400 AYPAE2 492 x 492 500 x 500 AYPAE3 592 x 592 600 x 600 AYPAE4 692 x 692 700 x 700 AYPAE5 792 x 792 800 x 800...
-
Page 28: Accessories
Designed for wall recess mounting, it controls the proportional opening and closing of the motor-driven regulating louver PAE MM (from 0 to 100%). PAE - External air intake It permits fresh air intake from the outside. It is supplied complete with wall brackets. It is usually mounted with the GR rain protection grille AREO i TECHniCAL MAnuAL... - Page 29 PAE M - Manual mixing external air intake louver Permits to mix recovered air with external fresh air. The manual regulation permits to change the fresh air percentage from 0 to 100%. This accessory is supplied with wall brackets. It is recommended to use it in conjunction with GR rain-protecting grille. PAE MM - Manual mixing external air intake louver Permits to mix recovered air with external fresh air.
-
Page 30: Maintenance
NOTE: it is recommended to carry out these operations at least once a year before the start of the heating season. AREO i TECHniCAL MAnuAL... - Page 31 Romagnoli 12/a 40010 Bentivoglio (BO) - italy Ph. +39 051/8908111 - Fax +039 051/8908122 www.galletti.com...
