Mercury GO BOLDLY Avator 75e Operation And Maintenance Manual

Electric outboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operation
and
Maintenance
Manual
Scan for service and support information

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GO BOLDLY Avator 75e and is the answer not in the manual?

Questions and answers

Related Manuals for Mercury GO BOLDLY Avator 75e

Summary of Contents for Mercury GO BOLDLY Avator 75e

  • Page 1 Operation Maintenance Manual Scan for service and support information...
  • Page 3 Thank you for purchasing one of our products. We sincerely hope your boating will be pleasant. Mercury Marine, Fond du Lac, Wisconsin, U.S.A. Read This Manual Thoroughly IMPORTANT: If you do not understand any portion of this manual, contact your dealer.
  • Page 4 Descriptions and specifications contained herein were in effect at the time this was approved for printing. Mercury Marine, whose policies are based on continuous improvement, reserves the right to discontinue models at any time or to change specifications or designs without notice and without incurring obligation.
  • Page 5 Alpha, Avator, Axius, Bravo One, Bravo Two, Bravo Three, Circle M with Waves Logo, GO BOLDLY, K‑planes, Mariner, MerCathode, MerCruiser, Mercury, Mercury with Waves Logo, Mercury Marine, Mercury Precision Parts, Mercury Propellers, Mercury Racing, MotorGuide, OptiMax, Pro XS, Quicksilver, SeaCore, Skyhook, SmartCraft, Sport‑Jet, Verado, VesselView, Zero Effort, Zeus, #1 On...
  • Page 6   ...

  • Page 7: Table Of Contents

    General Information Identification Records..................... 1 SmartCraft Connect and the Mercury Marine App..........1 Registering the Outboard and Battery..............2 Boater's Responsibilities..................2 Start‑In‑Neutral Protection Device................ 3 Lanyard Stop Switch....................4 Hood Operation....................... 7 Protecting People in the Water................8 Passenger Safety Message ‑ Pontoon Boats and Deck Boats......9 Wave and Wake Jumping..................
  • Page 8 Installation Accessories Information..................43 Installing the Outboard..................44 Transporting Aquatic Invasive Species (AIS)................49 Trailering the Outboard..................49 Trailering for Transportation Using an Outboard Support Brace...... 51 Features and Controls Tiller Handle Features................... 53 Copilot (Steering Friction Adjustment)..............60 Single Outboard Avator Remote Control Features..........60 Adjusting Friction and Detent–Electronic Remote Control (ERC) Models..
  • Page 9 Maintenance Cleaning and Detailing..................101 Inspection and Maintenance Schedule............. 102 Corrosion Control Anode..................104 Propeller Installation and Removal..............105 Checking the Hydraulic Fluid Level in the Tilt Cylinder Fluid Reservoir ..109 Outboard Storage Protecting External Outboard Components............. 111 Winterization and Storage................. 111 Troubleshooting Fuse and Lanyard Key Replacement..............
  • Page 10 viii   ...

  • Page 11: General Information

    The installer or boatbuilder selects the propeller based on performance and boat specifications. The primary recommended propeller is a 9 inch pitch propeller. Mercury offers an 8 inch pitch, a 9 inch pitch, and a 10.5 inch pitch for the Avator 75e/110e outboards. To purchase replacement propellers contact the local Mercury Marine Authorized Dealer.

  • Page 12: Registering The Outboard And Battery

    ® to the phone over Bluetooth pairing. 3. Follow all instructions found in the Mercury Marine App for pairing the phone to the outboard. 4. SmartCraft Connect Serial Number 5. Android™ devices ‑ Navigate to the Google Play App Store™ for downloading the Mercury Marine App.

  • Page 13: Start-In-Neutral Protection Device

    GENERAL INFORMATION Start‑In‑Neutral Protection Device The tiller handle shift controller or the remote control connected to the outboard is equipped with a start‑in‑neutral only protection device. This prevents the outboard from activating when the remote control or tiller control is placed in any position other than neutral at the time it is powered ON.

  • Page 14: Lanyard Stop Switch

    GENERAL INFORMATION 78180 Neutral Lanyard Stop Switch The purpose of a lanyard stop switch is to stop the outboard when the operator moves far enough away from the operator's position (as in accidental ejection from the operator's position) to activate the switch. Tiller handle outboards and panel mounted lanyard switches provide similar functionality and will stop or prevent propeller rotation as soon as the lanyard is displaced from its installed location.
  • Page 15 GENERAL INFORMATION There is a temporary lanyard key without a lanyard cord located under the hood of the tiller model outboard. Refer to Opening and Closing the Hood. Use this in case of emergency to get back underway in the event of loss of the lanyard.
  • Page 16 While the boat is coasting, it can cause injury to anyone in the boat's path as seriously as the boat would when under power. Mercury Marine strongly recommends that other occupants be instructed on proper starting and operating procedures should they be required to operate the outboard in an emergency (if the operator is accidentally ejected).

  • Page 17: Hood Operation

    GENERAL INFORMATION KEEP THE LANYARD STOP SWITCH AND LANYARD CORD IN GOOD OPERATING CONDITION Before each use, check to ensure the lanyard stop switch works properly. Power up, and engage the outboard and stop it by pulling the lanyard cord. If the outboard does not stop, have the switch repaired before operating the boat.

  • Page 18: Protecting People In The Water

    GENERAL INFORMATION 4. Release the slotted hood lock, it should stay recessed in its locked position. Hood Slotted hood lock 78386 Protecting People in the Water WHILE BOAT IS IN OPERATION People in the water cannot take quick action to avoid a boat heading in their direction.

  • Page 19: Passenger Safety Message - Pontoon Boats And Deck Boats

    GENERAL INFORMATION WHILE THE BOAT IS STATIONARY WARNING A spinning propeller, a moving boat, or any solid device attached to the boat can cause serious injury or death to swimmers. Stop and power down the outboard immediately whenever anyone in the water is near the boat.

  • Page 20: Wave And Wake Jumping

    GENERAL INFORMATION BOATS WITH FRONT-MOUNTED, RAISED PEDESTAL FISHING SEATS Elevated fishing seats are not intended for use when the boat is traveling faster than idle or trolling speed. Sit only in seats designated for traveling at faster speeds. Any unexpected, sudden reduction in boat speed could result in the elevated passenger falling over the front of the boat.

  • Page 21: Impact With Underwater Hazards

    GENERAL INFORMATION There is another less common hazardous result from allowing the boat to launch off a wave or wake. If the bow of the boat pitches down far enough, upon water contact it may penetrate under the water surface and submarine for an instant.

  • Page 22: Outboard Secure Fastening To Transom Safety Instruction

    Operating a boat or outboard with impact damage can result in product damage, serious injury, or death. If the boat experiences any form of impact, have an authorized Mercury Marine dealer inspect and repair the boat or power package. Outboard Secure Fastening to Transom Safety Instruction No person or cargo should occupy the area directly in front of the outboard while the boat is in motion.

  • Page 23: Safe Boating Recommendations

    Know and obey all nautical rules and laws of the waterways. • Mercury Marine recommends that all powerboat operators complete a boating safety course. In the U.S., the U.S. Coast Guard Auxiliary, the Power Squadron, the Red Cross, and the state or provincial boating law enforcement agency provide courses.
  • Page 24 Federal law requires that there be a U.S. Coast Guard‑approved life jacket (personal flotation device), correctly sized and readily accessible for every person onboard, plus a throwable cushion or ring. Mercury Marine strongly advises that everyone wear a life jacket at all times while in the boat.
  • Page 25 GENERAL INFORMATION Ensure that everyone in the boat is properly seated. • Do not allow anyone to sit or ride on any part of the boat that was not intended for such use. This includes the backs of seats, gunwales, transom, bow, decks, raised fishing seats, and any rotating fishing seat.

  • Page 26: Guardian Safety Feature

    Guardian Safety Feature The outboard motor is equipped with electronic monitoring of the battery and motor for conditions affecting safe operations. Mercury Marine refers to this system as Guardian. In the event that the Guardian system detects conditions of operation outside of safe parameters it will notify the operator with an audible warning.
  • Page 27 High humidity PROPELLER The Avator propeller is installed at the time of outboard installation using boat testing to verify the correct propeller has been selected. Mercury Marine offers propeller choices for the 75e/110e outboard in the following pitches: • 8 in.

  • Page 28: Recording Serial Numbers

    1015E041E Serial Number 1Q004137 110E HP NA KW NA LB NA KG NA Mercury Marine Brunswick Corp. Fond du Lac, WI 54935 Assembled in MX from MX and foreign components. CAN ICES - 27NMB - 2 78075 Model designation Serial number Certified Europe Insignia (as applicable)   ...
  • Page 29 GENERAL INFORMATION BATTERY SERIAL NUMBERS Record the battery serial numbers for future reference. The battery serial number is located on the battery as shown. 8M0123456 8M0123456 0123456789 0123456789 77872 Model designation Serial number Certified Europe Insignia (as applicable)   ...

  • Page 30: Component Identification

    GENERAL INFORMATION Component Identification REMOTE CONTROL MODEL Hood Cowl Power cable rigging conduit Transom assembly Motor lower unit Propeller Anode Anti‑ventilation plate 78116   ...
  • Page 31 GENERAL INFORMATION TILLER MODEL 78118 Hood Display Tiller Power cables (inside of rigging sleeve) Transom assembly Motor lower unit Propeller Anode Anti‑ventilation plate Cowl   ...

  • Page 32: Specifications

    GENERAL INFORMATION Specifications Parameter Specification 7.5 kW Outboard power rating 110e 11 kW 65.3 kg (144 lb) Tiller models 66.8 kg (147.0 lb) 59.8 kg (132.0 lb) Weight Remote control 61.4 kg (136.0 lb) 75e/ models 110e 62.8 kg (139.0 lb) Battery 42.5 kg (93.7 lb) Standard...
  • Page 33 GENERAL INFORMATION ‑ 20 to 0 °C ( ‑ 4 to 32 °F) is NOTE: Charging in ambient temperatures between allowed when the battery is being actively charged only. The 5400 Wh battery contains an internal heating element that will keep the core temperature of the battery above 0 °C (32 °F) during charging.
  • Page 34 GENERAL INFORMATION Notes:   ...

  • Page 35: Battery

    Mercury Marine Authorized Dealer for warranty coverage to apply. • Only use the Mercury Avator outboard motor or battery if it is complete and in good serviceable condition. • Keep the Mercury Avator outboard motor or battery away from children.
  • Page 36 If the battery indicates a permanent fault. (Refer to Battery Faults). d. That is damaged, frozen, or overcharged. • Handle the Mercury Avator battery with care. Do not crush the Mercury Avator battery or subject it to mechanical shock. •...

  • Page 37: Battery Disposal And Recycling

    Battery Disposal and Recycling For battery disposal under warranty, contact a Mercury Marine Authorized Dealer to process the disposal through Mercury's disposal process, or be directed to dispose of it locally in accordance with regional regulations. For batteries that are being submitted for warranty through MercNET, a battery report must be generated using CDS G3.

  • Page 38: Battery Management System

    Battery Disposal and Recycling Information Area Contact Customers contact Mercury Marine Technical Service ‑ (920) 929‑5040, or the local Mercury Marine Authorized Contiguous Dealer to see if local services are available. For boatbuilders United States disposing of batteries outside of warranty, contact Mercury and Canada Marine Sales ‑...

  • Page 39: Battery Installation, Power Center Installation, Power Disconnect Switch, And Fuse Housing Mounting

    DC negative, or the bonding/grounding bus on the boat. Before operating this product, Mercury Marine strongly advises that any operator of an Avator 75e/110e outboard completely read and understand both the 5400 Wh Battery Installation and Operation Manual and the Avator 75e/110e Electric Outboard Operation and Maintenance Manual.

  • Page 40: 5400 Wh Battery Maintenance And Storage

    BATTERY • It is preferable to leave the battery charger connected to a GFCI 110‑240 VAC outlet during storage. The Avator Battery Chargers are designed with a float feature that will maintain the charge level of the battery during periods of storage. There are two methods for providing 110‑240 VAC to the battery charger during out‑of‑the‑water periods of boat storage.

  • Page 41: Battery Disconnection And Removal

    IMPORTANT: As storage periods increase in length, the temperature range of storage specification is narrowed. If temperatures are exceeded for the times shown, battery capacity will be reduced. Battery damage from improper storage is not covered under the Mercury Marine Limited Warranty for the battery. Battery Disconnection and Removal...

  • Page 42: Battery Led Status

    BATTERY STORING THE BATTERIES - REMOVED FROM THE BOAT NOTICE Damage can result to a battery exposed to temperatures above 60 °C (140 °F). Always keep the battery away from heat sources. Do not store flammable objects near the battery. If storing the batteries removed from the boat, refer to Battery Disconnection and Removal and Battery Storage, Usage, and Charging Temperature Ranges...
  • Page 43 BATTERY 2. If the battery is powered off, the LEDs will all be off. A one‑second button push will display the charge level in green LEDs, and return to the off bottom LED. 78416 3. To power the batteries ON, refer to Powering the Batteries ON. 78372 NOTE: If the batteries remain ON for a period of time during a period of time during which the outboard has not been powered up and the batteries are not...
  • Page 44 BATTERY 5400 WH BATTERY STATE OF CHARGE (SOC) STATUS Pressing the button on the battery for one second and then releasing will result in a temporary display of battery charge status for that battery only. This occurs with the battery in either the ON or OFF state. The charge level status check does not affect the power state of the battery.
  • Page 45 BATTERY Fault Action Low SOC – Empty battery Battery voltage is critically low. If the condition is not resolved by charging, contact a Mercury Marine Authorized Dealer for service. 77979 Blinking LED Over or under temperature The battery core temperature is either above or below the limits.

  • Page 46: Charging The Batteries

    BATTERY Fault Action Permanent error Contact an authorized dealer for service. Do not attempt to use or charge the battery. 77982 Blinking LEDs Charging the Batteries 1. Ensure that all batteries are ON. Refer to Powering the Batteries ON. 2. Ensure that the power disconnect switch is OFF. Refer to Powering the Batteries ON.

  • Page 47: Charger Led Status

    BATTERY IMPORTANT: For on‑water charging, Do not connect the charger’s 3‑prong grounded plug to any outlet on the shore. Do not charge the batteries with a household extension cord while the boat is on the water. 77578 7. Connect and lock the boat’s shore power receptacle to a shore power pedestal in accordance with ABYC and NFPA‑70 guidelines.

  • Page 48: Powering The Batteries On

    BATTERY LED light 1 LED light 2 Indication Behavior/Color Behavior/Color Blinking/Red Blinking/Red Battery charger faulted Off/None Off/None Not connected to the AC wall plug Powering the Batteries ON IMPORTANT:  Before powering the batteries on or off, ensure the outboard is off and the power disconnect switch is turned to OFF. Outboard or component damage can result from turning the batteries on or off while the outboard and or power disconnect switch is on.
  • Page 49 BATTERY 2. Ensure the power disconnect switch is OFF. 78169 3. Locate the power/status button on the battery. 4. Press and hold the power/status button on the battery for five seconds until the power ON LED sequence pattern starts. 78372 5.

  • Page 50: Powering The Batteries Off

    BATTERY NOTE: The outboard is ready to be powered ON. 78174 Powering the Batteries OFF IMPORTANT:  Before powering the batteries on or off, ensure the outboard is OFF and the power disconnect switch is turned to OFF. Outboard or component damage can result from turning the batteries on or off while the outboard and or power disconnect switch is on.
  • Page 51 BATTERY b. Tiller models ‑ Ensure that the outboard is OFF by viewing the display. 78408 2. Ensure that the power disconnect switch is OFF. 78169 3. Locate the power/status button on the battery. 4. Press and hold the power/status button on the battery for three seconds until the LEDs are off.
  • Page 52 BATTERY 6. Ensure that the battery is off by observing the white LED battery OFF indication. Power/status button LEDs off 78171 7. Repeat the preceding steps for each battery installed on the boat.   ...

  • Page 53: Installation

    Mercury Avator outboards. These accessories are available from Mercury Marine dealers, distributors and may be available directly from Mercury Marine. Make sure to download the Mercury Marine app to an Apple® or Android® device for specials, discounts, and rebates regarding all Avator accessories.

  • Page 54: Installing The Outboard

    MERCURY MARINE VALIDATED MOTOR MOUNTING HARDWARE IMPORTANT: Mercury Marine provides validated fasteners and installation instructions, including torque specifications, with all of Mercury outboards so they can be properly secured to boat transoms. Improper installation of the outboard can cause performance and reliability issues that can lead to safety concerns.
  • Page 55 INSTALLATION INSTALLATION SPECIFICATIONS 2763 Minimum transom opening Outboard centerline spacing Minimum Transom Opening    Single outboard (remote control models) 48.3 cm (19 in.)    Single outboard (tiller handle models) 76.2 cm (30 in.)    Dual outboards 101.6 cm (40 in.) Outboard Centerline    Minimum 66 cm (26 in.) Transom thickness range Minimum...
  • Page 56 INSTALLATION INSTALLING THE OUTBOARD ON THE BOAT TRANSOM WARNING Failure to correctly fasten the outboard could result in the outboard propelling off the boat transom resulting in property damage, serious injury, or death. Before operation, the outboard must be correctly installed with the required mounting hardware.
  • Page 57 INSTALLATION Description lb‑in. lb‑ft Outboard fasteners 13.6   ...
  • Page 58 INSTALLATION Notes:   ...

  • Page 59: Transporting

    Avator limited warranty policy. Mercury Marine recommends trailering Avator 75e/110e equipped boats with an outboard support brace. Outboard support braces are not included with this product. Refer to Trailering with an Outboard Support Brace.
  • Page 60 TRANSPORTING 1. Tiller models–To prevent damaging the tiller handle assembly from bouncing up and down during trailering, set the tiller handle to the full upright and locked position. Refer to Tiller Handle Tilt. 78121 2. For trailering the outboard without an outboard support brace (transom saver), adjust the tilt position of the outboard to a vertical operating position using: a.

  • Page 61: Trailering For Transportation Using An Outboard Support Brace

    TRANSPORTING IMPORTANT:  The full‑up tilt position is only for static storage, with the boat in the water or on the trailer. Do not launch, retrieve, or transport the boat on the trailer with the outboard in the full‑up tilt position. Trailering for Transportation Using an Outboard Support Brace Follow all instructions included with the outboard support brace for safe trailering.
  • Page 62 TRANSPORTING Notes:   ...

  • Page 63: Features And Controls

    FEATURES AND CONTROLS Tiller Handle Features TILLER HANDLE TILT IMPORTANT: To prevent damage, the tiller handle must be raised and locked into a 78 degree position for trailering. Do not attempt to carry or lift the outboard by the tiller handle. 78151 78 degree position TILLER SHIFT LEVER...
  • Page 64 FEATURES AND CONTROLS Reverse movement ‑ Move the shift lever direction all the way to the • reverse stop. 78295 Reverse Neutral Forward TILLER LOCK RELEASE LEVER Rotate the tiller lock release levers in the aft or forward direction to allow the tiller handle to be raised or lowered.
  • Page 65 FEATURES AND CONTROLS TILLER HANDLE YAW The tiller handle yaw allows the operator to change the side to side angle of the handle in small increments and lock it in for operation of the tiller with the arm positioned either left or right of center. 78157 TILLER HANDLE YAW RELEASE 1.
  • Page 66 FEATURES AND CONTROLS 5. Verify the lever is locked into position. 78165 LANYARD STOP SWITCH Refer to Lanyard Stop Switch. 78153   ...
  • Page 67 FEATURES AND CONTROLS A spare lanyard stop switch clip is stored under the hood. 78366 Front THROTTLE ROTATION SLIDE SELECTOR IMPORTANT: Until the operator is familiar with the characteristics and features of this tiller handle control, it is strongly suggested to initially test‑operate the boat in a safe area.
  • Page 68 FEATURES AND CONTROLS Press the throttle rotation selector slide all the way to the left or the right until it stops. Throttle rotation selector slide (counterclockwise) Throttle rotation slide selector (clockwise) Neutral 78136 THROTTLE GRIP Controls the outboard speed. 1. Align the throttle grip with the neutral detent on the tiller handle when starting or before shifting into the forward or reverse gear position.
  • Page 69 FEATURES AND CONTROLS THROTTLE FRICTION KNOB 78155 TILLER HANDLE HEIGHT ADJUSTMENT SCREW With the tiller in the horizontal operating position, the height of the tiller can be adjusted in small increments. 1. Lift the tiller handle up slightly to access the tiller handle height adjustment screw.

  • Page 70: Copilot (Steering Friction Adjustment)

    FEATURES AND CONTROLS Raise the tilt position ‑ Push the toggle switch down. • 78166 Copilot (Steering Friction Adjustment) The copilot knob provides a steering friction adjustment for user preference. The copilot knob is used to help hold the tiller steering lever in place with minimal operator effort if the friction level is turned to the maximum position.

  • Page 71: Adjusting Friction And Detent-Electronic Remote Control (Erc) Models

    FEATURES AND CONTROLS Neutral lock bar ‑ Squeeze the neutral lock bar to allow the control • handle to move in forward or reverse directions. When the control handle is returned to neutral, the neutral lock bar will engage again, to prevent inadvertent travel of the remote control handle.
  • Page 72 FEATURES AND CONTROLS 1. Carefully pry the access cover from the ERC body. 78413 2. Adjust the handle friction and detent as required with the adjustment screws on the ERC. Friction adjustment screw Detent adjustment screw 75977 3. When adjustments are complete, install the back cover on the ERC. a.
  • Page 73 FEATURES AND CONTROLS c. Pivot the access cover downward to snap into place. 75978 Hooks on the access cover Slide hooks into the ERC body Pivot the access cover downward to snap into place ADJUSTING FRICTION AND DETENT ON AVATOR PANEL MOUNT ERC Recommended Tools •...
  • Page 74 FEATURES AND CONTROLS 1. Carefully pry the access cover from the ERC body. 76016 75957   ...
  • Page 75 FEATURES AND CONTROLS 2. Adjust the handle friction and detent as required with the adjustment screws on the ERC. Detent adjustment screw Friction adjustment screw 76015 Friction adjustment screw Detent adjustment screw 75956 3. When adjustments are complete, snap the ERC cover into place on the ERC.

  • Page 76: Helm-Mounted Lanyard Stop Switch

    FEATURES AND CONTROLS Helm‑Mounted Lanyard Stop Switch The helm‑mounted lanyard stop switch shuts the outboard off when the operator moves away from the boat controls, beyond the range of the lanyard cord. Refer to Lanyard Stop Switch. 75536 Power Tilt System INTRODUCTION TO THE POWER TILT SYSTEM The Avator outboard power tilt system allows the operator to adjust the tilt position of the outboard within the tilt operating ranges when the speed of...
  • Page 77 FEATURES AND CONTROLS USING THE POWER TILT 1. Place the outboard in neutral and reduce the speed below 8 km/h (5 mph) 2. Allow the speed of the boat through the water to stabilize or stop. 3. Press and hold the tilt switch: •...
  • Page 78 FEATURES AND CONTROLS 2. Stay clear of the outboard including the propeller before and while operating the tilt switch. CAUTION Avoid injury due to pinch hazards. Do not place any body parts between the outboard and the boat while operating the tilt switch. Stay clear and be observant of the outboard components while using the cowl mounted tilt switch.
  • Page 79 FEATURES AND CONTROLS b. Remote control models ‑ On the remote control 78167 c. All models ‑ On the starboard cowl panel 78168 2. Push and twist the tilt lock knob clockwise. 78409   ...
  • Page 80 FEATURES AND CONTROLS 3. Pull out on tilt lock knob to seat the lever into the recess of the transom bracket. 4. Use the power tilt switch to tilt the outboard down until the tilt bracket rests on the lever. 78410 Tilt bracket Recess of the transom bracket...
  • Page 81 FEATURES AND CONTROLS b. Remote control models ‑ On the remote control 78167 c. All models ‑ On the starboard cowl panel 78168 2. Push in and rotate the tilt lock knob counterclockwise until it hits the travel stop.   ...
  • Page 82 FEATURES AND CONTROLS 3. Release the tilt lock knob so that it will recess back into the unlocked position. 78411 4. Tilt the outboard down to desired position. TRIM TAB (CORROSION CONTROL ANODE) ADJUSTMENT The trim tab for the Avator 75e/110e outboards is also a corrosion control anode.
  • Page 83 FEATURES AND CONTROLS d. Turn the power disconnect switch to the OFF position. 78169 e. Loosen the trim tab bolt and make small adjustments at a time. 78420 f. Securely tighten the trim tab bolt. g. Disengage the tilt lock. Refer to Tilt Lock. IMPORTANT: Use caution when working around the propeller.
  • Page 84 FEATURES AND CONTROLS h. Turn the power disconnect switch to the ON position. 78174 i. Lower the tilt position, launch the boat and test for correction of the propeller steering torque. 4. If the boat steers toward the left, set the trim tab in the direction of b. 5.

  • Page 85: Warning Horn

    FEATURES AND CONTROLS SHALLOW WATER OPERATION When operating the boat in shallow water, the outboard should be raised to the highest tilt position angle necessary to clear all underwater obstacles. Operate the outboard below 8.04 km/h (5 mph) while tilted up for shallow water operation.

  • Page 86: Display Icon Legend

    FEATURES AND CONTROLS CAUTION If a caution state is detected, the audio warning system will sound for six one‑second intervals. 33402 Horn (on or off) Time (in seconds) CRITICAL If a critical state is detected, the audio warning system will sound for six seconds and then turn off.
  • Page 87 FEATURES AND CONTROLS Icon Description Time remaining 76106 Speed 76108 Power (kW) 76109 Distance remaining 76110 Settings 76111 Brightness 76112 Depth 76113 Throttle direction 76114 ALARM/WARNING Icon Description Active fault 76115   ...
  • Page 88 FEATURES AND CONTROLS Icon Description GPS fault 76116 Attach lanyard 76117 Temperature fault 76118 Propulsion fault 76119 Battery fault 76120 Charge icon 76121 CHARGE Charge text 76122 Low battery icon 76123 LOW BATTERY Low battery text 76124 Left alarm chevron 76125   ...
  • Page 89 FEATURES AND CONTROLS Icon Description Right alarm chevron 76126 ACTIVE FEATURE Icon Description TROLL Troll active 76127 POSITIVE STATES Icon Description Charge icon 76128 SAVED Settings Saved text 76129 READY Ready state (neutral) 76130 UNITS/NUMBERS/LABELS Icon Description ALARM Alarm text 76131 TYPE Type in alarm type...
  • Page 90 FEATURES AND CONTROLS Icon Description CODE Code in alarm code 76138 POWER Power (kW) 76139 Estimated text (estimated time to charge, ESTIMATED estimated range) 76140 RANGE Range text (distance to discharged) 76141 km/h Kilometers per hour 76143 Miles per hour 76144 % (percent) 76146...
  • Page 91 FEATURES AND CONTROLS BATTERY INDICATION Icon Description Battery scale 76149   ...
  • Page 92 FEATURES AND CONTROLS Notes:   ...

  • Page 93: Operation

    OPERATION Prestarting Checklist • The operator knows safe navigation, boating, and operating procedures. • An approved personal flotation device of suitable size is available for each person aboard. • A ring type life buoy or buoyant cushion designed to be thrown to a person in the water.

  • Page 94: Tiller Models

    OPERATION Tiller Models POWERING ON THE OUTBOARD–TILLER MODELS 1. Inspect the outboard and check the following items: a. The battery or batteries are On. Refer to Powering the Batteries ON. b. The power disconnect switch is in the ON position for powering on the outboard.
  • Page 95 OPERATION NOTE: The display will show the current battery percent. READY 74745 OPERATING THE OUTBOARD - TILLER MODELS Before starting, refer to the Prestarting Checklist and Prestarting Instructions. 1. Verify the tiller shift lever is in the neutral position. 78180 Neutral 2.
  • Page 96 OPERATION 5. To initiate propeller rotational thrust, place the tiller shift lever in the forward or reverse gear position. 78183 Reverse (R) Forward (F) 6. To increase the thrust of the outboard, twist the tiller handle grip either to the left or right. NOTE: Throttle direction configuration can be changed depending on operator ‑...
  • Page 97 OPERATION NOTE: The current unit of measure setpoint will flash. 74755 2. Use the left or right arrow button to select the type of units to be displayed. Left arrow button Right arrow button km/h 74756   ...
  • Page 98 OPERATION 3. Press the menu button to save the setting. km/h SAVED 74757 NOTE: Setup is complete. The display will revert back to the main screen. POWERING OFF THE OUTBOARD–TILLER MODELS 1. Press and hold the power button until the rotating "power down" animation stops and disappears.

  • Page 99: Remote Control Models

    OPERATION Remote Control Models POWERING ON THE OUTBOARD–REMOTE CONTROL MODELS Verify that: • The battery or batteries are ON. Refer to Powering the batteries ON. • The power disconnect switch is in the ON position. • The lanyard stop switch is present, slides in and out of position, and that the cord is in good condition.
  • Page 100 OPERATION 3. Turn the key to the ON position. 74947 Key in ON position 4. Check the display that there are no active faults or conditions that may cause active faults. 5. Check the safety and positioning of passengers before operating the outboard.
  • Page 101 OPERATION DUAL-HANDLE ELECTRONIC REMOTE CONTROL (ERC)—OPERATION AND ADJUSTMENT Operation The electronic remote control (ERC) handle controls the shift and throttle operation. Push the control handle forward from neutral to the first detent for forward gear. Continue pushing the handle forward to increase speed. Pull the control handle from the forward position to the neutral position to decrease speed and eventually stop.
  • Page 102 OPERATION 3. Adjust to the tension desired. 71978 Access cover Detent adjustment screws Handle friction adjustment screws SPECIAL DIGITAL THROTTLE AND SHIFT (DTS) FEATURES The dual outboard ERC system features several alternate operational modes for the electronic remote control (ERC) levers. Not all features are applicable to Avator.
  • Page 103 OPERATION Description of Controls 78565 Control/LED Function Illuminate when the outboard is in the neutral Neutral (N) LEDs (one on gear position. The lights flash when the each handle) outboard is in throttle‑only mode. Not applicable for Avator Outboards. Refer to Brightness (+ and –) Display Settings for adjusting the brightness.
  • Page 104 OPERATION Control/LED Function Raises and lowers the outboards, at idle speeds or below, for best efficiency or for UP ▲ and DN ▼—tilt conditions such as shallow water or trailering. control (if equipped) NOTE: Tilt switches for the individual outboards are located on the front (bow side) of the ERC. NOTE: Not all functions may be active.
  • Page 105 OPERATION 4. When the handle is moved, the outboard propeller speed and gear position is synchronized. To disengage 1 Lever mode: 1. Place both ERC levers in neutral. 2. Press the 1 LEVER button. The button light turns off. OUTBOARD SETTINGS - REMOTE CONTROL MODELS 1.
  • Page 106 OPERATION 2. Press the left or right arrow button to select the type of units to be displayed. 76168 Current unit of measure Right arrow button Left arrow button 3. Press the menu button to save the setting. km/h SA VED 76169   ...
  • Page 107 OPERATION NOTE: Setup is complete. The display will revert back to the main screen. READY READY 76170 POWERING OFF THE OUTBOARD–REMOTE CONTROL MODELS Power Off Turn the key to the OFF position. 74946 DECOMMISSIONING THE OUTBOARD 1. If the boat is to be left unattended, turn the power disconnect switch to OFF.

  • Page 108: Using And Changing Directional Controls

    OPERATION 3. For storage when the batteries are to be charged by the battery charger, turn the batteries to ON. RECOMMISSIONING THE OUTBOARD • Ensure the batteries are turned ON. Refer to Powering the batteries ON. • Ensure the power disconnect switch is turned ON. •...
  • Page 109 OPERATION Tiller handle models ‑ Three directional control positions provide boat • operation: forward (F), neutral (N), and reverse (R). When changing directional control, always stop at the neutral position and allow the propeller to stop turning. 78295 Forward (F) Neutral (N) Reverse (R) Remote control models ‑...

  • Page 110: Recommended Operating Temperature Ranges For The Avator 75E/110E Outboards

    Wash the outboard exterior with fresh water after each use. Each month, spray Mercury Precision or Quicksilver Corrosion Guard on external metal surfaces. Do not spray on corrosion control anodes as this will reduce the effectiveness of the anodes.

  • Page 111: Cleaning And Detailing

    To keep the outboard in the best operating condition, it is important that the outboard receive the periodic inspections and maintenance listed in the Inspection and Maintenance Schedule. Mercury Marine urges the operator to keep it maintained properly to ensure that the safety of the operator and the passengers, and retain its dependability.

  • Page 112: Inspection And Maintenance Schedule

    Wash off any salt buildup from the under cowl components with fresh water. After washing, allow the under cowl components to dry. Apply Quicksilver or Mercury Precision Lubricants Corrosion Guard spray on the external metal surfaces of the under cowl components.
  • Page 113 Charge the batteries fully before long‑term storage and every six months. Check the hydraulic fluid level in the tilt cylinder fluid reservoir. Add Mercury Power Trim and Steering fluid to the reservoir if it is not full. Verify the condition and LED status of the battery charger.

  • Page 114: Corrosion Control Anode

    4. Replace the propeller if there are signs of hub damage. IMPORTANT: Do not apply grease to the threads of the shaft. 5. Apply Mercury 2‑4‑C Marine Grease to the propeller shaft where the propeller contacts the shaft. 3 Year Maintenance Dealer (Every 3 years in storage or in use.

  • Page 115: Propeller Installation And Removal

    MAINTENANCE • Before it is completely eroded. • If the surface of the anode is rough. • If the fin of the trim tab portion of the anode is shorter than 6 cm (2.3 in.). 78197 Propeller Installation and Removal PROPELLER INSTALLATION WARNING Rotating propellers can cause serious injury or death.
  • Page 116 MAINTENANCE 2. Turn the power disconnect switch to OFF. 78169 3. Apply a coat of the recommended lubricant to the non‑threaded areas of the propeller shaft. IMPORTANT: Do not apply Extreme Grease or 2‑4‑C with PTFE to the threads of the propeller shaft. Description Where Used Part No.
  • Page 117 MAINTENANCE 4. Install the thrust washer onto the propeller shaft by sliding it all the way forward on the shaft until it stops. 5. Install the propeller onto the propeller shaft by sliding it forward up against the thrust washer. IMPORTANT: The propeller blades are sharp.
  • Page 118 MAINTENANCE IMPORTANT: Do not use an impact or power tool to remove the propeller nut from the propeller shaft. Do not attempt to hold the blade with a bare hand. When removing the propeller nut, a soft block such as plastic or wood can be used between the anti‑cavitation plate and a propeller blade to hold the propeller from rotating.

  • Page 119: Checking The Hydraulic Fluid Level In The Tilt Cylinder Fluid Reservoir

    2. Use a cotton swab or suitable sized object to verify that the level of hydraulic fluid is even with the bottom of the filler hole. 3. If required, add Mercury Power Trim & Steering fluid until the level of fluid is even with the bottom of the filler hole.
  • Page 120 MAINTENANCE Notes:   ...

  • Page 121: Outboard Storage

    • Touch‑up any paint nicks. See the local dealer for touch‑up paint. • Spray Quicksilver or Mercury Precision Lubricants Corrosion Guard on external metal surfaces (except corrosion control anodes). IMPORTANT: Do not apply corrosion guard to the exposed terminals of the battery connection.
  • Page 122 OUTBOARD STORAGE Notes:   ...

  • Page 123: Troubleshooting

    TROUBLESHOOTING Fuse and Lanyard Key Replacement FUSE LOCATION The outboard 12‑volt, 5‑amp fuse is located under the hood. 78220 5‑amp fuse Spare fuse Spare lanyard key FUSE IDENTIFICATION AND REPLACEMENT IMPORTANT:  Always carry spare ATC or ATO 5‑amp, 12‑volt fuses. Do not attempt to service the 48‑volt circuit fuse.

  • Page 124: Outboard Will Not Power Up

    TROUBLESHOOTING Qualified and trained personnel only: Use only compatible fuses (amperage and voltage) to replace serviceable fuses inside the Power Center: • Battery charger fuse: MINI 30‑amp, 58 VDC • Battery charger fuse: M10 Zcase 60‑amp, 58 VDC • Power fuse: M10 Zcase 150‑amp, 58 VDC •...

  • Page 125: Performance Loss

    Check operation for free travel and ensure Tiller control throttle or that there are no faults. If any faults occur, remote control throttle not the outboard must be serviced by a Mercury working correctly. Authorized Dealer. Damaged or improper size Refer to Specifications or Propeller Installation propeller.

  • Page 126: Battery Will Not Charge With Charger

    Possible Causes Recommended Maintenance IMPORTANT:  Do not use any charger except Charger not compatible Mercury Avator specific chargers. Aftermarket with Avator outboard. chargers may damage the battery. Ensure full engagement of the AC outlet to the The charger is either charger.

  • Page 127: Operator Service Assistance

    OPERATOR SERVICE ASSISTANCE Service Assistance LOCAL REPAIR SERVICE If service is needed for the Mercury outboard powered boat, take it to an authorized dealer. Only authorized dealers specialize in Mercury products and have factory‑trained technicians, special tools and equipment, and genuine Mercury Avator parts and accessories to properly service the outboard.
  • Page 128 RESOLVING A PROBLEM Satisfaction with the Mercury product is important to the dealer and to Mercury Marine. If there is ever a problem, question, or concern about the power package, contact the dealer or any authorized Mercury dealership. If additional assistance is needed: 1.

  • Page 129: Handling Damaged, Defective, Or Submerged Products

    If a battery is suspected of having been compromised, contact a Mercury Marine Authorized Dealer as soon as possible. Do not store the affected battery indoors, in a vehicle, or near any flammable materials.

  • Page 130: Ordering Literature

    Use extreme caution if transporting a battery that has been submerged. Do not store a battery that has been submerged indoors, in a vehicle, or near any other combustible materials. Contact a Mercury Marine Authorized Dealer for further instructions before transporting the battery. If...
  • Page 131 (920) 929‑4894 P.O. Box 1939 Fond du Lac, WI 54936-1939 OUTSIDE THE UNITED STATES AND CANADA Contact the nearest Mercury Marine authorized service center to order additional literature that is available for the particular power package. Mercury Marine Submit the following...
  • Page 132 OPERATOR SERVICE ASSISTANCE Notes:   ...

  • Page 133: Maintenance Log

    MAINTENANCE LOG Maintenance Log Record all maintenance performed on the outboard here. Be sure to save all work orders and receipts. Date Maintenance Performed Outboard Hours                               ...
  • Page 134 MAINTENANCE LOG Notes:   ...

  • Page 135: Predelivery Inspection (Pdi)

    PREDELIVERY INSPECTION (PDI) Predelivery Inspection (PDI) OUTBOARD INFORMATION Outboard Information Outboard kilowatt rating/Mercury Avator power rating Outboard serial number ‑ ‑ Battery serial number(s) ‑ ‑ Propeller size Boat brand Boat model Boat length TECHNICIAN INFORMATION I certify that the following checks and inspections have been completed.
  • Page 136 PREDELIVERY INSPECTION (PDI) Tighten the propeller nut to the specified torque. Refer to Propeller Installation. SOFTWARE AND DISPLAY Verified that the display is functional? Battery state of charge (SOC) levels report correctly and accurately on display. Verify all audible and displayed warning systems operate as designed. OUTBOARD STEERING - TILLER MODELS Tiller throttle directional operation can be changed using the throttle direction selector slide.
  • Page 137 PREDELIVERY INSPECTION (PDI) HELM RIGGING (IF EQUIPPED) Accessible 10‑pin diagnostic port (if applicable). The rigging in the helm is organized. Proper component installation orientation. Proper wiring retention and strain relief in place. All power cables, battery CAN cables, and 14‑pin data cables are rigged with drip loops after each connection point, to prevent water intrusion.
  • Page 138 Submit full report with PDI. Completion date. Clear all Freeze Frames and save a full report. Submit a full report with faults and history cleared to Mercury Technical Service and list email address. CUSTOMER DELIVERY Daily inspections/maintenance/documentation included with the boat.
  • Page 139 PREDELIVERY INSPECTION (PDI) Provided and reviewed battery charging recommendations including storage temperature requirements. Explained the Mercury Avator App (if equipped). Tiller models only, demonstrated and explained how to reverse the tiller handle rotation left to right. HELM Explain and review display features: Range, distance to empty.
  • Page 140 PREDELIVERY INSPECTION (PDI) Salesperson Date   ...
