- Page 1 QUICK INSTALLATION GUIDE SMILE-BAT-5P...
- Page 2 Introduction Suitability This document is only valid for the following systems: 1. SMILE-B3 PLUS 2. SMILE-B5 3. SMILE-S3.6 4. SMILE-S5 5. SMILE-S6 The above systems are collectively referred to as the Energy System in this document.
-
Page 3: Packing List
Packing list SMILE-BAT-5P Positive Power Cable (X1) Communication Cable (X1) Side Cover (X1) Battery Wall Bracket (X1) Negative Power Cable (X1) Screw M6*16 (X4) M4 Flange Expansion Bracket (X2) Wall Anchor ST6*55 (X8) Screw M5*12 (X1) (X13, 2 for spare) - Page 4 Mounting the Expansion Batteries Step1 Step2 Take out the battery from the packing box. Take out the expansion brackets and the battery wall bracket, then fix them together with four 4*M4 flange nuts (tools: Socket wrench SW7, torque: 1.6 Nm). Expansion bracket Battery wall bracket Step3...
- Page 5 Step5 Drill 6 holes on the wall with Φ10mm drill, insert 6 screw anchors into the drill holes. ∅ 10mm 70mm Step6 Use four M4 flange nuts to fix the wall bracket assembled in the step 2 to the wall bracket of top battery again (tools: Socket wrench SW7, torque: 1.6 Nm).
- Page 6 Step7 Attach the expansion bracket to the wall by tightening the screws with SW10 hexagon sleeve. Step8 Hold the handles on both sides of the battery pack and install the battery pack on the wall bracket. At least, two people are required for this step.
- Page 7 Step9 Tighten the wall bracket and the battery pack with screw M6*16 (X4) (tool: T20 screwdriver, torque: 3.0 Nm). 4 Nm The following have to be noticed before connection: DANGER WARNING Before connecting cables, ensure that all breakers of the inverter and •...
- Page 8 Step10 Remove the rubber plugs from the top battery, and remove the screws on the cover of batteries with T20 screwdriver. Step11 Remove the cable cover by unscrewing the screws at the top of the inverter and perform electrical connection work.
-
Page 9: Electrical Connection
Electrical Connection Overview of the Connection Area Position Position Designation Battery breaker of battery pack Power button of battery pack BAT+ connection port BAT- connection port BMS communication connectors Connection point for an additional grounding... - Page 10 Step12 Connecting Additional Grounding a）Prepare M5 OT terminals, strip the grounding cable insulation and insert the stripped part of the grounding cable into the ring terminal lug and crimp it. b）Connect the expanded battery to the ground point of the energy system with the grounding cable. M5*10 Screw 2.5 N·M...
- Page 11 Step 13 Remove the terminal resistance from the battery and plug it into the BMS communication port of the last installed battery (the battery furthest from the inverter). Last battery...
- Page 12 Step14 Connect the positive power cable from battery 2 to battery 1 (tool: T20 screwdriver, torque: 3 Nm). Battery 1 Battery 2 4 Nm...
- Page 13 Step15 Connect the negative power cable from battery 2 to battery 1 (tool: T20 screwdriver, torque: 3 Nm). Battery 1 Battery 2 4 Nm...
- Page 14 Step16 Connect the BMS communication cable from battery 2 to battery 1. RJ45 connector RJ45 connector Battery 1 Orange/White Orange/White Orange Orange Green/White Green/White Blue Blue Blue/White Blue/White Green Green Brown/White Brown/White Brown Brown Battery 2 RS568B线序 NOTE Power cables and communication cables are needed to be made by installers if the expanded batteries are not installed downward. 1.The sequence standard of the communication cable is RS568B.
- Page 15 Step17 Assemble front cover and side cover of the expanded battery with 3*M4 flange nuts (tools: Socket wrench SW7, torque: 1.6 Nm). Step18 Attach the cover to the battery pack. Fasten the cover on the battery with screws in sequence 1-7 with screw M5*12 (X4) (tool: T20 screwdriver, torque: 2.5 Nm).
- Page 16 Step19 Insert the rubber plugs of the batteries.
-
Page 17: Checking Before Power-On
Commissioning Step20 1.Checking Before Power-On Check Item Acceptance Criteria The mounting space is proper, and the mounting environment is clean and tidy, without Mounting environment any foreign object. Battery pack and inverter The battery pack and inverter are mounted correctly, securely and reliably. mounting WiFi installation The WiFi module is installed correctly, securely, and reliably. - Page 18 Step21 2. Check the Running State Short press the power button on the right side of battery pack and switch on the battery breaker on the battery pack, then the LED light is on. Switch on the battery breaker of the inverter. Switch on the external AC breaker between the grid and the inverter.
-
Page 19: Battery Technical Data
Usable Capacity 4.79 kWh Protection Class Ⅰ Operating Temperature -10℃ ~50℃ Enclosure IP65 IFpP37/131/201/ Battery Designation [P15S]M/-10+50/95 Alpha ESS Co., Ltd. TEL:+86(0) 513 806 068 91 EMAIL:info@alpha-ess.com ADD:JiuHua Road 888, Nantong High-Tech Industrial Development Zone, Nantong City, 226300 Mdde in China... - Page 20 @AlphaEnergyStorageSystem @AlphaESS @alpha_ess @AlphaESS Alpha ESS Co., Ltd. Alpha ESS Suzhou Co., Ltd. Alpha ESS Australia Pty. Ltd. +86 513 8060 6891 +86 512 6828 7609 +61 402 500 520 (Sales) info@alpha-ess.com info@alpha-ess.com +61 1300 968 933 (Technical Support) www.alpha-ess.com...
