- Page 1 Siberian™ Mini Glycol Chiller 230V / 50Hz Installation, Operation & Service Manual lancerbeverage.com...
-
Page 2: Table Of Contents
Certificate of Warranty ....................... 17 Manufacturer’s Checklist ....................18 www.lancerbeverage.com Page 2 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 3: Specifications And Features
Max total head per the following pump configurations: SPK 2-11 50 metres www.lancerbeverage.com Page 3 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 4: Options
Page 4 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 5: Service & Maintenance
• Unit is for indoor use only unless suitably protected by a weatherproof enclosure. • The Hoshizaki Lancer Siberian system chiller should be located in a well-ventilated area that will allow easy access for servicing. • Install on a flat, level surface. Chiller can be wall mounted in a cool room of minimum height 2.1m if the suitable part number is purchased. -
Page 6: Wall Mounting
The wall mounting kit for 31002004 SIBERIAN MINI 404A-211-WM and 31002006 SIBERIAN MINI 134A- 211-WM consists of www.lancerbeverage.com Page 6 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 7: Refrigeration Connection
Page 7 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. -
Page 8: Connecting Glycol Lines
(for submersible pumps and vertical wet pit pumps containing lubricants) 3.6 Connecting Glycol Lines • Connect glycol lines from the manifolds to the Hoshizaki Siberian system chiller. • Supply manifold direct to pump(s). • Return manifold to glycol return pipe via return solenoid if required. -
Page 9: Commissioning
The Hoshizaki Lancer Siberian system chiller requires a 30% glycol / water mixture (see concentration chart on page 11 for details). Put 12 litres of glycol in the tank and fill with water until the glycol / water mixture reaches the overflow. -
Page 10: Thermostat- Carel Pjeasy - Thermostat Parameters
All other non used parameters are hidden to avoid confusion. www.lancerbeverage.com Page 10 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 11: Programming Instructions
Antifreeze alarm can be reset by holding “UP” and “DOWN” keys for 5 seconds. www.lancerbeverage.com Page 11 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 12: Scheduled Maintenance
/ water mix Target Concentration www.lancerbeverage.com Page 12 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 13: Trouble Shooting
System leak Low glycol % Add glycol www.lancerbeverage.com Page 13 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 14: Electrical Diagram - Carel Thermostat
Siberian Mini Glycol Chiller 7. Electrical Diagram – Carel Thermostat www.lancerbeverage.com Page 14 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 15: Wiring Diagram - Carel Thermostat
Siberian Mini Glycol Chiller 8. Wiring Diagram – Carel Thermostat www.lancerbeverage.com Page 15 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 16: Spare Parts List
IEC Lead FEM 1200mm 83000308 IEC Lead MALE 300mm www.lancerbeverage.com Page 16 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022... -
Page 17: Certificate Of Warranty
Siberian Mini Glycol Chiller 10. Certificate of Warranty It is the policy of Hoshizaki to provide to its current customers, warranty for all equipment supplied and installation work performed within a specified period. Parts and Equipment Lancer provides a warranty period of twelve (12) months from the date of original invoice for all manufactured parts. -
Page 18: Manufacturer's Checklist
Work Order No: ................Affix label here www.lancerbeverage.com Page 18 of 18 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000218 Images are for illustration purposes only as product may vary. No 109-2 29 Sept 2022...
