- Page 1 S4E V3 Hi-Carb Superchiller 240V / 50Hz Installation, Operation & Service Manual lancerbeverage.com...
-
Page 2: Table Of Contents
Certificate of Warranty ....................... 28 Manufacturer’s Checklist ....................29 www.lancerbeverage.com Page 2 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 3: Introduction
2. The Company Hoshizaki Lancer is a wholly owned subsidiary of Lancer Corporation, a world leader in the supply of Beverage Dispensing Equipment based in San Antonio, Texas. Lancer has manufacturing bases and distribution networks in 97 countries. -
Page 4: Product Details
Adjustable legs (79232218) Height with legs approx. 805mm Casters (79602411) Height with casters 765mm www.lancerbeverage.com Page 4 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 5: Superchiller Safety Information
Page 5 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 6: Service & Maintenance
If damage exists, have carrier note damage on bill of landing and file a claim with the carrier. www.lancerbeverage.com Page 6 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 7: Unpacking
Supporting structure must be securely fixed to floors or walls. www.lancerbeverage.com Page 7 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 8: Connecting Python
(i.e. double pass of soda circuit out and back from dispense point to soda return). www.lancerbeverage.com Page 8 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. -
Page 9: Connecting To Water Supply
When filling the water tank, care must be taken to not splash Warning water onto the electrical components www.lancerbeverage.com Page 9 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 10: Electrical Connection
(where applicable), and syrup pours from each dispenser. www.lancerbeverage.com Page 10 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. -
Page 11: Scheduled Maintenance
Page 11 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... - Page 12 Remove sanitising fittings from BIB disconnects and re-connect disconnects to appropriate BIB's. Operate dispensing valves until syrup flows freely. www.lancerbeverage.com Page 12 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020...
-
Page 13: Postmix Circuit Diagram
8. Postmix Circuit Diagram 8.1. 3 PUMP UNIT www.lancerbeverage.com Page 13 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... - Page 14 S4E V3 Hi-Carb Superchiller 240V / 50Hz 8.2. 2 PUMP UNIT www.lancerbeverage.com Page 14 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020...
-
Page 15: Electrical Circuit Diagram S4E V3
S4E V3 Hi-Carb Superchiller 240V / 50Hz 9. Electrical Circuit Diagram S4E V3 www.lancerbeverage.com Page 15 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 16: Control Board Connections And Jumper Settings
S4E V3 Hi-Carb Superchiller 240V / 50Hz 10. Control Board Connections and Jumper Settings www.lancerbeverage.com Page 16 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 17: Airflow Diagram
S4E V3 Hi-Carb Superchiller 240V / 50Hz 11. Airflow Diagram www.lancerbeverage.com Page 17 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 18: Trouble Shooting
Diagnostic tool. LED lights up when contact closed on adjacent relay. LEDS (ON PC BOARD) www.lancerbeverage.com Page 18 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... - Page 19 20. Replace control or probe if defective. www.lancerbeverage.com Page 19 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020...
- Page 20 Pump leaks from shaft Worn pump seals. Replace pump. seal. www.lancerbeverage.com Page 20 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020...
- Page 21 It should be set at 550 kPa. www.lancerbeverage.com Page 21 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020...
-
Page 22: Omni Icebank Control Test
(Simulates ice growth over the probes) www.lancerbeverage.com Page 22 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 23: Omni Carbonator Level Control Test
(i.e. Water level drops below low level probe) www.lancerbeverage.com Page 23 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 24: Assembly Diagrams & Parts List
‘V’ BAND CLAMP 800000105 POSTMIX MOTOR MAG IEC PLUG www.lancerbeverage.com Page 24 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 25: Postmix Assembly Diagram
S4E V3 Hi-Carb Superchiller 240V / 50Hz 15.2. Postmix Assembly Diagram www.lancerbeverage.com Page 25 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 26: Refrigeration Parts List
COMPRESSOR DANFOSS GS34MFX 83000282 COMPRESSOR START RELAY & CAPACITORS www.lancerbeverage.com Page 26 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 27: Refrigeration Assembly Diagram
S4E V3 Hi-Carb Superchiller 240V / 50Hz 15.4. Refrigeration Assembly Diagram www.lancerbeverage.com Page 27 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020... -
Page 28: Certificate Of Warranty
S4E V3 Hi-Carb Superchiller 240V / 50Hz 16. Certificate of Warranty It is the policy of Hoshizaki to provide to its current customers, warranty for all equipment supplied and installation work performed within a specified period. Parts and Equipment Lancer provides a warranty period of twelve (12) months from the date of original invoice for all manufactured parts and the associated labour. -
Page 29: Manufacturer's Checklist
Copy checklist & file, put manual/checklist and pump insulator kit in plastic bag & place in the tank area. Customer asset No. W/O ............... www.lancerbeverage.com Page 29 of 29 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000002 Images are for illustration purposes only as product may vary. 036-5 12 March 2020...
