- Page 1 Glycoolpac 27hx Self Contained Glycol Chiller Installation, Operation & Service Manual www.lancerbeverage.com...
-
Page 2: Table Of Contents
12. Certificate of Warranty ....................20 13. Manufacturer’s Checklist ....................21 www.lancerbeverage.com Page 2 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 3: Introduction
2. The Company Hoshizaki Lancer is a wholly owned subsidiary of Lancer Corporation, a world leader in the supply of Beverage Dispensing Equipment based in San Antonio, Texas. Lancer has manufacturing bases and distribution networks in 97 countries. -
Page 4: Product Details
Glycoolpac 27hx Manual 4. Product Details 4.1 Product Features The Lancer Glycoolpac 27hx chiller is supplied with the following features as standard: Advanced high efficiency heat exchanger technology uses 45% less refrigerant than previous coil models. Digital Thermostat with 1-button energy saving ECO Mode off-peak temperature setting. -
Page 5: Specifications
Capacity (kW @ -10°C SST) 2.7 kW www.lancerbeverage.com Page 5 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 6: Safety Information
Children should be supervised to ensure that they do not play with the appliance. www.lancerbeverage.com Page 6 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 7: Service
ELECTRICAL SUPPLY BEFORE COMMENCING MAINTENANCE OR SERVICE. www.lancerbeverage.com Page 7 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 8: Installation
Page 8 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 9: Connecting Glycol Lines And Glycol Tank Overflow
Additional premixed 30% glycol / water solution will be required for commissioning. www.lancerbeverage.com Page 9 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. -
Page 10: Connecting To Electrical Power
Check all connections for leaks www.lancerbeverage.com Page 10 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 11: Control Settings
Press and Hold “DOWN” button for approximately 5 seconds. www.lancerbeverage.com Page 11 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 12: Alarm Signals
*Factory programmed to Hoshizaki Lancer Specifications. www.lancerbeverage.com Page 12 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 13: Monthly Maintenance
When using compressed air- always wear protective eye wear. www.lancerbeverage.com Page 13 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 14: Trouble Shooting
Replace thermostat or contactor. contacts permanently closed. www.lancerbeverage.com Page 14 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 15: Circuit Diagram
Glycoolpac 27hx Manual 10. Circuit Diagram www.lancerbeverage.com Page 15 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 16: Spare Parts List
CAPACITOR START EMBRACO NJ9238GK 83000338 CAPACITOR RUN EMBRACO NJ9238GK www.lancerbeverage.com Page 16 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 17: Gp 27 Hx Evaporator Assembly
79000386 RIVET 1/8 S/S SHORT AVINOX. www.lancerbeverage.com Page 17 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 18: Gp27 Hx Electrical Box
PROBE NTC – 2 PER 83000184 PJEASY THERMOSTAT www.lancerbeverage.com Page 18 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 19: Gp27 Hx Pump Assembly
83000308 IEC LEAD MALE SPLASHP 300MM www.lancerbeverage.com Page 19 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013... -
Page 20: Certificate Of Warranty
Glycoolpac 27hx Manual 12. Certificate of Warranty It is the policy of Hoshizaki Lancer to provide to its current customers, warranty for all equipment supplied and installation work performed within a specified period. Parts And Equipment Hoshizaki Lancer provides a warranty period of twelve (12) months from the date of original invoice for all manufactured parts and the associated labour. -
Page 21: Manufacturer's Checklist
W/O ................................W/V ................................Affix label here www.lancerbeverage.com Page 21 of 21 Hoshizaki Lancer reserve the right to change specifications without notice. Part No 68000204 Images are for illustration purposes only as product may vary. No 024 – 27 November 2013...
