  • Page 4: Product Details

    S4E POLARIS V3 SPC54 4C CCA Product Features The Lancer S4E Polaris V3 Superchiller is a refrigerated unit designed to maintain a liquid product temperature through the python and dispenser. When coils are fitted the unit will chill liquid products stored at ambient temperature. The superchiller has a range of two pumps with different flow rates and can be used in ice bank or Glycol operation.
  • Page 5: Ice Bank

    & certified Electrical, Plumbing, & Refrigeration Technicians. www.lancerbeverage.com Page 5 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 6: Installation

    The superchiller must always be handled in a vertical position. Carefully unpack the Lancer S4E Polaris V3 Superchiller from the shipping carton, remove the wooden base. If appropriate, assemble legs to unit by carefully tilting (tilt should not be more than 45°).
  • Page 7: Mounting Superchiller

    Use of an RCD is recommended. www.lancerbeverage.com Page 7 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 8: Commissioning

    TDS reading www.lancerbeverage.com Page 8 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 9: Purge System

    “SET” key to display its value. www.lancerbeverage.com Page 9 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 10: Scheduled Maintenance

    • Check concentration with a refractometer. (see chart below) www.lancerbeverage.com Page 10 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 11 • Reconnect power supply and start machine. www.lancerbeverage.com Page 11 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 12: Electrical Circuit Diagram

    S4E Polaris V3 – Circuit Diagram www.lancerbeverage.com Page 12 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 13: Airflow Diagram

    S4E Polaris V3 Superchiller™ 240V / 50Hz 7. Airflow Diagram www.lancerbeverage.com Page 13 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 14: Trouble Shooting

    Remove obstruction or replace motor. Inefficient compressor Replace www.lancerbeverage.com Page 14 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 15: Omni Icebank Control Test

    (Simulates ice growth over the probes) www.lancerbeverage.com Page 15 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 16: Refrigeration & Body Assembly Parts List

    PROBE NTC RUGGEDIZED 83000091 PROBE NTC (BULB END) www.lancerbeverage.com Page 16 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 17: Assembly Diagram

    S4E Polaris V3 Superchiller™ 240V / 50Hz Assembly Diagram 10.1 www.lancerbeverage.com Page 17 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
  • Page 18: Certificate Of Warranty

    S4E Polaris V3 Superchiller™ 240V / 50Hz 11. Certificate of Warranty It is the policy of Hoshizaki to provide to its current customers, warranty for all equipment supplied and installation work performed within a specified period. Parts and Equipment Lancer provides a warranty period of twelve (12) months from the date of original invoice for all manufactured parts.
  • Page 19: Manufacturer's Checklist

    Customer asset No. W/O ..............Affix label here www.lancerbeverage.com Page 19 of 19 Hoshizaki Lancer reserve the right to change specifications without notice. Part No: 68000206 No 046-3 – 7 August 2019 Images are for illustration purposes only as product may vary.
