EX-1012

1. Description

The EX-1012 is an external expansion box with four PCI slots for extending or adding PCI connec-
tions via a PCI Express slot. For the settings of I/O addresses and interrupts no jumpers are ne-
cessary, because they are assigned automatically by the mainboard. The EX-1012 can be used in
addition to the mainboard PCI connectors and supports all standard PCI I/O cards (e.g. serial,
parallel, USB, FireWire etc...) with 5 & 3,3 volts. Included is a PCIe host adapter card, a USB-C
expansion cable and the expansion box itself. The EX-1012 is powered by an AC/DC power supply
(12-24V DC). It provides instant PCI bus expansion via the PCI Express slot of any computer sys-
tem. Since no drivers or software are required for installation, installing the EX-1012 into your sys-
tem is a breeze
Features:
•
Expands 4 PCI 32-bit 33MHz slots over existing PCI Express slot
•
The PCI slots are fully compatible with the PCI bus Rev. 3.0
•
Supports 1-lane 2.5Gb/s PCI Express data transfer rate
•
Supports both 5V and 3.3V PCI cards
•
Supports up to a maximum of 2 meters USB-C cable
•
12-24V DC power supply is required
•
Certificate for

2. Extent of Delivery

Before installing the EX-1012 in your system, please first check the contents of the delivery:
•
EX-1012
•
PCIe-Host-Adapter-Card
•
Low Profile Bracket
•
Power Supply (12V/3A)
•
UBS-C-Cable (1 Meter)
•
Manual
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
