3. Layout, LED's & Jumper Setting

3.3 Jumper Setting

There are three jumpers on the board. Please leave JP1 and JP3 as they were delivered from the
factory. You can change the jumper JP2 as follows:
JP2 Setting
„ON"
(Factory Setting)
„HOST"
© Copyright 2021 by EXSYS Vertriebs GmbH. All Rights Reserved
On-/Off Switch
On
On
JP2
JP1
Host PC Power
Don't care
On
JP3
11
English
Expansion Box Power
On
On
