Sealey WORKSAFE SSP5.V2 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS,
WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT
IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE
WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. INTRODUCTION
Shade 5 welding lens with indirect ventilation in goggle frame. Suitable for gas welding. Conforms to BS EN 175 and BS EN 169.
Notified Body: 2797.
Type Examination Certificate Number: CE 691450.
Carried Out By: BSI Group The Netherlands B.V.
2. SAFETY
CAUTION: this welding goggle does not provide unlimited eye protection. For your own protection read these instructions completely
before using this eye-protection.
Always perform a risk assessment and follow correct health and safety procedures before using this product.
9
No parts of the eye-protector which are in contact with the wearer are made of materials which are known to cause any skin irritation.
9
This goggle has been designed for your personal safety. It must be worn for the whole duration of exposure to hazards.
9
Leave the work area if dizziness or irritation occurs, or if the goggle becomes damaged.
9
The product is for eye protection against moderate impact, but is NOT unbreakable.
9
DO NOT modify or alter the eye protector.
8
WARNING! Scratched or damaged oculars should be replaced.
‰
WARNING! Materials which may come into contact with the wearer's skin could cause allergic reactions to susceptible individuals.
‰
If the symbols F, B and A are not common to both the ocular and the frame then it is the lower level which shall be assigned to the
9
complete eye-protector.
Toughened mineral filter oculars shall only be used in conjunction with a suitable backing ocular.
9
WARNING! Eye protectors against high speed particles worn over standard ophthalmic spectacles may transmit impacts, thus creating
‰
a hazard to the wearer.
3. APPLICATIONS
3.1. FIELD OF USE
This welding goggle is designed to protect the user against eye injuries through mechanical impact. The goggle is marked on the
ocular and the frame with a series of numbers and symbols to indicate the manufacturer, the field of use, the protection capabilities and
performance characteristics of the eye-protector. The marking of the oculars and of the frame are signified as follows:
- Cover Lens (dimensions Ø50mm x 2mm)
LD 1 F
- Protective Lens (dimensions Ø50mm x 2mm)
LD 1 F
- Filters
The use of filters must be EC/EU certified and their dimension must be Ø50mm The scale number must be adapted to the relevant
welding process. To know their characteristics of protection, consult the marking and notice of use of the filters.
5 JY 1
© Jack Sealey Limited
GAS WELDING GOGGLES
SSP5.V2
MODEL NO:
B CE
CE Certification
Symbol of protection against high speed particles, medium energy (120m/s)
Symbol of protection against high speed particles, low energy (45m/s)
Optical class
Identification of the manufacturer
B CE
CE Certification
Symbol of protection against high speed particles, medium energy (120m/s)
Symbol of protection against high speed particles, low energy (45m/s)
Optical class
Identification of the manufacturer
CE
CE Certification
Optical class
Identification model from the manufacturer
Shade number
Original Language Version SSP5.V2 Issue 1 12/03/24
