Sealey SGA3.V2 Instructions

thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to Wear opaque
instructions goggles
1. Safety
Always have a fire extinguisher nearby.
9
never use oxygen gas to blow soot or dirt from your clothes.
8
Do not wear ragged clothes, as sparks can ignite the ragged or loose ends.
8
secure cylinders to cart, wall or post to prevent them from falling.
9
All cylinders should be used and stored in an upright position.
9
never drop or strike a cylinder. Do not use cylinders that have been dented.
8
cylinder caps should be used when storing or moving cylinders.
9
empty cylinders should be kept in specified areas and clearly marked 'emPtY'.
9
never use oil or grease on any inlet connections, outlet connections or cylinder valves.
8
examine hoses for cuts, burns or worn areas before each use. Also inspect fittings for damage. if any damage is found, replace
9
immediately.
Keep all threads and unions clean and free from oil, dirt or grease.
9
never apply oil or grease to any thread.
8
for safety advice regarding gas bottles refer to the supplier of the bottles.
9
make sure bottle keys are in place at all times so that in the event of an emergency the valves can be turned off quickly.
9
check all joints weekly to make sure there are no leaks. leaKIng HoSeS Can KIll.
9
remember at all times Blue = oXYGen 'o'
9
reD = AcetYlene 'A'
oxygen fittings have a right-handed thread and notches on hose unions to indicate this.
9
this regulator has no user-serviceable parts. All repairs/calibrations must only be undertaken by a BcGA approved service agent
9
2. IntroDuCtIon
twin gauge regulator to Bs en iso 2503:2009 with bull nose adaptor and 3/8"BsP hose union. displays bottle pressure and working pressure
for oxygen.
© Jack sealey limited
instructions for
oxygen regulator
model no:
Wear gloves Wear protective
clothing
Original Language Version
Sga3.V2
Wear safety
footwear
.
sGA3.V2 | issue 2(l)- 20/12/16
