Assembly, Installation, Care, Maintenance and User Instructions
DO NOT attempt somersaults or flips. Paralysis or death can result if you land on your head or neck!
No more than one person on the trampoline at a time. Multiple users increase the risk of injury.
Use trampoline only with mature, knowledgeable supervision.
These instructions are important to minimize chances of injury. Please read each of them
thoroughly before you assemble and use this trampoline. Retain this manual for future reference.
Maximum weight of the user shall NOT exceed 220lbs/100kg for this product.
Trampoline must be used with enclosure that is properly installed and maintained
For Customer Service, please call 1-866-370-2131 or visit
Level 20, Parkview Centre,7 Lau Li Street, Causeway Bay, Hong Kong
14ft trampoline and enclosure
with basketball Hoop
TR-0132BSK-168
Monday – Friday 9:00 AM – 5:00 PM Eastern Time
Corporate Office 1-800-497-6106
BY
Sportspower Ltd.
www.sportspowerltd.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BouncePro TR-0132BSK-168 and is the answer not in the manual?

Questions and answers

Related Manuals for SPORTSPOWER BouncePro TR-0132BSK-168

Summary of Contents for SPORTSPOWER BouncePro TR-0132BSK-168

  • Page 1 Trampoline must be used with enclosure that is properly installed and maintained For Customer Service, please call 1-866-370-2131 or visit www.sportspowerltd.net Monday – Friday 9:00 AM – 5:00 PM Eastern Time Sportspower Ltd. Level 20, Parkview Centre,7 Lau Li Street, Causeway Bay, Hong Kong Corporate Office 1-800-497-6106...
  • Page 2 NO SOMERSAULTS OR FLIPS – PARALYSIS OR DEATH can result if you No more than ONE user at a time land on your head or neck! (maximum weight - 220 lb/100 kg). Do not use if in a Do not allow Remove all hard Do not use cast or have...
  • Page 3 Only genuine Sportspower replacement parts sold through our authorized dealer are recommended. Replacement parts from other sources may not have been designed, tested or manufactured to Sportspower standards. Because of this, Sportspower cannot guarantee the performance and safety of the product when non genuine replacement parts are used.

  • Page 4: Table Of Contents

     TABLE OF CONTENTS Before you start to assemble… ........................1 Before using the product… ..........................1 Important Safety Instructions ........................... 2 Important Instructions for Enclosure Netting and Mat ..................6 Trampoline and Enclosure Parts List ....................... 8 Hardware and Tools Parts List ......................... 9 Basketball Parts List ............................

  • Page 5: Before You Start To Assemble

    Heavy gloves must be used to protect your hands from pinch points during assembly and goggles must be worn to avoid injuries to the eyes.  Never modify the construction or the design of the product. Do not use any unauthorized Sportspower parts with this trampoline. ...

  • Page 6: Important Safety Instructions

    IMPORTANT WARNINGS Important Safety Instructions Carefully read these warnings before using this product. Failure to follow these warnings can result in serious injury or death.   Only one user at any one time! Multiple users can cause loss of control, collision or falls on the trampoline. This could result in serious injury to legs, arms, back, neck or head.
  • Page 7 IMPORTANT WARNINGS  Use trampoline only with mature, knowledgeable adult supervision.  Do not attempt or allow somersaults. Landing on the head or neck can cause serious injury, paralysis, or death, even when landing in the middle of the mat. ...
  • Page 8 This can result in serious injuries and/or product damage. If you see any signs of stretched or damaged springs, do not use the trampoline until replacement springs are properly installed. Please contact our customer service representatives to order original Sportspower replacement parts.
  • Page 9 Sportspower authorized replacement netting or pad is installed. Please refer to the Trampoline Net & Pad – Maintenance Requirements section contained in this manual for further details.

  • Page 10: Important Instructions For Enclosure Netting And Mat

    Official Sportspower replacement nets and padding can be purchased by contacting our authorized customer service by toll free number or email which can be found on the website www.sportspowerltd.net.
  • Page 11 Replace the enclosure net and pad earlier if there are any signs of wear, tear, brittleness, cracking, stretching or any other signs of weakness. New enclosure netting and pad can be purchased through SPORTSPOWER’S authorized service center (toll-free numbers and email address can be found on our website www.sportspowerltd.net).

  • Page 12: Trampoline And Enclosure Parts List

    Trampoline and Enclosure Parts List Trampoline Part Picture Description Quantity Number Trampoline Mat, stitched with Triangle-Rings Frame Pad Top Rail with Leg Sockets Top Rail Leg Base Leg Base Vertical Leg Extension （two holes） Vertical Leg Extension (three holes) Spring Trampoline Safety Instruction Placard Spring Loading Tool...

  • Page 13: Hardware And Tools Parts List

    Hardware and Tools Parts List Part Picture Description Quantity Number Arc Washer Screw Allen Wrench Wrench Gap Spacer Bolt Large Spring Lock Washer(M8) Cap Nut Self-Locking Screw Tube Cap Cord End Cap Small Spring Lock Washer(M4) Small Spring Lock Washer(M6) M6 Arc Washer (B) Cap Nut Bolt (M6x45mm)

  • Page 14: Basketball Parts List

    Basketball System Parts List (all parts packed in Basketball box) Part Picture Description Quantity Number Basketball Board Plastic Connectors Basketball Net Basketball Hoop Hook and Loop Strap (long) Hook and Loop Strap (short) Basketball Air Pump Screw (M8 x20mm) Flat Washer...

  • Page 15: Assembly And Installation Instructions

    Before assembly, please ensure that you have all the parts required to assemble the product. If you are missing any parts, please contact our Customer Support agents.  Please do not use unauthorized Sportspower parts to assemble the trampoline. This may damage the integrity of the product and will void the manufacturer’s warranty. ...

  • Page 16: Trampoline Frame Assembly

    Trampoline Frame Assembly BEFORE YOU BEGIN: Review all steps before assembly and read all precautions before using the trampoline. Three adults are recommended to assemble this trampoline. Protective gloves should be used during assembly to avoid injuries during installation. Goggles should be worn to avoid injuries to the eyes. Note : We’ve provided two adjustable wrenches to help with assembly, but you’re more than welcome to use your own tools.
  • Page 17 Step 2- Leg Support Assembly At this point, two people will be needed to assemble the trampoline.  Connect the Vertical Leg Extensions (#6A and #6B) to the Leg Base (#5). Secure using Screws (#B) and Arc Washer (#A) and tighten using Allen Wrench (#C) as shown below (the assembled parts will be hereinafter referred to as “Leg Support”).
  • Page 18 Step 3 – Top Rail Assembly  Complete the trampoline frame by inserting all of the Top Rails (#4) in between Top Rail with Leg Sockets (#3) as shown below. DO NOT PLACE HANDS NEAR THE OPENING WHEN CONNECTING THE TUBES. WEAR PROTECTIVE GLOVES TO PROTECT FROM INJURIES DURING ASSEMBLY.
  • Page 19 Step 4 – Secure the Leg Support to the Top Rail  Secure Vertical Leg Extension (#6A) to the frame using Self-Locking Screw (#I), Small Spring Lock Washer (#P) and Allen Wrench (#C) as shown below. If the holes do not match up, rotate Vertical Leg Extension back and forth until the holes are aligned.

  • Page 20: Trampoline Mat Assembly

    Trampoline Mat Assembly When attaching the springs, do not place your hands, arms, legs or any other body part close to the connector points (i.e. joints connecting the steel tubes). The connector points can become pinch points as the trampoline springs tighten up.
  • Page 21 Step 6 –Spring Assembly Continue to attach springs in the same manner. For even distribution of tension and ease of assembly, the springs must be placed on opposite sides of the mat in an alternating manner, i.e. 10 then 46, 28 then 64, etc. In addition to the previously installed springs, you should now have springs at 10, 28, 46 and 64 as shown below.
  • Page 22 Step 7 – Spring Assembly  Continue to attach springs in the same manner. For even distribution of tension and ease of assembly, the springs must be placed on opposite sides of the mat in an alternating manner, i.e. 5 then 41, 14 then 50, 23 then 59, 32 then 68, etc.
  • Page 23 Step 8 –Spring Assembly  Continue to attach the remaining springs in the same manner as the previous step, i.e. the springs must be placed on opposite sides of the mat in an alternating manner to ensure even distribution of tension. IMPORTANT: Once all the springs are properly installed, you must go back to Step 4 and now tighten the screws on all Leg Supports.

  • Page 24: Frame Pad Assembly

    Frame Pad Assembly Never use the trampoline without the Frame Pad, the Frame Pad reduces the risk of getting injured by hitting the metal frame or springs. Inspect the Frame Pad before each and every use to ensure all exposed metal parts are fully covered by the Frame Pad! Step 9 ...

  • Page 25: Trampoline Enclosure Assembly

    Trampoline Enclosure Assembly BEFORE YOU BEGIN: This trampoline must only be used when the enclosure netting is properly assembled. The trampoline netting  must be checked thoroughly before each use to ensure there are no tears or damages. Please carefully read all the Important Warnings contained in this manual and all warnings on the product before use.
  • Page 26 Step 11 – Connect the Enclosure Upper Frame to the Lower Frame  Attach Tube Cap (#K) to Upper Frame Tube with Foam (#10A) with Self-Locking Screw (#I) using Allen Wrench (#C) as shown below. Repeat this step for all five #10A upper frame tubes. ...
  • Page 27 Step 12– Connect Basketball Support Frame Tube to Basketball Board Bolt  Attach Basketball Support Frame Tube with Foam (#13) to Upper Frame Tube with Foam (# 10B) with Arc Washer (# T), Spring Lock Washer (# Q), (# R) and Cap Nut (# S). Tighten using Allen Wrench (#C) and Wrench (#D) as shown below.

  • Page 28: Basketball Assembly

    Basketball System Assembly Step 13 – Assemble Basketball Hoop  Remove the foam from Basketball Hoop (#16A) and attach Basketball Net (#16) using Long and Short Straps (#17A and #17B). See Step 14 for detailed instructions. You must not grab, hang, pull, push or make any contact or put any pressure on the basketball hoop, rim or frame.
  • Page 29 Step 14  Attach Basketball Net (#16) to Basketball Hoop (#16A) using Long Straps (#17A) at the back and Short Straps (#17B) at the front as shown below. Diagram 14-1 Diagram 14-2...
  • Page 30 Step 15 – Assemble Basketball Board and Basketball Hoop  Attach Plastic Connector (#15A) to Basketball Board (#15) using Screw (#N), Flat Washer (#O) and Allen Wrench (#C).  Attach Basketball Hoop (#16A) to Basketball Board (#15) and then insert the foam into the back of Basketball Board (#15) as shown below.
  • Page 31 Step 16 – Assemble Basketball Board and Basketball Hoop  Attach Basketball Board (#15) to Basketball Support Frame Tube with Foam (#13) using Screw (#N), flat washer (#O) and Allen Wrench (#C) as shown below.  Attach the snap-in-buckles located at the top of the enclosure netting to Upper Frame Tube with Foam (#10B) as shown below.
  • Page 32 Step 17 – Connect the Enclosure Upper Frame to the Lower Frame  Connect all six Upper Frame Tube with Foam (#10A and #10B) to Lower Frame Tube with Foam (#11). Secure with Self-Locking Screw (#I) using Allen Wrench (#C) as shown below. Helpful Tips: One person should stand inside the trampoline to hold the netting in place while another person installs all the frame tubes from the outside.
  • Page 33 Step 18 – Tie the Enclosure to the Mat  Secure the trampoline netting to the trampoline frame using the Cords (#L). Lift up the frame pad and tie one end of the cord to any one of the triangle-rings on the trampoline mat as shown below. ...
  • Page 34 Step 19 - Secure the Frame Pad  Wrap and tie the inner elastic straps on the frame pad around the triangle-rings and the outer straps around the trampoline frame as shown below. Diagram 19-1 TRIANGLE-RING INNER ELASTIC-STRAP...
  • Page 35  For the elastic straps near the leg sockets, wrap them BEHIND the leg sockets and then tie a one-sided bow in front as shown below. Diagram 19-2 OUTER ELASTIC STRAP Diagram 19-2 Make sure that the knots and bows are tight for all elastic straps. ...
  • Page 36 Step 20 – Close the Enclosure and Attach the Safety Instruction Placard  Close the zipper and buckles located at the entrance of the Enclosure Netting (#12).  Attach Trampoline Safety Instruction Placard (# 8) to the trampoline frame as shown. The zipper and buckles should be closed during use to avoid users falling out of the trampoline, as well as during periods of non-use to restrict access by unauthorized users.
  • Page 37 Step 21 – Inflate Basketball  Use Air Pump (#19) to inflate Basketball (#18) as shown below. Hint: Store the pump needle inside the air pump when not in use.

  • Page 38: Disassembly Of The Trampoline And Enclosure

    DO NOT USE THE TRAMPOLINE WHEN THE ENCLOSURE IS REMOVED. Do not make changes or add attachments to the trampoline that are not authorized genuine sportspower parts. The user must carry out changes to the trampoline (e.g. the addition of an attachment) according to the instructions of the manufacturer, particularly those attachments which include instructions on their assembly, necessary measurements and the correct fastening (e.g.

  • Page 39: Care And Maintenance

    Please contact our customer service representatives to order original Sportspower replacement parts.  Please do not use unauthorized Sportspower parts to assemble the trampoline. This may damage the integrity of the product and can cause injuries during use. ...

  • Page 40: Proper Use Instructions

    Proper Use Instructions Read and understand the use instructions in this manual prior to using this product. Failure to do so can result in serious injury or death. Responsibilities of the user The key here is to stay in control of your jumps. DO NOT move onto more complicated, more difficult maneuvers until you have mastered the basic, fundamental bounce.
  • Page 41 Read and understand the use instructions in this manual prior to using this product. Failure to do so can result in serious injury or death.  Read all instructions before using the trampoline. Warnings and instructions for the care, maintenance and use of this trampoline are included to promote proper and enjoyable use of this equipment.

  • Page 42: Learning The Fundamental Trampoline Skills

    Learning the fundamental trampoline skills The following lessons are suggested for you to learn basic steps and bounces. Before using the trampoline, you should read and understand all warnings. A complete discussion and demonstration of body mechanics and trampoline guidelines should occur between the supervisor and student as well.
  • Page 43 BASIC TRAMPOLINE BOUNCES THE BASIC BOUNCE 1. Start from the standing position, with your feet having shoulder width apart and with head up and eyes on mat 2. Swing arms forward and up in a circular motion 3. Bring feet together while in mid-air and point toes downwards.

  • Page 44: Product Warranty

    Product Warranty Sportspower Ltd warrants its products to be free from defects in material and workmanship under normal use and service conditions for ninety (90) days after the date of purchase. The steel frame on trampolines is warranted for two (2) years after the date of purchase.
  • Page 45 SPORTSPOWER IS NOT RESPONSIBLE OR LIABLE FOR INDIRECT, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THE PRODUCT OR OTHER DAMAGES WITH RESPECT TO ANY ECONOMIC LOSS, LOSS OF PROPERTY, LOSS OF REVENUE OR PROFITS, LOSS OF ENJOYMENT OR USE, COST OF REMOVAL, INSTALLATION OR OTHER CONSEQUENTIAL DAMAGES.
