SPORTSPOWER Jump Zone LT-6005-156 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TRAMPOLINE ENCLOSURE
FOR
13FT TRAMPOLINE WITH 4 LEGS
Assembly, Installation, Care Maintenance, and Use Instructions
USER'S MANUAL
LT-6005-156+EN
WARNING
THE TRAMPOLINE ENCLOSURE IS ONLY TO BE USED AS AN ENCLOSURE FOR A TRAMPOLINE.
YOU MUST THOROUGHLY READ AND UNDERSTAND INSTRUCTIONS IN THIS MANUAL, BEFORE
ASSEMBLING AND USING THE TRAMPOLINE ENCLOSURE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
MAXIMUM WEIGHT OF THE USER SHALL NOT EXCEED 220LBS/100KGS
CUSTOMER SERVICE
Toll Free: 1-866-370-2131
MONDAY-FRIDAY, 9 A.M. - 5 P.M. CENTRAL TIME

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jump Zone LT-6005-156 and is the answer not in the manual?

Questions and answers

Related Manuals for SPORTSPOWER Jump Zone LT-6005-156

Summary of Contents for SPORTSPOWER Jump Zone LT-6005-156

  • Page 1 TRAMPOLINE ENCLOSURE 13FT TRAMPOLINE WITH 4 LEGS Assembly, Installation, Care Maintenance, and Use Instructions USER’S MANUAL LT-6005-156+EN WARNING THE TRAMPOLINE ENCLOSURE IS ONLY TO BE USED AS AN ENCLOSURE FOR A TRAMPOLINE. YOU MUST THOROUGHLY READ AND UNDERSTAND INSTRUCTIONS IN THIS MANUAL, BEFORE ASSEMBLING AND USING THE TRAMPOLINE ENCLOSURE.

  • Page 2: Enclosure Safety Information

    ENCLOSURE SAFETY INFORMATION The trampoline enclosure is only to be used as an enclosure for a trampoline and the trampoline must be of the appropriate size as covered by specific enclosure. PLEASE READ ENTIRE INSTRUCTION BOOKLET BEFORE YOU ASSEMBLE OR USE THIS TRAMPOLINE.

  • Page 3: Parts List

    PARTS LIST #A UPPER FRAME TUBE WITH FOAM x 8 pcs #B LOWER FRAME TUBE WITH FOAM & CLAMP x 8 pcs #C TUBE CAP x 8 pcs #F NUT COVER x 16 pcs #G CORD x 8 pcs #D SCREW x 16 pcs #H ENCLOSURE NETTING x 1 pc #E LOCK NUT x 16 pcs...

  • Page 4: Assembly Instruction

    ASSEMBLY INSTRUCTION CAUTION: TWO ADULTS ARE REQUIRED TO ASSEMBLE THIS ENCLOSURE. STEP 1 Please make sure the Attach #J END CAP to the #B LOWER FRAME TUBE WITH FOAM & CLAMP. #J END CAP is inserted to the side closer to the CLAMP on the Frame Tube as shown in FIGURE 1. FIGURE 1 STEP 2 Please have someone helping you to hold the frame tube.
  • Page 5 STEP 3 Attach #C TUBE CAP to #A UPPER FRAME TUBE WITH FOAM as shown in FIGURE 3. Repeat this step for all upper frame tubes. STEP 4 CAUTION: TWO ADULTS ARE REQUIRED TO ASSEMBLE THIS ENCLOSURE. Attach #A UPPER FRAME TUBE WITH FOAM to #B LOWER FRAME TUBE WITH FOAM & CLAMP as shown in FIGURE 3.
  • Page 6 STEP 5 Attach the snap in buckles on the top of the netting enclosure to the #C TUBE CAP as shown. Attach the top snap in buckles for all other sets of tube frame. Please make sure the cap holder is facing outward.
  • Page 7 IMPORTANT NOTICE If the strap falls off the buckle in some cases, please follow the instruction below to re-assemble it. Please note that two sides of buckle are different. You should slide the strap through the slot from the SIDE A, otherwise it wouldn’t work properly.

  • Page 8: Care And Maintenance

    Important Warning You should go back now and stretch all attachment buckles tight, so the enclosure netting stands stiff. Otherwise, the enclosure netting will not function properly. DISASSEMBLY To disassemble, simply follow assembly STEP 1 thru STEP 6 in reverse order, until you have disassembled the enclosure.

  • Page 9: Use Instructions

    WARNING!! PLEASE READ ENTIRE INSTRUCTION BOOKLET BEFORE YOU USE THIS TRAMPOLINE. Use trampoline only with mature, knowledgeable supervision. WARNING!! PARALYSIS OR DEATH CAN NO MORE THAN ONE PERSON RESULT IF YOU LAND ON AT A TIME ON THE TRAMPOLINE! YOUR HEAD OR NECK! MULTIPLE JUMPERS INCREASE DO NOT PERFORM THE RISK OF INJURY SUCH AS...
  • Page 10 Do not attach anything to the netting that is not a Sportspower LTD. approved accessory or part of the trampoline enclosure. Stop bounce by flexing knees as feet come in contact with the trampoline bed. Learn this skill before attempting others.
  • Page 11 Keep objects away that could interfere with the performer. Maintain a clear area around the trampoline and trampoline enclosure. Bounce only when the surface of the mat is dry. Wind or air movement should be calm to gentle. The trampoline and trampoline enclosure must not be used in gusty or severe winds In severe wind situations, the trampoline and trampoline enclosure can be blown about.

  • Page 12: Limited Warranty

    SPORTSPOWER authorized service center, or to products used for commercial or rental purposes. No other Warranty beyond that specifically set forth above is authorized by SPORTSPOWER.
