Vaporesso Drizzle Vaping Kit Quick Manual

Thank you for choosing Vaporesso Products!
Please read this manual carefully to ensure
proper use. For additional information or
questions regarding to this product or its use,
please visit www.vaporesso.com
Drip tip
Main features Package Include
● ECO Universal COIL, Only change the EUC 1 x Drizzle Vaping Kit
● Specially engineered for The best MTL vaping 1 x EUC Extra
● CCELL Ceramic Coil Inside 1 x USB Cable
Drizzle Vaping Kit by Vaporesso is sleek modern in design, easy to carry, and easier to use. Thanks to its tiny design, it is specially
designed with adjustable top airflow tank for the best MTL vaping experience. It adopts the ECO Universal Coil, so that you only need to
replace the EUC without changing the metal sleeve, that is truly ECO friendly and makes vaping more affordable. Built with CCELL ceramic
coil inside, it is guaranteed to deliver the most original flavor of your e-liquid.
Relax with Drizzle Vaping Kit!
How to Use
1.Switch On/Off:
Press the fire button 5 times in quick succession within 2 seconds to turn the device on. In the same way, the device will be powered off
after 5 presses.
2.Vaping:
Hold the fire button and inhale through the mouthpiece. Release the fire button and exhale.
3. Adjustment of Air Flow:
The top airflow system can be adjusted with slight twisting motions of the top lid which will not loosen its attachment to the pyrex glass
4. Filling E-liquid:
This easy top-fill tank will only ask of you to screw out the lid and fill in the chamber when the base is securely shut.
Be sure to safely position the glass part when this process is in place to avoid spillage.
5. Changing Atomizer:
Unscrew the base to simply remove and insert a new atomizer whenever needed. Pull the EUC out from the base and insert a new one.
Screw the Base on. Wait after replacing to make sure the coil is well primed.
Drizzle Vaping Kit
Quick Guide
Pyrex glass tube Micro USB
Lid
Base Power button
Specification
Dimension: 18 x 102.5 mm
Capacity: 1.8 ml
Battery: 1000mAh Built In
6.Charging:
Simply charge Drizzle Vaping Kit by connecting it with a computer or a wall adapter via USB cable. When it's fully charged, the button light
will go out.
Function:
Short Circuit Protection:
1.When the short circuit occurs before working, the button light flashes for 5 times and there will be no output power.
2.Low Wattage Protection
When the battery voltage is lower than 3V, the fire button light flashes for 3 times and the battery will be locked.
3.Over Vaping Protection
When the fire button is pressed for more than 10 seconds, the light flashes 3
times then goes off. The battery will be locked.
4.Low Battery Protection
When the battery is less than 10%, the light will flashes till it goes off completely.
Note:
1.Please power-off the Drizzle Vaping Kit when not in use.
2.Do not to press the button if the Drizzle Vaping Kit is not in use.
3.Only have your Drizzle Vaping Kit repaired by Vaporesso. Do NOT attempt to repair it on your own as it may lead to further damage to
the item and/or personal injury.
Caution
1.The device is intended for usage by people over 18, NOT by non-smokers, children, pregnant or breastfeeding women, people with or at
risk of heart disease, or people taking medication for depression or asthma. The electronic cigarette is not a smoking cessation device.
2.Please keep this unit out of reach of children or pets;
3.Please don' t drop, throw or abuse your device, it may cause damage;
4.Please keep the battery dry;
5.Do not place it in extremely temperatures;
6.Do not try to disassemble the battery;
7.This device does not mean to be used as a nicotine replacement therapy for smoking cessation.
This refillable electronic cigarette is intended for use with compatible liquid, which may contain nicotine. Nicotine is
an addictive substance and its use is not recommended for use by the following:
- Non smokers or persons under the legal smoking age
- Pregnant or breastfeeding women
- Persons experiencing heart disease, stomach or duodenal ulcers, liver or kidney problems, long-term throat
disease or difficulty breathing due to bronchitis, emphysema or asthma.
- Persons with an overactive thyroid gland or experiencing phaeochromocytoma (a tumour of the adrenal gland that
can affect blood pressure)
- Those taking the medications Theophylline, Ropinirole or Clozapone
You may experience the following side effects if you use nicotine containing e-liquid in combination with this
product. If this happens, please consult a healthcare professional and show them this leaflet if possible:
- Feeling faint
- Nausea
- Dizziness
- Headache
- Coughing
- Irritation of the mouth or throat
- Stomach discomfort
- Hiccups
- Nasal congestion
- Vomition
- Chest palpitations/pain or an irregular heart rate
This device should not be used by persons under the age of 18 or non-smokers.
Designed in California
Manufacturer:Shenzhen Smoore Technology Limited
Add:Building 8,Dongcai Industrial Park,Gushu Town,
Baoan District,Shenzhen, China 518102
Management System of SMOORE factory has been assessed
and registered under the Norm cGMP, ISO13485, ISO9001
and ISO14001.TM and ©2016 Vaporesso All rights reserved
