Installation Instructions - Lever & Gen II Lever
Wire Connectors
Models 52, 53, 55, L2, L3 & L5
• Do not exceed the rating of these connectors
• Turn OFF power before removing or installing connectors
• Wiring must comply with all applicable electrical regulations
• COPPER TO COPPER ONLY. Do not use on aluminium wire.
• Incorrect use of these connectors can cause electrical fires, personal injury or death
• Use only one conductor per port
• Strip wires back 9 – 10mm (52, 53 & 55) / 11-12mm (L2, L3 & L5)
• For solid and rigid stranded wire, grip wire firmly and insert conductor into open port
(lever does not need to be open)
• For flexible stranded wire (>7 strands) lift lever and insert conductor into open port. Close lever
• Verify conductors are fully inserted to the back of the connector.
• To remove a wire, lift lever and pull out wire
Strip Length
Specifications
Rating
Depth
Width
Height
Wire Combination Range
Specifications
Rating
Depth
Width
Height
Wire Combination Range
Insertion
Solid, Rigid Stranded and
Flexible Wires
Solid and Rigid Stranded
Flexible Wires
Model 52 2-Port
11.9 mm
Model L2 2-Port
13.3 mm
idealind.com
Removal
Model 53 3-Port
24 Amp / 450V / 85°C
21 mm
16.1 mm
11.7 mm
0.2mm
-2.5mm
2
2
Model L3 3-Port
32 Amp / 450V / 85°
18.6 mm
18.9 mm
8.8 mm
0.2mm
- 4.0mm
2
2
0.14mm
- 4.0mm
2
2
Model 55 5-Port
24.5 mm
Model L5 5-Port
30.4 mm
2/16
