This guide provides information regarding the installation, operation, maintenance and
warranty of the Pressurized Flow Dividers PFS 300C (3 outlets) to PFS-1000C (10 outlets)
from Premier Tech Water and Environment. For additional information, contact our customer
service at 1 800 632-6356.
1. TECHNICAL DATA
MATERIALS
PVC and polyethylene plastic.
INLET/OUTLET
• Inlet: Barbed adapter for 50 mm (2") nominal
diameter flexible pipes.
• Outlet: Male outlet adapted to couplings for the 100 mm (4")
nominal diameter PVC pipe (BNQ or SDR 35).
RATIO OF FLOW DISTRIBUTION
Variation inferior to 5% with 5 outlets or less.
Variation inferior to 8% with 6 outlets or more.
OPERATION PRESSURE
Minimum 7 kPa (1 psi).
Maximum 28 kPa (4 psi).
INCLUDED
One (1) Y-Tee adapter 100 mm Ø (4") BNQ per PFS outlet.
2. PRODUCT DESCRIPTION
The pressurized flow dividers PFS-300C to PFS-1000C are complementary components of the Ecoflo
to larger size projects. They allow cluster installation of 3 to 10 Ecoflo biofilters to handle larger flows and can also be
used in any type of septic installation. They ensure that the effluent, that has already undergone preliminary treatment in one
or more septic tanks equipped with effluent filter(s), is divided into 3 to 10 equal parts, depending on the installation's
specific requirements. The flow dividers are pressure fed and distribute the effluent to the treatment systems through gravity
flow pipes.
3. LOCATION AND INSTALLATION
3.1 Location
The pressurized flow dividers PFS-300C to PFS-1000C are connected to the pipe joining the pumping station to the treatment
systems such as the Ecoflo biofilters or conventional drainfields.
20221024 — Item #642839
Installation Guide
and Owner's Manual
Pressurized flow dividers PFS-300C
to PFS-1000C (3 to 10 outlets)
biofilter for average
®
