PREMIER TECH STB-650B Series Owner's Manual

®
Ecoflo Peat Filter systems (Concrete)
Congratulations on your purchase of an Ecoflo
have wisely chosen to protect your health as well as the environment. This manual contains information on system
operation and maintenance, guidelines for use and warranties for models
(with integrated pump), H1, H2, or H3 (different heights), -1,-2, or -3,(quantity of Peat Filters) A or NA (assembled or not
certified under the NSF Standard 40. For additional information, contact our customer service at 1
assembled)
800 6Ecoflo (800 632-6356).
System description and Operating principle
The Ecoflo ® Peat filter system is a wastewater treatment system designed to treat domestic wastewater.
Your complete Ecoflo ® Peat filter system includes a septic tank, an effluent filter, one or more Peat Filters
and, depending on the type of installation, a pumping station and a flow divider.
System description
®
The Ecoflo Peat Filter is made of a concrete shell enclosing a
natural filtering media composed of two specific layers (bottom
and top layers) especially selected to treat residential wastewater.
Two polyethylene lids securely fastened limits the accesses to the
system. Under the main and secondary access lids is located an
insulating board that deflects the incoming air into 2 aeration
channel to feed the filtering media. That lid also insulates the
inside parts of the system.
Operating principle
To be treated, the wastewater goes first into the septic tank where it is submitted to a primary treatment. Then it goes through
the effluent filter, to prevent solids discharge to the effluent, and in the flow regulator to restrain the flow rate reaching the
® Peat Filter. Once inside the Ecoflo
Ecoflo
distribution plates located on both sides of the central support plate. These plates include channels with orifices to distribute
the effluent evenly on top of the filtering media. Afterwards, wastewater trickles down into the filtering media where its
organic content is consumed by bacteria. The treated effluent is collected in the gravel bed and evacuated by gravity (STB-
650B series) or with an integrated pump (STB-650BR series).
Figure 1 Water flow diagram
(STB-650BR series with integrated pump)
Please take note that for models STB-650BR-H2/H3 series-A/NA the diagram differ slightly regarding the aeration and
drainage system but the same operating principle applies.
Premier Tech Environment
®
Peat filter system. In choosing the Ecoflo
The Ecoflo
under standard 40.
described here meets Class I requirements as per ANSI/NSF
standard 40.
®
, the water is directed into the tipping bucket in order to be split equally over the
1/9
Owner's manual – USA-NSF
®
Peat filter system, you
STB-650B (without integrated pump) or BR
®
Peat filter system has been tested and listed
Each model of Ecoflo
Figure 2 Water flow diagram
(STB-650B series with gravity discharge)
OwnerManSTB-650BBRconcrete-NSF
®
