  • Page 1 USER GUIDE CONTROL PANEL BALBOA | Your Single Source Solution TP740 User Guide...
  • Page 2 THANK YOU FOR CHOOSING BALBOA WATER GROUP SPA CONTROLS. TP740 Control Panel Family BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 3: Table Of Contents

    MODES THE MAIN SCREEN WITH CLIM8ZONE SET THE CLIM8ZONE MODE SET eHeater MODE SET THE SPEED MODE TP740 PANEL COMPATIBILITY VIEW MESSAGES BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 4: Review Main Screen

    Message Code: MO28 connected (local or cloud connection) Light 1 I - Arrow Light 1 Light 1 Light 1 The heater may be dry BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 5: Review User Interface

    The next page shows various examples of or changing a selected item on the panel screen is generally selected items (B, H, K). done with the SELECT button. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 6 Cancel icon (J) and press the SELECT navigation button. Locks pane http Switch Off Switch On BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 time Language: English http...
  • Page 7 Settings menu (D). VIEW MESSAGE SCREEN Go to page 42. Settings Music Settings Invert Settings Invert Test Invert Test 12:00 am BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 8: Set Time Of Day

    24-hour time display. pane http time http * View “Navigate Settings Menu” on page 7. View Quick Tip video. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 lter Language: English http...

  • Page 9: Change Set Temperature

    Heater Off Heater On View Quick Tip video. 12:00 am BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English heat https...

  • Page 10: Run Spa Devices

    If a Circulation Pump icon appears (D) in the Spa screen, the icon is not controllable. It is there to show you the equipment status only. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24...

  • Page 11: Set Filter Cycle Time

    * View “Navigate Settings Menu” on page 7. View Quick Tip video. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 set te Language: English https...

  • Page 12: Review Settings Menu

    GFCI test applies to North America only. This feature is not available on CE rated systems. * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 13: Set Units

    Units Units 12:00 am Temperature °F Temperature °F Time 12 HR Time 12 HR * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 14: Change Heat Settings

    Note: M8 is not available on all control systems. * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 15 Heat screen. set te https heat https * View “Navigate Settings Menu” on page 7. View Quick Tip video. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English temp...

  • Page 16: Select Language

    P. Light P. Light Brightness Brightness Panel Screen Sleeps After 5 min P. Light Brightness * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 17 5 min P. Light P. Light P. Light Brightness 100% Brightness 100% Brightness 100% * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 18 Screen Sleeps After 15 min P. Light P. Light P. Light Brightness Brightness Brightness * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 19: Invert Display

    12:00 am 12:00 am RIGHT DOWN usic Settings Invert Settings Invert Test Invert Test * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 20: Lock The Panel And/Or Settings

    12:00 am Main screen 12:00 am 12:00 am 12:00 am Switch On Switch Off * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 21: Perform Gfci Test

    Using Reset (F) forces a new Test to be performed at the new location. * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24...

  • Page 22: Fill Your Hot Tub

    Priming Mode screen (view next page or the flow from one pump may hide (B)). Only pump icons appear on the the flow from another pump. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 23 12:00 AM 12:00 am Message Code: MO28 The heater may be dry Test ---- Setup # Setup # Fault Log Select Logo Display BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 24 Three separate lighting zones give you full lighting control and flexibility. Note: is not available on all control systems. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...

  • Page 25: Review Screen

    Zone B Cancel Zone A Zone C Zone C Group 1: AB Groups BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Restore Defaults Language: English Restore Defaults Group Press OK to restore the default Zone A Restore defaults.

  • Page 26: Illuminate Your Spa

    Color 2 Zone A Zone A Zone A Zones Zones Zones Zone S Zone S Zone S BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Groups Groups Groups Group Language: English Group Colors...

  • Page 27: Customize Your Colors

    Groups Zone A Zone A Groups Groups Groups Group Group Group Group BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Color 2 Language: English Zone A Zone A Zone A Zone A...

  • Page 28: Rename Zones

    Zone A: Status Pro Groups Group Zone A Zone B Zone C * View “Navigate Settings Menu” on page 7. oups oups Groups BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English Group...

  • Page 29: Select Zone Functionality

    Zone C Zone C * View “Navigate Settings Menu” on page 7. Zone A Groups Groups Group BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English Color 2 Group Zone A...

  • Page 30: Group Zones

    Zone A Zone B Zone B Cancel Zone C Zone C * View “Navigate Settings Menu” on page 7. Groups Group BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English Zone A...
  • Page 31 Cancel Zone B Zone C Cancel Zone C Zone C * View “Navigate Settings Menu” on page 7. Groups Group BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English Zone A...
  • Page 32 Enjoy an immersive spa experience with Balboa Bluetooth Audio. Note: BBA 3 is not available on all control systems. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 33 2 - If your screen shows “USB”, you have 0:45 3:15 an older bba1 or bba2 unit. Settings Bluetooth BT Connected BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English Fade EQ Preset Flat...
  • Page 34 * View “Navigate Settings Menu” on page 7. Bluetooth Bluetooth Bluetooth Bluetooth My Favorite Song My Favorite Song My Favorite Song My Favorite Song BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 35 Note: CLIM8ZONE is not available on all control systems. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 36 The electric heater is continuously disabled. 4 - Enabled The electric heater is continuously enabled. This setting is selected automatically when Clim8zone mode is set to “Disabled.” BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 37 Spa screen (D) for apprximately 10 - 60 seconds. During this short time, other spa devices will not opperate. This is a power management feature. 12:00 AM 12:00 AM BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 38 4 - Cancel your setting (F), or save your setting (E). Clim8zone Modes: Heat and Cool Heat Only Cool Only Disabled * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 39 NOTE: eHeater mode is not available when Clim8zone is set to “Cool Only” or “Disabled” (view page 38). * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 40 II does not support speed modes, so Speed (C) will not appear in the Clim8zone screen. * View “Navigate Settings Menu” on page 7. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 41 Panel Compatibility TP740 PANEL COMPATIBILITY The TP740 panel family is compatible with the following Balboa Water Group products. TP740 PANEL FAMILY Trapezoid Large Rectangle Small Rectangle CONTROL SYSTEMS BP2000, BP2100 BP501, BP601 BP100, BP200 CLIM8ZONE HEAT PUMPS Clim8zone Clim8zone BALBOA...
  • Page 42 The heater may be dry example, the water temperature in the heater may ---- need to change before a message will clear. BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
  • Page 43 Europe - europe@balboawater.com Balboa Water Group 3030 Airway Avenue Costa Mesa, CA 92626 Phone: 714.384.0384 www.balboawater.com Specifications subject to change without notice. XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX BALBOA | Your Single Source Solution TP740 User Guide Document No. 42418 Rev. B1 - 04/16/24 Language: English...
