- Page 1 O R I G I N A L I N S T R U C T I O N S O R I G I N A L I N S T R U C T I O N S USER GUIDE M O B I L E M A S O N R Y C L E A N I N G...
- Page 2 O R I G I N A L I N S T R U C T I O N S INDEX Safety information Safety Information Checklist Specification Site Requirements Checklist of Parts Required Control Panel Detailed View Quick Setup Guide Routine Maintenance Declaration of Conformity...
- Page 3 C O N S I D E R A T I O N S W H E N U S I N G T H E D O F F S Y S T E M Only Stonehealth inducted and authorised operators may use the equipment. A nominated person adjacent, other than the Operator, should be aware of how to safely shut down the system in unforeseen circumstances.
- Page 4 O R I G I N A L I N S T R U C T I O N S Safety Information Checklist Whilst Stonehealth have made every effort to give appropriate general guidance the equipment must comply iwth and be used in accordance with any regulation appropriate to the site on which it is in use.
- Page 5 O R I G I N A L I N S T R U C T I O N S Specification Mass 250KG Dimensions L: 1100mm W: 600mm H: 900mm Flow rate 7 - 10L Per Minute Output temperature 150°c Pump pressure 20 - 150 bar Noise level...
- Page 6 O R I G I N A L I N S T R U C T I O N S Site Requirements Y O U W I L L N E E D : Clean, cold water supply with a positive pressure. Approximately 10 Litres per minute flow Clean uncontaminated fuel –...
- Page 7 O R I G I N A L I N S T R U C T I O N S Checklist of Parts Required Lance x2 DOFF Skid Mount Spare fuel filter Jerry can De-scaler hose Hose 25 litres of DOFF descaler Extension hose Trigger...
- Page 8 O R I G I N A L I N S T R U C T I O N S Control Panel Detailed View Emergency stop Oil light Cool down light ON/OFF Thermostat reset Thermostat Pump pressure adjustment Pressure gauge...
- Page 9 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide To operate the DOFF Skid Mount, you will need a clean, cold water supply providing no less than 7 - 10 litres of water per minute.
- Page 10 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Next, connect the water supply. Now connect the hot hose to the connector on the DOFF Skid Mount.
- Page 11 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Then, connect the Trigger to the hot hose. To power on the DOFF Skid Mount, pull the emergency stop button out fully and then turn the key clockwise to the one o’clock position Avoid frequent ON/OFF of the switch and trigger.
- Page 12 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Once the system has been flushed, you can safely connect the lance to the DOFF trigger. Lances can be supplied in different lengths to suite your requirements. Adjust the controls to the desired heat and pressure.
- Page 13 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide To power off the DOFF, turn the temperature dial down to the ‘off’ position and wait for the blue light to turn on.
- Page 14 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Here you can check the oil level and replenish accordingly, if required. You are now ready to start using the DOFF Skid Mount. For more detailed operation instructions, scan the QR code or visit stonehealth.com/setting-upthe-stonehealth-doff-skid-mount/...
- Page 15 Always cool down DOFF system when not in use (we recommend cooling for any break in operation of more than 2 minutes). Stonehealth stock a full range of spare parts. Due to the nature of the system, we recommend only using parts supplied by Stonehealth and will need to be fitted by a competent person.
- Page 16 O R I G I N A L I N S T R U C T I O N S EC Declaration of Conformity W H A T D O E S A D E C L A R A T I O N O F C O N F O R M I T Y M E A N ? It is a formal declaration by a manufacturer, or the manufacturer’s representative, that the product to which it applies meets all relevant requirements of all product safety directives applicable to that product.
- Page 17 O R I G I N A L I N S T R U C T I O N S EC Declaration of Conformity In accordance with EN ISO 17050-1:2004 Stonehealth Ltd G4/5 Draycott Business Park, Cam, Dursley, Gloucestershire, GL11 5DQ, UK in accordance with the following Directives:...
- Page 18 O R I G I N A L I N S T R U C T I O N S Notes...
- Page 19 O R I G I N A L I N S T R U C T I O N S...
- Page 20 National Trust, English Heritage, Historic Scotland, CADW and other worldwide conservation bodies. Stonehealth is proud of its reputation in providing solutions with integrity and setting new standards of restoration and technology excellence in the stone industry.
