- Page 1 O R I G I N A L I N S T R U C T I O N S O R I G I N A L I N S T R U C T I O N S USER GUIDE S U P E R H E A T E D W A T E R / S T E A M C L E A N I N G S Y S T E M...
- Page 2 O R I G I N A L I N S T R U C T I O N S INDEX Safety information Safety Information Checklist Specification Checklist of Parts Required Site Requirements Quick Setup Guide Routine Maintenance Declaration of Conformity...
-
Page 3: Safety Information
C O N S I D E R A T I O N S W H E N U S I N G T H E D O F F S Y S T E M Only Stonehealth inducted and authorised operators may use the equipment. A nominated person adjacent, other than the Operator, should be aware of how to safely shut down the system in unforeseen circumstances. - Page 4 Visually check all equipment before use, if damage is noted the equipment should not be used. The normal fuel for the DOFF is light gas oil or motor vehicle diesel (white diesel), or (28 second) domestic central heating oil. Never Petrol, Gasoline or Spirit Fuels! Acid Descaler supplied with product should be handled with care: see product Health &...
-
Page 5: Specification
O R I G I N A L I N S T R U C T I O N S Specification Voltage 110V or 230V 50Hz Frequency (or local requirement for international market) Heater Output 74KW Rated Pressure 12Mpa / 120 Bar Current P O W E R C O N S U M P T I O N Hotbox... - Page 6 **Please note that the RCD (230V only) is not illustrated in the image above. DOFF trigger Hotbox DOFF lance x2 Pump Jerry can x2 Transformer (110V only) Spare fuel filter Extension cable De-scaler hose Blue input hose DOFF Integra hose 25 litres of DOFF descaler DOFF extension hose...
-
Page 7: Site Requirements
230 volt 50hz/60hz AC supply to BS7671 (+10% to - 6%) 13 Amp (use RCD) or 6.5KVA (cont) Generator 230 volt or 110 volt as above or Stonehealth DOFF Power Unit (DPU) Clean, cold water supply with a positive pressure. Approximately 10 Litres per minute flow Clean uncontaminated fuel –... - Page 8 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Plug in the Transformer** to appropriate power supply Plug Extension cable into Transformer** and into DOFF pump Please note that the Transformer is for 110V systems only, for 230V use RCD that is supplied.
- Page 9 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Plug Hotbox into Pump Connect Blue Input Hose male into DOFF Pump...
- Page 10 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Connect Blue Input Hose female into Hotbox Connect Integra Hose into Hotbox...
- Page 11 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Connect Integra Hose into Extension Hose Connect Extension Hose to Trigger...
- Page 12 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Connect Trigger to Lance Connect Mains Water Supply to Pump...
- Page 13 Hotbox (10) You are now ready to start up the DOFF as per your Stonehealth Induction training. The DVD supplied with this system also shows the starting, running and shutdown procedure. Avoid frequent ON/OFF of the switch and trigger.
-
Page 14: Routine Maintenance
Nozzles can wear which will affect the performance of the machine. Replace nozzle if spray jet becomes defused or defined jets appear at the edges of the spray. Always cool down DOFF system when not in use (we recommend cooling for any break in operation of more than 2 minutes). -
Page 15: Ec Declaration Of Conformity
O R I G I N A L I N S T R U C T I O N S EC Declaration of Conformity W H A T D O E S A D E C L A R A T I O N O F C O N F O R M I T Y M E A N ? It is a formal declaration by a manufacturer, or the manufacturer’s representative, that the product to which it applies meets all relevant requirements of all product safety directives applicable to that product. - Page 16 The Restriction of Hazardous Substances Directive hereby declare under our sole responsibility that: Equipment Specialist Steam Cleaning Equipment. Model DOFF Integra Serial Number D2 – as per dash name plate. is in conformity with the applicable requirements of the following documents: Ref. No.
- Page 17 O R I G I N A L I N S T R U C T I O N S Notes...
- Page 18 O R I G I N A L I N S T R U C T I O N S Notes...
- Page 19 O R I G I N A L I N S T R U C T I O N S O R I G I N A L I N S T R U C T I O N S...
- Page 20 National Trust, English Heritage, Historic Scotland, CADW and other worldwide conservation bodies. Stonehealth is proud of its reputation in providing solutions with integrity and setting new standards of restoration and technology excellence in the stone industry.
