- Page 1 O R I G I N A L I N S T R U C T I O N S O R I G I N A L I N S T R U C T I O N S USER GUIDE S U P E R H E A T E D W A T E R / S T E A M C L E A N I N G S Y S T E M...
- Page 2 O R I G I N A L I N S T R U C T I O N S INDEX Safety informati on Safety Informati on Checklist Specifi cati on Checklist of Parts Required Site Requirements Quick Setup Guide Routi ne Maintenance DOFFIII Remote Control DOFFIII Control Screen...
- Page 3 C O N S I D E R A T I O N S W H E N U S I N G T H E D O F F I I I S Y S T E M Only Stonehealth inducted and authorised operators may use the equipment. A nominated person adjacent, other than the Operator, should be aware of how to safely shut down the system in unforeseen circumstances.
- Page 4 O R I G I N A L I N S T R U C T I O N S Safety Informati on Checklist Whilst Stonehealth have made every eff ort to give appropriate general guidance the equipment must comply with and be used in accordance with any regulati on appropriate to the site on which it is in use.
-
Page 5: Hotbox
O R I G I N A L I N S T R U C T I O N S Specifi cati on Voltage 110V 50Hz Frequency (or local requirement for internati onal market) (or local requirement for internati onal market) Heater Output 74KW Rated Pressure... -
Page 6: Remote
O R I G I N A L I N S T R U C T I O N S Site Requirements Y O U W I L L N E E D : 110 volt 50hz/60hz AC 16 Amp supply Or 3KVA (cont) Generator 110 volt as above Clean, cold water supply with a positi ve pressure. -
Page 7: Table Of Contents
O R I G I N A L I N S T R U C T I O N S Checklist of Parts Required Hotbox DOFFIII Trigger Remote DOFFIII lance x2 Jerry can x2 Transformer 110V De-scaler hose Extension cable 25 litres of DOFFIII descaler DOFFIII hose DOFFIII extension hose... -
Page 8: Extension Cable
O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Connect a water supply to the DOFFIII Water Inlet. Using the DOFFIII Extension Cable (4), connect power supply to the DOFFIII. Please note that the Transformer is for 110V systems only. -
Page 9: Doffiii Hose
O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Connect the DOFFIII Hose to the water outlet. Connect the DOFFIII Trigger to the other end of the DOFFIII Hose (5). -
Page 10: Doffiii Extension Hose
O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Connect the fuel connectors to the DOFFIII Jerry Can. Always use clean, uncontaminated fuel – Diesel, Paraffi n, Kerosene, Heati ng Oil. NEVER PETROL OR GASOLINE To power up the DOFFIII, pull out emergency stop butt on out fully, then press the ON/OFF butt on. -
Page 11: Doffiii Trigger
O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Press the run butt on and pull the DOFFIII Trigger, wait for the water to run clear. Connect the DOFFIII Trigger to Lance (8). - Page 12 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide The DOFFIII Remote Control is designed to operate up to 50 meters from the system. Press butt on 1 to switch on the system and butt on 2 to cool the system and switch it off . In hard water areas, the DOFFIII will require descaling.
- Page 13 O R I G I N A L I N S T R U C T I O N S Quick Setup Guide Connect the Descale Hose (10) and place the other end of the Hose into a bucket. Always remove the Lance before descaling.
-
Page 14: Scaler Hose
N E W F E A T U R E O R I G I N A L I N S T R U C T I O N S DOFFIII Remote Control Start-up or F U N C T I O N S Shutdown from up to The DOFFIII Remote Control is designed to operate up to 50 meters... -
Page 15: Litres Of Doffiii Descaler
N E W F E A T U R E O R I G I N A L I N S T R U C T I O N S Smart Technology The DOFFIII has many built in features to protect the operator and the system such as over- heat, over-pressure and service status. - Page 16 Stonehealth stock a full range of spare parts. Due to the nature of the system, we recommend only using parts supplied by Stonehealth and will need to be fi tt ed by a competent person. D E S C A L E...
- Page 17 O R I G I N A L I N S T R U C T I O N S EC Declarati on of Conformity W H A T D O E S A D E C L A R A T I O N O F C O N F O R M I T Y M E A N ? It is a formal declarati on by a manufacturer, or the manufacturer’s representati ve, that the product to which it applies meets all relevant requirements of all product safety directi ves applicable to that product.
- Page 18 O R I G I N A L I N S T R U C T I O N S EC Declaration of Conformity In accordance with EN ISO 17050-1:2004 Stonehealth Ltd G4/5 Draycott Business Park, Cam, Dursley, Gloucestershire, GL11 5DQ, UK in accordance with the following Directives:...
- Page 19 O R I G I N A L I N S T R U C T I O N S...
- Page 20 Nati onal Trust, English Heritage, Historic Scotland, CADW and other worldwide conservati on bodies. Stonehealth is proud of its reputati on in providing soluti ons with integrity and setti ng new standards...
