StarTech.com 1B-USB-C-CFE-ADAPTER Quick Start Manual

CFexpress Type B to USB-C Reader - 8in (20cm) Cable - USB 3.2 (10Gbps)
Product ID
1B-USB-C-CFE-ADAPTER
1
Component
1
CFexpress Card Slot
2
USB-C Host Connection
3
LED Indicator
Product Information
For the latest drivers/software, technical specifications, and declarations of conformance,
please visit: www.StarTech.com/1B-USB-C-CFE-ADAPTER
3
Function
Insert a CFexpress Card
•
Supports CFexpress Type B Cards
•
Connect to a USB-C Host
•
Supports up to USB 10Gbps
•
Solid White to indicate driver has been installed,
•
and USB connection enumerated
Flashes White to indicate drive activity
•
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/
Requirements
USB-C Enabled Host Device x 1
•
CFexpress Type B Card x 1
•
Package Contents
CFexpress Card Reader x 1
•
2
Quick-Start Guide x 1
•
Installation
WARNING! When removing media cards connected to Card Reader, it is required to
remove/eject the device from within the operating system. Failure to remove storage
devices properly can result in lost data, or permanent damage to the Memory Card or
Card Reader.
Installing the CFexpress Card Reader
Note: This adapter supports CFexpress Type B cards only. If you are unsure if your
memory card is a CFexpress Type B card, please contact the card manufacturer for
more information.
Insert a CFexpress Card into the compatible CFexpress Card Slot.
1.
Connect the USB-C Host Connection to an available USB-C Port on the Host
2.
Computer.
The operating system will detect the CFexpress Card Reader and automatically
3.
install the correct Drivers.
Remove a CFexpress Card
To prevent any potential data corruption or damage to the card, ensure the device
1.
has been removed/ejected from within the operating system.
While holding the CFexpress Card Reader with one hand, gently push the
2.
CFexpress Card into the slot. Once the eject mechanism is engaged, release the
CFexpress Card. The mechanism will push the Card partially out of the slot, making
it easier to remove.
Note: Avoid using excessive force, as this may damage the card or the card reader.
Gently grasp the CFexpress Card firmly with the other hand and gently pull it out of
3.
the slot.
Quick-Start Guide
Manual Revision: April 25, 2024
