ANBAUANLEITUNG
mounting instructions • instructions de montage • instrucciones de montaje • istruzioni di montaggio
BC.HTA.01.740.35900
beinhaltet • contains • contient • contiene • contiene
HTA.01.740.85900/B
BC.HTA.00.740.30000
BC.HTA.00.740.12100/B
BC.HTA.00.740.12200/B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BC.HTA.01.740.35900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SW-Motech BC.HTA.01.740.35900

Summary of Contents for SW-Motech BC.HTA.01.740.35900

  • Page 1 ANBAUANLEITUNG mounting instructions • instructions de montage • instrucciones de montaje • istruzioni di montaggio BC.HTA.01.740.35900 beinhaltet • contains • contient • contiene • contiene HTA.01.740.85900/B BC.HTA.00.740.30000 BC.HTA.00.740.12100/B BC.HTA.00.740.12200/B...

  • Page 2: Safety Warning Symbol

    ~ 0.75 h. EASY DIFFICULT ENGLISH ·Thank you for choosing this premium product from SW-MOTECH. PREPARATION: Read the mounting instructions carefully and make sure Visit our online shop for more information (e.g. model assignments). Required that all parts on the parts list are available.
  • Page 3 Use thread locker: Indicates that a thread must be coated with liquid thread locker. H (HIGH): high strength; M (MEDIUM): medium strength; L (LOW): low strength. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 4 Ø 18 / ø 8,4 / h 22 Ø 18 / ø 8,4 / h 5 SC.ST.08.055.48.912.109 SC.ST.08.050.02.6912.109 US.ST.084.02.125 DB.00.180.082.020.01 DB.00.180.084.022.01 DB.00.180.084.005.01 The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 5 Tighten the screws (5) as specified in the mounting instructions.  CAUTION: Tightening the screws (5) too tightly will damage the plastic parts. × × 2.5 Nm The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 6 Pay attention to the attachment point shown in the detailed drawing. Do not tighten the screws (13) yet. × × × 1.5 Nm × The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 7 MOUNTING STEP · READ AND KEEP MOUNTING INSTRUCTIONS! Remove the original screws shown from the vehicle. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 8  NOTE: HONDA CB500F (16 –), CBR500R (16 –), CB500Hornet (24 –): Install the mounting brackets (1/2) on both sides with the screws (16) and the spacers (19). In combination with the SW-MOTECH luggage rack GPT.01.924.1600*, the rear spacers (19) are no longer required on both sides. In their place, install the spacers (20) with the parts of the luggage rack (*) shown in the detailed drawing.
  • Page 9  WARNING: before starting your journey, check that all components are firmly seated. Remove the connectors (9/10) from the vehicle when driving WITHOUT saddlebags. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 10 TÜV regulations. After assembly, have parts that are subject to registration entered in the vehicle documents by your test centre. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.

  • Page 17: Safety Warning Symbol

    ~ 0.5 h. EASY DIFFICULT ENGLISH ·Thank you for choosing this premium product from SW-MOTECH. PREPARATION: Read the mounting instructions carefully and make sure Visit our online shop for more information (e.g. model assignments). Required that all parts on the parts list are available.
  • Page 18 ASSEMBLY section, the vehicle manufacturer's our online shop: specifications must be observed and applied. www.sw-motech.com The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 19 PARTS LIST · READ AND KEEP MOUNTING INSTRUCTIONS! BC.HTA.00.740.005.02 BC.HTA.00.740.007R.02 BC.HTA.00.740.004R.02 The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 20 Remove the foil from the adhesive surfaces of the adhesive Velcro strip (2) and affix it to the spots indicated along the edge of the Blaze saddlebag. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 21 Loop the Velcro strap (1) onto the rear loop of your Blaze saddlebag. Pull the Velcro strap (1) until taut. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 22  WARNING: Before each ride, check that the heat guard (3) is properly and securely fastened! The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 23 TÜV regulations. After assembly, have parts that are subject to registration entered in the vehicle documents by your test centre. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 24 ~ 0.25 h. EASY DIFFICULT ENGLISH ·Thank you for choosing this premium product from SW-MOTECH. PREPARATION: Read the mounting instructions carefully and make sure Visit our online shop for more information (e.g. model assignments). Required that all parts on the parts list are available.
  • Page 25 ASSEMBLY section, the vehicle manufacturer's our online shop: specifications must be observed and applied. www.sw-motech.com The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 26 PARTS LIST · READ AND KEEP MOUNTING INSTRUCTIONS! BC.HTA.00.740.003.02 The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 27 Thoroughly clean any grease and dirt residues from the determined adhesive positions. Remove the foils from the adhesive surfaces of the abrasion/edge protectors (1). The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 28 Check the correct positioning of the abrasion/edge protectors (1) again once the BLAZE saddlebags have been loaded. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 29 TÜV regulations. After assembly, have parts that are subject to registration entered in the vehicle documents by your test centre. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
