Page 1: Operation Manual
WINDOW TYPE ROOM AIR CONDITIONER OPERATION MANUAL HW-07CK03 HW-09CK03 HW-07LF03 HW-09LF03 Please read this operation manual before using the air conditioner. Please keep it attentively. No.0010550222A... -
Page 2: Table Of Contents
C/26 Outdoor Minimum: 2. If the supply cord is damaged, it must be replaced by the manufacturer or its serviceagent or a similar qualified person. 3. After installation, the power plug should be easily reached. 4. The wiring method should be in line with the local wiring standard. -
Page 3: Part Name
Parts Name Machine body Front panel Air inlet (indoor side) Machine body Air outlet (indoor side) Air inlet (outdoor side) Display panel Power plug Air filter (inside) Operation panel... -
Page 4: Operation Guide
" or " " , the air conditioner will only blow out air without cooling. If the mode selection switch is turned from cooling mode to fan mode, do not turn it back until at least 3 minutes have elapsed. -
Page 5: Operation Guide
Note: It is advisable not to keep horizontal flap at downward position for a long time in COOL or FAN mode, otherwise , condensate water might occur. Don't move the vertical flap with hand in order to avoid the vertical flap abnormal, using the remote controller to adjust the move of vertical flap. -
Page 6: Maintenance
Air filter cleaning (before cleaning, turn off the power) When dirt accumulates on air filter, air circulation will be blocked, which causes poor cooling. It is advisable to clean air filter every two weeks for longer operation. Take out the air filter... - Page 7 2. Block the back hole of the conditioner with rubber lid and install outlet pipe fitting to the bottom hole, which can make the condensed water flow out from the bottom plate. (See Fig.2) If necessary the above two methods can both have extra pipe added on the outlet pipe fitting.
-
Page 8: Maintenance
Maintenance Don't be exposed to cold air for Avoid opening doors and windows a long time. unless necessary. Use curtain or blind Keep heat source away from Direct sunlight may reduce cooling air conditioner. effect, always use window curtain. After unit stops, don't restart it Set temp . -
Page 9: Troubleshooting
Are there any obstacles blocking air inlet and outlet? Is air filter clogged? Remove the heat source Is there too much heat source in the room? If problems can not be solved please pull out power plug and contact your dealer. -
Page 10: Installation Instructions
Avoid places where flammable gas leaks. Problems may occur if unit is installed in the following places: Place where oil exists in the air including engine oil or seaside with salt breeze blows and hot spring area with sulphurous gas in the air. -
Page 11: Installation Guide
(As illustrated in Fig. 1). 2. For the convenience of operation, it is recommended that air-conditioner be installed at least at the height of 760-1300 mm above the floor and no obstacles before it for a free airflow. -
Page 12: Installation Guide
Installation Guide Installation of air-conditioner (only for reference) Iron frame 1. Make the wall hole or window hole (see Fig.1) . 2. Fix the prefabricated iron frame to stable position by expansible screws. 3.Take out the conditioner and accessories Width of the wall from the package .
