Page 1: Operation Manual
WINDOW TYPE ROOM AIR CONDITIONER OPERATION MANUAL Please read this operation manual before using the air conditioner. Please keep it attentively. No.0010515220 HW-07LM13 HW-07LM03 HW-09LM13 HW-09LM03 HW-12LM13 HW-12LM03... -
Page 2: Table Of Contents
Contents Contents ... 2 Part Name ... 3 Operation Guide ... 4-5 Maintenance ... 6-8 Trouble shooting ... 9 Installation Instructions ... 10 Installation Guide ... 11-12 The machine is adaptive in following situation: 1. Applicable ambient temperature range: Indoor Cooling Outdoor 2. -
Page 3: Parts Name
Parts Name Machine body Operation panel Front panel Air inlet (indoor side) Machine body Air outlet (indoor side) Air inlet (outdoor side) Display panel Power plug Air filter (inside) MINI COOL COOL WAIT THREE MINUTES BEFORE RESTARTING HIGH HIGH COOL COOL... -
Page 4: Operation Guide
Hint When the mode selection switch is turned to "HIGH FAN" or "LOW FAN" , the air conditioner will only blow out air without cooling. If the mode selection switch is turned from cooling mode to fan mode, do not turn it back until at least 3 minutes have elapsed. -
Page 5: Operation Guide
Otherwise, the fuse may blow due to overload. Do not exceed the selection range. This switch controls the preset indoor temperature to make the air conditioner start or stop automatically, so as to reduce power consumption and operate the system both comfortably and economically. -
Page 6: Maintenance
Maintenance Air filter cleaning (before cleaning, turn off the power) When dirt accumulates on air filter, air circulation will be blocked, which causes poor cooling. It is advisable to clean air filter every two weeks for longer operation. Take out the air filter 1.Press the concave parts on both sides at the lower part of air inlet grille to open the air inlet grille. - Page 7 Maintenance Disposal of the condensed water Generally there are two methods available on disposal of the condensed water: 1. Block the bottom plate hole of the conditioner with rubber lid, install back hole and let the condensing water flow from the back hole of the conditioner. (See Fig.1 ) In this method, the accumulated condensed water in the bottom plate is hit by the fan onto the heat exchanger, and evaporated and blown out from the machine.
-
Page 8: Maintenance
Set temp . a little bit higher before going to bed. Proper temperature Don't be exposed to cold air for a long time. Keep heat source away from air conditioner. After unit stops, don't restart it until 3 min. have elapsed. OK! Enjoy a 3-min nap... -
Page 9: Troubleshooting
Troubleshooting Doesn't work Is plug firmly inserted? Is there power failure? Does fuse get burned? Is thermostat switch wrongly adjusted? No cool air or poor cooling Is there any direct sunlight in the room? Are doors or windows left open? Are there any obstacles blocking air inlet and outlet? -
Page 10: Installation Instructions
Installation Instructions Don't hang clothes in the vicinity of air inlet. This will decrease cooling effect and cause abnormal operation. G o a w a y ! For longer and trouble-free operation of the unit, pay special attention to the following: Install air-con at a place strong enough to support the unit. -
Page 11: Installation Guide
Installation Guide Selection of the installation position 1. The air-conditioner is better installed in shadow or in a place with short period of sunshine. In case the air-conditioner is installed at the point exposed directly to the sunshine, it should be protected from the direct sunlight as possible in order to avoid the long time of direct sunlight otherwise its performance will be lowered. -
Page 12: Installation Guide
Installation Guide Installation of air-conditioner 1. Make the wall hole or window hole (see Fig.1) . 2. Fix the prefabricated iron frame to stable position by expansible screws. 3.Take out the conditioner and accessories from the package . Cooling-only type air-conditioner: before dispatched from the factory, the drip hole at the bottom plate has been blocked by rubber lid in the accessories.
