Marco 3B MIX FONT Quick Start Manual

MIX UNDERCOUNTER HOT WATER
WITH 3B FONT
> Space-saving countertop font
>
Vacuum insulated tank for up to 70% more
energy-efficiency
3B MIX FONT
1000879
MIX UC3
1000880
FONT SPECS
NAME DIMENSIONS INCL. DRIP TRAY
ORDER CODE
3b MIX Font
1000879
BOILER SPECS
PRODUCT INFO WATER TYPE
NAME
MULTI-TEMP
ORDER CODE
MIX UC3
1000880
Y
MIX UC8
1000887
PACKAGING
NAME PACKAGING DIMENSIONS
ORDER CODE
3b MIX Font
1000879
MIX UC3
1000880
MIX UC8
1000887
For more information visit www.marcobeveragesystems.com
(D x W x H mm)
168 x 120 x 287
SIZE DIMENSIONS
ADJUSTABLE DIMENSIONS
TEMP (D x W x H mm)
385 x 210 x 444
Y
385 x 210 x 617
(L x W x H mm)
290 x 570 x 215
450 x 290 x 540
450 x 290 x 700
> Dispense three volumes and three temperatures
from one boiler
DIMENSIONS
138
MIX UC8
1000887
OR
DIMENSIONS EXCL. DRIP TRAY
(D x W x H mm)
138 x 30 x 287
PERFORMANCE SPECS
IMMEDIATE
L/HR
DRAW OFF
3L
28L
8L
PACKED WEIGHT
2kg
11kg
14kg
SYSTEM SET - UP
TAP TO COUNTER
(T mm)
247
PLUMBING & ELECTRICAL REQS
CUPS POWER PLUMBING
/HR @220v REQS
156 2.8kW 3/4" BSP
QTY / PALLET
30
24
18
