Marco FRIIA HCS Manual

FRIIA HOT/COLD/SPARKLING
>
Sleek, stylish font
combining hot/cold/
sparkling water
>
0.8 or 2.1 GAL boiler
option
CHILLER/CARBONATOR
PRODUCT INFO SIZE
NAME DIMENSIONS
( D X W X H inches )
ORDER CODE
Chiller/
Carbonator 17.1 x 10.2 x 17.9
1000861US
PRODUCT INFO SIZE
NAME DIMENSIONS
ORDER CODE ( D X W X H inches )
MIX UC3 - 220v
1000880US
15.1 x 8.2 x 17.4
MIX UC3 - 110v
1001880US
MIX UC8 - 220v
15.1 x 8.2 x 24.2
1000887US
FRIIA HCS FRIIA HCS PLUS
DIMENSIONS
NAME
INC. DRIP TRAY
ORDER CODE
( D X W X H inches )
3b Font
6.6 x 4.7 x 11.2
1000862
For more information visit www.marcobeveragesystems.com
ORDER CODES
> FRIIA HCS
> FRIIA HCS Plus
BOILER
PERFORMANCE SPECS
CUPS
GAL/HR
/HR
7.9-11.8 GALS/hr based
175-235
on incoming water temp
(ΔT =
of 59°F and output
18 °F)
water temp of 41-44°F
PERFORMANCE SPECS
IMMEDIATE
GAL/HR
DRAW OFF
7.3 GAL
0.8 GAL
3.6 GAL
2.1 GAL
FONT DIMS
5.4
DIMENSIONS
EXCL. DRIP TRAY COUNTER
( D X W X H inches )
5.4 x 1.1 x 11.2
(Complete bundle)
1000865US/1001865US
(220/110v)
1000867US
SYSTEM SET - UP
PLUMBING, ELECTRICAL AND TECHNICAL SPECS
POWER PLUMBING COMPRESSOR
@110V REQS POWER
3/8"
Compression
180W 1/8hp
or 3/8" John
Guest
PLUMBING & ELECTRICAL REQS
CUPS/HR POWER
2.8kW
@ 220v
1.4kW
75
@ 110v
2.8kW
@ 220v
NAME
Fonts (all)
Chiller
MIX UC3 -
220v/110v
MIX UC8 -
220v
TAP TO
PLEASE
NOTE
( inches )
9.7
CHARGE REFRIGERANT
45g R290
PLUMBING
NEMA
REQS
L6-20P
3/8"
Compression
5-15p
or 3/8" John
Guest
L6-20P
PACKAGING
DIMENSIONS WEIGHT
(L x W x H inches)
11.4 x 22.4 x 8.4 4.4lbs
19.2 x 11.8 x 20.2 69.4lbs
17.7 x 11.4 x 21.2 25lbs
17.7 x 11.4 x 27.5 30.8lbs
FRIIA components (font, boiler and
chiller) are packed and shipped in
individual boxes. FRIIA Sparkling
variants require food-grade CO
2
(not supplied by Marco).
