Aruba Networks AP-OUT-MNT-V1A Installation Manual

AP-OUT-MNT-V1A Mount Kit
The AP-OUT-MNT-V1A mount kit can be used for mounting an outdoor AP to a wall or pole.
Package Contents
Table 1: Package Contents
Item
AP-OUT-MNT-V1A Mounting bracket
M6 x 20 screw
60 cm cable tie
6 inches hose clamp
Customer Supplied Equipment
#1 Phillips screwdriver
n
Electric drill with drill bits
n
Anchor bolts, washers, and nuts
n
Mounting the AP to a Wall
To mount an access point to a wall, follow these steps:
1. Use the mounting bracket as a template, or the dimensions of the mounting bracket on the last
page of the printed installation guide, to mark four mounting points on the wall.
2. Use a drill to make four holes on the four markings from the previous step.
3. Insert an anchor bolt (not included in the package) into each drilled hole.
4. Place the mounting bracket over the anchor bolts and press the bracket against the wall.
5. Place the washers and nut (not included in the package) onto the bolt's threaded end and tighten
the nut until the mounting bracket is firmly attached to the wall.
AP-OUT-MNT-V1A Mount Kit | Installation Guide
AP-OUT-MNT-V1A Mount Kit
Quantity
1
2
1
2
Installation Guide
1
