- Page 1 INSTRUCTION MANUAL Cordless Auto Feed Screwdriver DFR540 DFR550 DFR750 Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model DFR540 DFR550 DFR750 Screw strip 4 x 25 - 55 mm 4 x 45 - 75 mm No load speed (min 4,000 Overall length 424 mm 464 mm Net weight 2.0 - 3.0 kg 2.1 - 3.1 kg 2.1 - 3.2 kg... - Page 3 When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.
-
Page 4: Cordless Screwdriver Safety Warnings
12. Use the batteries only with the products Always secure workpiece in a vise or similar specified by Makita. Installing the batteries to hold-down device. non-compliant products may result in a fire, exces- sive heat, explosion, or leak of electrolyte. SAVE THESE INSTRUCTIONS. -
Page 5: Functional Description
FUNCTIONAL CAUTION: Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that DESCRIPTION have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and CAUTION: charger. • Always be sure that the tool is switched off and Tips for maintaining maximum the battery cartridge is removed before adjust- ing or checking function on the tool. battery life Installing or removing battery cartridge Charge the battery cartridge before completely discharged. - Page 6 See the table below for the relation between the number indicated on the label on feeder box and the respective screw length. For Models DFR540, DFR550 Number indicated on the label Screw length 25 mm...
- Page 7 Adjusting the driving depth Reversing switch action ► 1 . Stopper base 2. Casing 3. Adjusting knob ► 1 . Reversing switch lever Depress the stopper base as far as it will go. While This tool has a reversing switch to change the direction keeping it in this position, turn the adjusting knob until of rotation. Depress the reversing switch lever from the the bit tip projects approx. 5 mm from the stopper base.
- Page 8 Press the dust cover toward the plane bearing and pull Removing screw strip out the bit. If the dust cover cannot be moved as far as the plane bearing, try it again after turning the bit To remove the screw strip, just pull it out in the direction slightly. of the arrow. If you depress the reverse button, you can To install the bit, insert it into the socket while turning it pull out the screw strip in the reverse direction of the slightly. After installing, always make sure that the bit is arrow.
-
Page 9: Driving Operation
Carry hook CAUTION: • Always check the bit carefully for wear before The carry hook is convenient for temporarily hooking driving operations. Replace a worn bit or poor the tool. It can be installed on either side of the tool. fastening may result. When removing the carry hook, widen it by pressing its • Always hold the tool squarely against the driving right ends ON BOTH SIDES in the directions of arrow surface. Holding it at an angle may damage the (1) and raise it in the direction of the arrow (2). screw heads and cause wear on the bit. This may also lead to poor fastening. -
Page 10: Replacing Carbon Brushes
► 1 . Front cover 2. Screws any other maintenance or adjustment should be per- formed by Makita Authorized Service Centers, always Raise the arm part of the spring and then place it in the using Makita replacement parts. recessed part of the housing with a slotted bit screw- driver of slender shaft or the like. 10 ENGLISH... -
Page 11: Optional Accessories
OPTIONAL ACCESSORIES CAUTION: • These accessories or attachments are recom- mended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regard- ing these accessories, ask your local Makita Service Center. • Drywall screw strip • Phillips bit • Various type of Makita genuine batteries and chargers • Plastic carrying case NOTE: • Some items in the list may be included in the tool package as standard accessories. They may differ from country to country. 11 ENGLISH... - Page 12 Makita Corporation 885286A5 20170825 www.makita.com...
