Desisti SUPER LED F10HP Instruction Manual

330w led fresnel spotlight 90-240v 50-60 hz
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

SUPER LED F10HP
330W LED Fresnel SPOTLIGHT 90-240V 50-60 Hz
(white light, either Tungsten or Daylight balanced Correlated Color Temperature)
INSTRUCTION MANUAL
Manual Operated
Pole Operated
MANUFACTURER
REPRESENTATIVE
ILT Italy S.r.l.
Via Cancelliera # 10a, 00041 Albano Laziale (Rome- Italy).
Tel. +39/06/902901 Fax. +39/06/90231051
desisti@desisti.it
U.R.L.: www.desisti.it
E-mail:
1. INTRODUCTION
Congratulations on your purchase of a SUPER LED F10 HP lighting fixture.
Our commitment to Total Customer Satisfaction and our consolidated experience and leadership in design innovation and
manufacturing of lighting products for the professional Entertainment Industry means you can depend upon the quality of this product.
The SUPER LED F10 HP is a compact, highly efficient Fresnel lens spotlight using a LED ARRAY combined with the DE SISTI
Patented optical system to optimize the photometric performances of LED ARRAYS when utilized in combination with either Fresnels
or Plano Convex lenses.
The Lighting Fixture is DMX Controlled and includes a number of parameters that can be set locally, it is equipped with power supply
for AC feed (90-240V 50-60Hz) and it is available with either Tungsten or Daylight Balanced CCT with high power and high CRI.
It utilizes Standard accessories from the DE SISTI range of equivalent Fresnel Lens size, such as Barndoor, Colour Frame, Cones,
scrims.
2. YOKE AND ACCESSORIES ASSEMBLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUPER LED F10HP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Desisti SUPER LED F10HP

Summary of Contents for Desisti SUPER LED F10HP

  • Page 1 SUPER LED F10HP 330W LED Fresnel SPOTLIGHT 90-240V 50-60 Hz (white light, either Tungsten or Daylight balanced Correlated Color Temperature) INSTRUCTION MANUAL Manual Operated Pole Operated MANUFACTURER REPRESENTATIVE ILT Italy S.r.l. Via Cancelliera # 10a, 00041 Albano Laziale (Rome- Italy).
  • Page 2 Super LED F10 HP Manual Operated 3. POWER AND DMX DAISY CHAIN The SUPER LED F10 HP permits both POWER and DMX DAISY CHAIN. In fact each Fixture is respectively equipped with: For DMX: • 1 XLR5 pin Panel Mount Male (DMX IN)

  • Page 3: Safety Instructions

    • 1 XLR5 pin Panel Mount Female (DMX OUT) For Mains Supply • 1 20A Powercon NAC3MPA BLUE (POWER IN) • 1 20A Powercon NAC3MPB WHITE (POWER OUT) It is recommended to Daisy Chain a Max of 10 fixtures, even if the limitations imposed by DMX Standards are for an higher q.ty of units and even if the Powercon Connections are rated for 20A max.

  • Page 4: Installation Instructions

    The luminaire should never be OPERATED close to inflammable materials. The ones indicated in the above table are the minimum distances recommended. Other requirements for safe use are: A. Do not cover the apertures of the luminaire housing. They are essential for correct ventilation. B.

  • Page 5: Dmx Address

    2nd menu displayed Explanation of each menu function 1st menu displayed DMX ADDRESS This Function is to SET the DMX address from 1 to 512 The Product is delivered with a default setting of the DMX address at 1. As indicated next to each picture, it is required to reach the DMX addr Menu, select the preferred base DMX Address and Select Once the DMX Address is SET, in order to return to the MAIN MENU, it is necessary to rotate KNOB 2 counter-clock-wise to...
  • Page 6 CHANNEL SETTING (RESOLUTION & FUNCTION) This function is to SET THE DIMMING RESOLUTION either at 8 bits or at 16 bits. Select DMX resol by rotating and pushing KNOB2, the following choices are available: - 8 bits resolution (the display will show 8 bit). The fixture utilizes 1 DMX Circuit for the Light Dimming, which is the BASE CIRCUIT set in the ADDRESS.

  • Page 7: Periodic Inspection & Maintenance

    9. PERIODIC INSPECTION & MAINTENANCE This product requires very little routine maintenance, if any, but has special cleaning instructions: Disconnect fixture from power and allow it to cool for 10 min. 1. Vacuum or gently blow away any dust from fan blades and grills 2.
