Desisti SOFT LED 1 Instruction Manual

60w led softlight 90-250v 50/60 hz

Advertisement

SOFT LED 1
60W LED SOFTLIGHT 90-250V 50/60 Hz
(white light, either Tungsten or Daylight balanced)
INSTRUCTION MANUAL
Manual Operated
(Pole Operated available, not shown)
MANUFACTURER
REPRESENTATIVE
ILT Italy S.r.l.
Via Cancelliera # 10a, 00041 Albano Laziale (Rome- Italy).
Tel. +39/06/902901 Fax. +39/06/90231051
U.R.L.: www.desisti.it
E-mail:
desisti@desisti.it
1. INTRODUCTION
Congratulations on your purchase of a SOFT LED 1 lighting fixture.
Our commitment to Total Customer Satisfaction and our consolidated experience and leadership in design innovation and manufacturing of
lighting products for the professional Entertainment Industry means you can depend upon the quality of this product.
The SOFT LED 1 is a innovative Remote Phosphors 60W LED SOFTLIGHT, with a COLOR RENDERING INDEX – CRI higher than 95 for the Tungsten
CCT and for the Daylight CCT; it provides a smooth and soft shadow projecting beam, yet within a controlled field that makes it ideal for multiple
camera set ups.
The Lighting Fixture is DMX Controlled and includes a number of parameters that can be set locally, it is equipped with either a 90-250V
50/60Hz power supply for AC feed and the front Remote Phosphors Panel is easily interchangeable and it is available with either Tungsten or
Daylight Balanced CCT.
Standard accessories are available such as Black or White Honeycombs with either narrow or medium cells for different beam shaping and
control, Colour Frame, Beam Intensifier and a special yoke for multiple fixtures configuration, for background lighting applications.
This Manual is applicable to Soft LED1
Revised August 2018
