- Page 1 AUTOOL SDT50 Smoke Leak Detector User Manual www.autooltech.com...
- Page 2 AUTOOL TECHNOLOGY CO.,LTD www.autooltech.com aftersale@autooltech.com +86-755-2330 4822 / +86-400 032 0988 Hangcheng Jinchi Industrial Park, Bao’an, Shenzhen, China Corporate Standard: Q/OR 006-2023...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Copyright Information..................2 Copyright......................2 Trademark ....................... 2 Cautions ......................3 Warning ......................3 Product Introduction ..................4 Overview ......................4 Working theory....................4 Features ......................4 Technical parameter..................5 Product Structure ....................5 Structure diagram.................... 5 Operations Instruction .................. -
Page 4: Copyright Information
COPYRIGHT INFORMATION Copyright ● All rights reserved by AUTOOL TECH. CO., LTD. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of AUTOOL. -
Page 5: Cautions
CAUTIONS Warning Before using the instrument, please read this manual careful- ly for proper operation. If you are not a technician, please do not change, disassemble or repair the product; otherwise all the losses shall be borne by the user. This product is powered by electricity and should not be used as a toy for children. -
Page 6: Product Introduction
PRODUCT INTRODUCTION Overview AUTOOL SDT50 smoke leak detector is an entry-level automotive pipeline leak detection tool, which can accurately detect various leaks in the automotive pipeline system, helping maintenance technicians to quickly locate leaks and solve problems. Working Low oxygen combustion theory ●... -
Page 7: Technical Parameter
Technical Power Supply DC 12 V parameter Test Oil Filling Volume 10-20 ml Rated Output Pressure ＜10 psi Rated Output Flow ＜5 L/min Rated Power Product Weight 1.5kg 2.5 kg Gross Weight PRODUCT STRUCTURE Structure diagram Filling port Smoke indicator Smoke control switch Hook port Power socket... -
Page 8: Operations Instruction
If the test oil is overfilled, turn the device upside down to drain out part of the oil. ● Start using the SDT50 after the first two steps. ● Detail Fit the smoke hose to the smoke outlet (F) and the power cord operation to the power socket (E). -
Page 9: Operation Guidelines For Automobile Pipeline Inspection
use in case the detector is not used for a long time. Operation Turn off the engine ignition switch. ● guidelines NOTE for automo- bile pipeline All leak detection of automobile piping systems must be inspection performed with the engine turned off. ●... -
Page 10: Description Of Accessories
1 pc pipeline There is a volume scale for Oil Filling Bottle 1 pc checking filling amount Hook 1 pc For install the unit Product related operation AUTOOL SDT50 Smoke Leak Detector User manual 1 pc User Manual instructions www.autooltech.com... -
Page 11: Maintenance Service
MAINTENANCE SERVICE Our products are made of long-lasting and durable materials, and we insist on perfect production process. Each product leaves the factory after 35 procedures and 12 times of testing and inspec- tion work, which ensures that each product has excellent quality and performance. -
Page 12: Warranty
Disclaimer All information, illustrations, and specifications contained in this manual, AUTOOL resumes the right of modify this manual and the machine itself with no prior notice. The physical appearance and color may differ from what is shown in the manual, please refer to the actual product. -
Page 13: Return & Exchange Service
RETURN & EXCHANGE SERVICE ● If you are an AUTOOL user and are not satisfied with the Return & AUTOOL products purchased from the online authorized Exchange shopping platform and offline authorized dealers, you can return the products within seven days from the date of receipt;...
