Rear Panel Overview
Supplying Power to
the Keypad
Connecting Multiple Keypads
RJ45-RS232 port
RJ11 future
RJ45-data and power
RS485 termination switch
(only the two end
devices of the RS485 bus should have
termination on)
RJ45 connector cable*
RJ45 I/O box
RS485 A
RS422 in B
RS485 B
RS422 in A
12 VDC power
RS422 out B
12 VDC power
RS422 out A
12 VDC / 1 A power supply
*Use only the RJ45 cable provided with the keypad. If
the cable needs to be replaced, refer to the KTD-405
Manual.
Connecting a
Multiplexer or DVMR
and Domes
PMB 225, PO Box 3004
Corvallis, OR 97339
800-469-1676 between 7 a.m. and
5 p.m Pacific time, Monday through
Friday. If calling from Oregon,
dial 541-754-9133
1036558B
Quick Reference
Quick Reference
Guide
Guide
KTD-405
Controller Keypad
