Model:
BUILT-IN INDUCTION HOB
HB BI 293 G
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HB BI 293 G and is the answer not in the manual?

Questions and answers

Related Manuals for EF HB BI 293 G

Summary of Contents for EF HB BI 293 G

  • Page 1 Model: BUILT-IN INDUCTION HOB HB BI 293 G USER MANUAL...

  • Page 2: Safety Guidelines

    Dear Customer, Thank you for having purchased and given your preference to our product. This manual provides a means to make full use of the features of this product. The safety precautions and recommendations are also featured in this manual. We recommend that you read this manual for best performance and to extend the life of your appliance.
  • Page 3 Important Safety Instructions • After having unpacked the appliance, check to ensure that it is not damaged. • No combustible material or products should be placed on this appliance at any time. • In order to avoid hazard, this appliance must be installed according to the instructions for installation.
  • Page 4 • Do not let your body, clothing or any item other than suitable cookware contact the ceramic glass until the surface is cool down. • Children less than 8 years of age shall be kept away unless continuously supervised. • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot.
  • Page 5 • WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g., with a lid or a fire blanket. •...
  • Page 6 W(mm) H(mm) D(mm) A(mm) B(mm) X(mm) HB BI 293 G Selection of Installation Equipment • The cooktop must be housed in heat-resistant work surface to avoid large deformation caused by the heat radiation. • Cut the work surface according to the dimension shown in the above table (Fig.1) •...
  • Page 7 Fig.2 E (Air Exit) 650 mm Min 50 mm Min 30 mm Air Intake Min 5mm Front View Note: The safe distance between the cooktop and any wall cupboard or cooker hood positioned immediate above the cooktop should be at least 650mm.

  • Page 8: Securing The Hob

    • An approved isolating switch providing full disconnection from the main power supply is incorporated in the permanent wiring, mounted and positioned to comply with the local wiring rules and regulations. • The isolating switch will be easily accessible to the customer with the hob installed.

  • Page 9: Electrical Connection

    Installing the hob into the work surface Place the hob into the cut-out hole and position it properly gently apply downward pressure on the hob to push it into the cut-out hole. Glass Retaining bracket Screw ST 3.5*8 Worktop Bo�om ELECTRICAL CONNECTION The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker.

  • Page 10: Product Overview

    Advice for User PRODUCT OVERVIEW HB BI 293 G Ø 160mm / 1200 W zone Ø 180mm / 1700 W zone 3. Control panel CONTROL PANEL 1. Timer Key 2. Decreasing Key (power or timer) 3. Increasing Key (power or timer) 4.

  • Page 11: Use Of Induction Hob

    USE OF INDUCTION HOB Before using the induction hob, read this manual carefully and take note on the “Safety Guidelines” section. Remove any protective film that may still be on the induction hob Induction Cooking System Induction cooking is a safe, advanced, efficient, and economical cooking technology. When cooking zone is selected, the electromagnetic circuit produce induced currents that instantly heat the bottom of the cookware which then transfer heat directly to the food.
  • Page 12 • The cooking zone will not operate if the cookware diameter is too small (the symbol “ ” will appear on the display. Follow the recommended cookware diameter given in the following table to correctly use the cooking zone. Minimum cookware diameter Cooking Zone (mm) recommended Ø...
  • Page 13 TOUCH CONTROL This appliances comes with touch control system. Do take note on the following before using the hob. Note: • The control responds to touch, so you don’t need to apply any pressure. • Use the ball of your finger, not the tip. •...

  • Page 14: Operation

    OPERATION TIME LIMIT OF THE COOKING ZONE Each cooking zone is switched off automatically after a maximum preset time if no further operation is performed. The maximum preset time limit depends on the set power level and the default cooking times are shown in the table below: Power Level Operation Time Limit (hour)
  • Page 15 TO END COOKING Select the cooking zone that you wish to turn off by tapping the relevant hea�ng zone, thenset the power level to " 0 " or you can tap the relevant ON/OFF control to switch off both zone . Note Beware of hot surfaces! “H”...
  • Page 16  As a minute minder - the timer will not turn any cooking zone off when the set time is up. It works as a reminder or alarm.  As an automatic switch off timer - to turn the cooking zones off after the set time is up.
  • Page 17 Using the Timer as Automatic Switch Off Timer 1. Select the heating zone and set the desired power level. “ ” by 10 minutes 2. Tap the timer key on the selected zone, the timer display default and the second digit “0” will start blinking (Each single digit has to be configured individually).
  • Page 18 HEAT SETTING Heat Setting Suitability • Delicate warming for small amounts of food 1 - 2 • Melting chocolate, butter and food that burn quickly • Gentle simmering • Reheating 3 - 4 • Simmering • Slow boiling 5 - 6 •...

  • Page 19: Care And Maintenance

    CARE AND MAINTENANCE Problem Action Remarks Switch off the main power of • When the power of the cooktop is the cooktop. switched off, there will be no ‘hot Apply a cooktop cleaner while surface’ indication but the cooking the glass is still warm (but not zone may still be hot! Take extreme Soiling on glass hot!)

  • Page 20: Troubleshooting

    TROUBLE SHOOTING Problem Possible causes Action • No power. • Make sure the cooktop is connected to the power The cooktop cannot be supply and is switched on. turned on. • Check whether there is power outage • The controls are locked. •...
  • Page 21 The induction hob or a • Technical fault. cooking zone switch off • Please note down the error unexpectedly, an code, switch off the main acoustic signal sounded power of the induction hob and an error code is and contact customer service displayed (typically center.

  • Page 22: Failure Display And Inspection

    FAILURE DISPLAY AND INSPECTION The cooktop is fitted with safety devices to protect the electronic system and if an abnormality occurs, the cooktop will enter into protective state automatically and the following error codes will show: Problem Possible Causes Action Signal Lost (PCB Contact customer service centre Failure)

  • Page 23: Technical Specification

    TECHNICAL SPECIFICATION Model No: HB BI 293 G Cooking Zones Electric Supply 220-240V~ / 50-60Hz Total Electric Power 2900W Product Dimensions L x W x H 310mm x 520mm x 62mm Built-In Dimensions L x W 270mm x 490mm This appliance is labeled in compliance with European directive 2012/19/EU for Waste Electrical and Electronic Equipment (WEEE).

  • Page 24: Warranty And Service

    WARRANTY AND SERVICE  To activate your warranty, please register your appliance.  Warranty registration can be done via our website or scan the QR code below Website https://shop.casa.sg/E-Warranty QR Code Scan the QR Code below. It will redirect straight to our “Warranty Registration” page.
