USER MANUAL
Updated to 4.3.xR software version
(where x indicates all 4.3 software versions)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G7 and is the answer not in the manual?

Questions and answers

Related Manuals for Farmnavigator G7

Summary of Contents for Farmnavigator G7

  • Page 1 USER MANUAL Updated to 4.3.xR software version (where x indicates all 4.3 software versions)
  • Page 2 2.1.7 TASKS ISOXML 3.2.4 Headland 2.2 New Job 3.2.5 Obstacles 2.3 Continue / Close Last Job 3.2.6 Auto Steering system (For G7 Plus 2.4 Setup and G7 Iso) 2.4.1 Satellites 3.2.7 Nudge 2.4.2 GPS antenna position on the tractor 31 4.

  • Page 3: Table Of Contents

    6.1.2 NTRIP Configuration 6.2 NTRIP Configuration for Turtle RTK or third-party receivers 6.2.1 GPS fix check 6.2.2 NTRIP Configuration 6.3 G7 software updates 6.3.1 Software Update via WiFi (G7 Plus, G7 Terminal and G7 Iso) 6.3.2 Software Update via USB 6.4 Video camera 6.4.1 Type of supported cameras 6.4.2 Connect a video camera 6.4.3 Display mode for Video camera...
  • Page 4 - Use ground compensation function; - Connect ISOBUS equipment (with Iso Kit). 1.2 Electrical connections G7 is provided with a bracket and a wiring with connectors to ensure an easy and safe installation on your tractor. Wiring harness consists of a 2A protection fuse.
  • Page 5 For ISOBUS systems (G7 Terminal, G7 ISO, Iso Kit) an additional cable is included for connecting the G7 Farmnavigator to the tractor’s ISOBUS In-Cab socket. IN-CAB Figure 1.2.b - ISOBUS In-Cab connection diagram 1.3 How to install a FARMNAVIGATOR antenna The procedure described below refers to the Turtle series and All in One series.
  • Page 6 If you use an antenna with ground compensation, the orientation of the antenna relative to the direction of travel of the vehicle is key. For FARMNAVIGATOR products, the orientation is defined by the position of the antenna connector, and it must be opposite to the forward direction of the vehicle. Follow the instructions in the antenna package for more details. FARMNAVIGATOR G7 – User Manual...
  • Page 7 Figure 1.3.5.a How to install the antenna – Orientation 1.4 Turning the device on Before turning G7 on, make sure the display is connected to the bracket. Check that the bracket is firmly anchored to the tractor and that the power cable is plugged into 12V socket. Figure 1.4.a - Turning on the display 1.
  • Page 8 ATTENTION: a reset of the device might cause data loss. 1.5 How to use multi-touch display G7 is provided with a multi-touch display which allows you to perform specific actions with your fingers. Tap the screen to select a button from the menu.
  • Page 9 The main menu shows the basic operations for the creation of a new job, system setup, the creation of a new implement, the connection to an ISOBUS implement and the connection to MyFarmnavigator cloud. Figure 2.0 - Main menu 2.1 DATABASE Figure 2.1 - DATABASE menu FARMNAVIGATOR G7 – User Manual...
  • Page 10 G7 functions are designed to save and precisely organize all the information relating to each single job. It is advisable to enter data from the outset, in order to fully exploit all the advantages of this technology. Through DATABASE menu, it is possible to manage all your data (insertion, visualization, editing, elimination, exportation).
  • Page 11 It is essential to save FARMERS name. FARMERS refer to all customers or landowners. If a company has the ownership of all the worked lands, insert the name of the company in the FARMERS section: FARMNAVIGATOR G7 – User Manual...
  • Page 12 3. Tap the green arrow in the upper left corner of the screen to go back to the previous page. Figure 2.1.2 - List of farmers 2.1.3 FIELDS Figure 2.1.3 - List of fields associated with farmers or others FARMNAVIGATOR G7 – User Manual...
  • Page 13 4. Tap the green arrow in the upper left corner of the screen to go back to the previous page. 2.1.4 PRODUCTS G7 allows you to create a list of products and save their use after each activity. 1. Select “Add New”;...
  • Page 14 Figure 2.1.6.a - IMPLEMENTS menu Figure 2.1.6.b - Implement name 3. If active, select the external controller type. Select “No section control” to use the implement without section control. FARMNAVIGATOR G7 – User Manual...
  • Page 15 5. If the implement is mounted, tap “REAR FIX MOUNT”; - Offset 1 refers to the distance between the posterior axle and the implement operating point; - Offset 2 refers to an eventual misalignment between the implement and the centre of the tractor. FARMNAVIGATOR G7 – User Manual...
  • Page 16 - Offset 1 is the distance between the posterior axle and the junction; - Offset 2 is the distance between the junction and the implement operating point; - Offset 3 refers to a possible misalignment between the implement and the centre of the tractor; FARMNAVIGATOR G7 – User Manual...
  • Page 17 Figure 2.1.6.h - Working width setting 9. Tap “Working width”, insert implement width, and select “OK”; 10. Tap “Minimum turning radius” and insert the turning value indicated in the tractor registration certificate, and select “OK”; FARMNAVIGATOR G7 – User Manual...
  • Page 18 Below the lower limit, the color of the area will be yellow instead of green. Above the upper limit, the color of the area will be blue instead of green. Figure 2.1.6.k - Activation and definition of working speeds FARMNAVIGATOR G7 – User Manual...
  • Page 19 The TASKS ISOXML section contains all the activities carried out with ISOBUS equipment. TASKS ISOXML contain information about the Field, Tool, Product and Variable Rate to apply. These activities can be created remotely and imported into G7 in the standard ISOXML format via USB (read chapter 5.4 ‘Importing a map in ISOXML format’).
  • Page 20 It is then possible to activate the activity (i.e. make it available for the ISOBUS equipment) by pressing the “Activate” button. At this point the activity is enabled and all the details are visible. Figure 2.1.7.b - Task data page FARMNAVIGATOR G7 – User Manual...
  • Page 21 To create a new job in fast mode, that is without entering all the working parameters and starting with your job: 1. Select “START NEW JOB”; Figure 2.2.a - Start new job page 2. Select the implement from the “IMPLEMENT” line, tapping the downward green arrow; FARMNAVIGATOR G7 – User Manual...
  • Page 22 Figure 2.2.b - List of implements 3. Select the name of the implement; 4. Select “OK” to switch to the job page; Figure 2.2.c - Job page FARMNAVIGATOR G7 – User Manual...
  • Page 23 A-B parallel guidelines Tap this icon to work with A-B parallel guidelines. Table 2.2.a - A-B straight lines - Tap the icon to save point A; - Proceed few metres straight ahead to save point B; FARMNAVIGATOR G7 – User Manual...
  • Page 24 Smart cursor The smart cursor is provided with two lines. It helps user to maintain the tractor aligned with the direction of the A-B guideline. Table 2.2.b - Distance from guideline and smart cursor FARMNAVIGATOR G7 – User Manual...
  • Page 25 2.3 Continue / Close Last Job G7 allows you to continue the last job, accessing it directly from the Main Menu: 1. Select “CONTINUE LAST JOB” from the main menu; 2. This page shows you all the information about your last job. Select “OK” to confirm;...
  • Page 26 At the end of a job, it is possible to manually close the job in progress by touching the “CLOSE JOB” button. Figure 2.3.d Main menu - Close Job If the job is not closed manually, G7 allows you to continue the last job carried out as mentioned above.
  • Page 27 Find here the info calculated by the GNSS receiver, the map with the position of the satellites and, for RTK receivers, the Latency (delay compared to the last RTK correction), Base ID (identification number of the RTK base) and Estimated Err are highlighted (estimated error in the positioning in meters). FARMNAVIGATOR G7 – User Manual...
  • Page 28 This value should be changed to lower values near 0 km / h only if RTK receivers are used. ATTENTION: do not change this parameter unless after confirmation from technical support. 8. ANTENNA POSITION Read paragraph 2.4.1.1 FARMNAVIGATOR G7 – User Manual...
  • Page 29 Then press the “Set zero level” button. At this point, any errors due to an installation that is not perfectly flat will be canceled and a new zero reference in pitch and roll will be re-established. FARMNAVIGATOR G7 – User Manual...
  • Page 30 Figure 2.4.1.d - Zero calibration of the ground compensation 10. NTRIP CLIENT NTRIP Client refers to the technology that allows you to download precision corrections for RTK antennas from the internet. Figure 2.4.1.e - NTRIP Client access configuration FARMNAVIGATOR G7 – User Manual...
  • Page 31 - The RTK receiver connected to the “GPS Antenna” port; - An active internet connection: - For Turtle RTK > use WiFi via G7 Plus, G7 Iso and G7 Terminal; - For All in One RTK > the internet connection is already integrated in the receiver;...
  • Page 32 Figure 2.4.2 - Antenna position configuration page 2.4.3 Auto Steering (for G7 Plus and G7 Iso) Auto Steering menu allows you to access G7 settings when it is connected to Auto Steering system. 1. Select “SETUP” > “Auto Steering”; Figure 2.4.3 - Auto Steering configuration page...
  • Page 33 - SYNC JOB START/STOP: set this function “ON” and select Auto Steering button to start colouring the worked area. 2.4.4 ISOBUS From the ISOBUS menu you can access the ISOBUS features supported by G7: Virtual Terminal (VT) and Task Controller (TC). Figure 2.4.4 - ISOBUS functionality configuration page The status shows whether VT and TC are disabled, not connected, or active (ready to use).
  • Page 34 It is possible that there are more than one ISOBUS VT device in the network. At this point you can define a primary and a secondary device: - Main VT: the implement communicates with G7 for the main functions, the ID is 1; - Secondary VT: the implement communicates with G7 only for secondary functions (the display of the secondary VT depends on the equipment), the ID is 2.
  • Page 35 2.4.4.1.4 Transmit GPS Speed In this section you can enable the sending of the speed information read by the GPS antenna connected to the G7, to the ISOBUS equipment (if it is not equipped with other proprietary speed sensors). - OFF: sending disabled;...
  • Page 36 In this section you can view the counters of the connected ISOBUS equipment. 2.4.4.2.3 TASK CONTROLLER LOG In this section you can find the error messages, anomalies and alarms reported by the Task Controller. Figure 2.4.4.2.3 TC configuration page FARMNAVIGATOR G7 – User Manual...
  • Page 37 2.4.5 Navigation activation (only for G7 Terminal) On the G7 Terminal device it is possible to activate all navigation and database management functions. You can take advantage of a free trial period for navigation, after which it is necessary to activate the license (read par.
  • Page 38 3. START / STOP ON GENERIC PORT By activating this function, it is possible to connect to the implement / tractor to the G7 via the “GENERIC PORT”. You can use pin 2 and pin 3 of the port as a two-state logic signal input, that is open / closed according to this scheme: - Open circuit between pin2 and pin3 = open state = STOP state = coloring disabled;...
  • Page 39 It is possible to configure units of measurement for area, speed and distance: 1. Tap on “SETUP” > “Units”; 2. Select the unit that you need to modify; 3. Select the required unit of measurement; Figure 2.4.8 - Units of measurement FARMNAVIGATOR G7 – User Manual...
  • Page 40 2. Select the preference than has to be changed and tap the arrow to change it. 2.4.10 Remote control Remote control menu allows you to configure the supplied remote control. - Select “SETTINGS” > “Remote control”. FARMNAVIGATOR G7 – User Manual...
  • Page 41 Auto Steering system, placing a mark on the map (on obstacles, on specific points, etc.). To connect the remote control, make sure that it is within a range of a few metres from G7 and insert batteries into the slot. Then: 1.
  • Page 42 Table 2.4.10 - Remote control functions 2.4.11 Wireless connectivity (for G7 Plus, G7 Iso and G7 Terminal) G7 is provided with wireless connectivity and it can be connected to a WiFi hotspot. A dedicated menu allows the configuration of a WiFi network.
  • Page 43 2.4.12 Remote access (for G7 Plus, G7 Iso and G7 Terminal) Install the app Mirror Control to control G7 with your smartphone or tablet. This app allows you to use the display of your Android or Apple device as if it was G7 display.
  • Page 44 It is possible to connect G7 to a smartphone or tablet via WiFi network, only if G7 and the smartphone or tablet are connected to the same router. 1. Select “SETUP” > “Remote access” > Mirror Control > ON; 2.4.13 General Settings This page contains the general features of the device.
  • Page 45 ISOBUS equipment connected to the device. The Virtual Terminal screen is split into two parts. For the G7 Terminal device, the Virtual Terminal (VT) is displayed automatically when turned on. The device is already active and enabled to view and interact with the ISOBUS equipment.
  • Page 46 Figure 2.4.15.a – Virtual Terminal on G7 Terminal In all other G7 devices, however, the Virtual Terminal screen is divided into two parts: - A partial display is shown on the left of navigation, with the most important information: the line, the sections and the error on the line.
  • Page 47 Figure 2.4.15.b – Split VT screen 2.5 MyFarmnavigator Menu From the MyFarmnavigator menu you can access the interconnection and data exchange functions between the device and the MyFarmnavigator portal. Figure 2.5.a - MyFarmnavigator access page FARMNAVIGATOR G7 – User Manual...
  • Page 48 MyFarmnavigator portal. Viceversa, from the portal it is possible to send information to the device. When the connection with the portal is active, MyFarmnavigator icon is shown on the work page. Figure 2.5.c - MyFarmnavigator Icon during connection with the cloud FARMNAVIGATOR G7 – User Manual...
  • Page 49 Table 3.1.1 - Job name 3.1.2 Connected devices At the upper right corner of the screen, there are the icons that identify the type of devices connected to G7. Devices connected to G7 Connected and working remote control FARMNAVIGATOR G7 – User Manual...
  • Page 50 The compass is oriented according to tractor’s progress. The black tip of the compass indicates the North. The scale bar indicates the zoom level applied to the map. Table 3.1.4 - Zoom and compass FARMNAVIGATOR G7 – User Manual...
  • Page 51 Table 3.1.5 - Area, speed, distance The information displayed may vary if G7 is connected to third-party devices. Long tap area value icon (second box starting from the left) to open a selection menu and change the information displayed.
  • Page 52 Figure 3.2.2.a - A-B guidelines Once A-B lines are defined and created, the icon will indicate the type of guideline which is currently active during your job. A-B Parallel A+ Heading Table 3.2.2.b - Icon with A-B guideline type FARMNAVIGATOR G7 – User Manual...
  • Page 53 Delete A-B lines This feature allows you to delete the A-B guideline created in the field. The area already worked and coloured in green will not be deleted. Table 3.2.2.c - Functions available in the A-B menu FARMNAVIGATOR G7 – User Manual...
  • Page 54 It is possible to carry on the activities even during the measurement of field boundaries. It is important to take into account that G7 calculates the position of the field boarders according to the width of the chosen implement.
  • Page 55 Figure 3.2.3.c - Field name modification - Field boundaries are now saved and stored in memory NOTE: it is possible to locate the field on the same perimeters next year only by using an RTK instrumentation. FARMNAVIGATOR G7 – User Manual...
  • Page 56 3. Select “HEADLAND”, and set the width of the headland that must be a multiple of implement width. An area which corresponds to the headland will be displayed on the map. Figure 3.2.4.a - Headland, start a new row FARMNAVIGATOR G7 – User Manual...
  • Page 57 4. Select headland key, named “HEADLAND”, and set the width of the headland that must be a multiple of implement width; 5. An area which corresponds to the headland will be displayed on the map. Figure 3.2.4.b - Headland width configuration Figure 3.2.4.c - Headland, area FARMNAVIGATOR G7 – User Manual...
  • Page 58 Table 3.2.4 - Headland specific functions 3.2.5 Obstacles G7 allows users to save and view the position of a specific point on the map (e.g. an obstacle). - G7 Plus / G7 iso permits you to activate this option only with remote controller.
  • Page 59 Figure 3.2.5 - Obstacle on the map 3.2.6 Auto Steering system (For G7 Plus and G7 Iso) G7 is compatible with Auto Steering mode. Connect G7 to an external device which allows the steering wheel to be activated automatically and keep the tractor on the guideline.
  • Page 60 Tap this icon to set nudge step in centimetres, e.g. 5 cm. Move the line to the left Tap this icon to immediately move the line to the left, for example 5 cm (value set as nudge step). FARMNAVIGATOR G7 – User Manual...
  • Page 61 Tap this icon to close the menu relative to nudge page. The menu will be closed automatically after 5 seconds of inactivity. Table 3.2.7.b - Details of nudge functions ATTENTION: the maximum allowed nudge step is equal to half of the implement width. FARMNAVIGATOR G7 – User Manual...
  • Page 62 Navigation can also be activated from the setup menu, in free trial or lifetime license. NOTE: sharing GPS speed from G7 Terminal to ISOBUS equipment is possible if a GNSS receiver is connected to the GPS port. Or by activating the internal GPS of the device from the Satellites menu.
  • Page 63 10. The field takes the name defined during the new job creation page. Tap “EDIT” if you want to modify it; 11. Field boundaries will be saved and stored. 12. It is possible to work within the perimeter following the defined A-B lines. FARMNAVIGATOR G7 – User Manual...
  • Page 64 NOTE: this feature is available only with RTK instrumentation. G7 allows you to reload a previous job and work it again, recalling the A-B lines used during the previous activity. 1. Tap “DATABASE”, 2.
  • Page 65 1. Tap “START NEW JOB”; 2. Select the “FARMER”; 3. Select the “FIELD”. It is essential to select the name of the field used during the previous activity, so that to recall the A-B lines used in that field. FARMNAVIGATOR G7 – User Manual...
  • Page 66 NOTE: this function can be used only if the field is set. G7 allows you to save more than one A-B lines and recall them for further activities. To save more than one A-B lines within the field, proceed as follows: 1.
  • Page 67 1. Tap “A-B”; 2. Tap AB List icon. Figure 4.7.a - A-B line change during job AB list icon. Table 4.7 - A-B list icon 3. Select the A-B line type that you need to display; FARMNAVIGATOR G7 – User Manual...
  • Page 68 4. Delete A-B line, tap “YES”. The line will be deleted only from the display, but it is stored in memory; Figure 4.7.c - Example of a job with more than one A-B line saved FARMNAVIGATOR G7 – User Manual...
  • Page 69 4. Confirm to apply the movement. 4.10 Connect an external device to control sections G7 allows you to connect third-party external devices to make an automatic control of the section. This feature can be used with implements such as: - Weeding barrel...
  • Page 70 1. Connect the external device to the G7 bracket through 9-pin serial port marked as “CONTROLLER”; 2. Turn both G7 and the external device on. Any other settings concerning the external device are not part of this manual; 3. Select “DATABASE” > “IMPLEMENTS”;...
  • Page 71 Figure 4.10.b - External implement type selection page 5. Select which type of external control is connected to G7; 6. Scroll through the list and select the connected device; Figure 4.10.c - External device type FARMNAVIGATOR G7 – User Manual...
  • Page 72 7. Wait for a connection between G7 and the device; Figure 4.10.d - Connection between G7 and the external device 8. Set the total width divided into sections; Figure 4.10.e - Section configuration: nozzle per section FARMNAVIGATOR G7 – User Manual...
  • Page 73 9. It is possible to set the width of the spray boom either for the number of nozzles per single section or for the entire section width; Figure 4.10.f - Sections configuration: section width 10. Enter the number of boom sections; Figure 4.10.g. - Number of sections configuration FARMNAVIGATOR G7 – User Manual...
  • Page 74 Below is an example of 18 metres boom with 5 sections; G7 allows you to insert a time value to advance the opening and closing of the section so as to anticipate the command that must be send to the external device. This value, expressed in seconds, is equal to the time required by the device to order the opening of the sections and the actual release of product from the nozzles.
  • Page 75 For example, a value of 100% means that the section will be closed in case of total overlapping. A value of 50% means that the section will be closed when the boom overlaps the total section width by 50%. Figure 4.10.k - Spray boom overlap configuration FARMNAVIGATOR G7 – User Manual...
  • Page 76 On the job page, there are icons that show the sections status. Boom sections status Green colour indicates that the section is active and operating. Red colour indicates that the section is active but turned off. Table 4.10.a - Boom sections status FARMNAVIGATOR G7 – User Manual...
  • Page 77 The section is always inactive. In this case, the drop is red. Table 4.10.b - Section status: automatic and manual 4.11 How to activate the free VT and TC trial (G7 Iso, G7 Terminal, Iso Kit) 1. Position G7 on the ISOBUS bracket;...

  • Page 78: How To Activate The Lifetime Vt And Tc License

    4.12 How to connect an ISOBUS instrument In the ISOBUS menu it is possible to activate or deactivate the interaction between G7 and ISOBUS equipment. For the correct use of this function you need: 1. ISOBUS implement correctly wired and connected to the tractor;...

  • Page 79: Using "Planter" To Create Fields Planting Layout

    Figure 4.15 - Prescription map work screen 4.16 Using “Planter” to create fields planting layout G7 allows you to design and realize planting layout of vines, fruit plants, cultivation and installation of poles. In order to activate this feature, it is necessary to use a “Planter” implement.
  • Page 80 4. Create a new job and select A-B parallel lines (or A + Direction). Point A will represent the position of the first plant; 5. Define the distance between rows and plants and tap OK to confirm; Figure 4.15.b - Distance between plants and rows configuration page FARMNAVIGATOR G7 – User Manual...
  • Page 81 Figure 4.15.c - Field planting layout, point A 7. Proceed to point B and tap “B”. In this way the lines will be created and the plants position will be marked on the line. Figure 4.15.d - Plant distribution on A-B line FARMNAVIGATOR G7 – User Manual...
  • Page 82 It allows user to know how many plants have actually been worked from the beginning of the work. Table 4.15 - Information about “Planter” NOTE: third-party accessories will be available for the motions of the tractor, both for Auto Steering and for planter automation. FARMNAVIGATOR G7 – User Manual...

  • Page 83: Importing And Exporting Data

    5.1 Download a job and view it in the office G7 allows you to download a job in KMZ format and visualize it on your Personal Computer (PC). NOTE: in order to use this function, Google Earth™ software must be installed on your PC.

  • Page 84: Import The Field Boundaries In Kmz Format

    5.2 Import the field boundaries in KMZ format G7 allows you to import field boundaries in KMZ format. This feature is useful when you want to move field registration from one G7 to another or if the field boundaries are drawn in your office using Google Heart™...
  • Page 85 Figure 5.2.a - KMZ file import access menu Figure 5.2.b - File KMZ selection 3. Tap “Import” and wait for the fields to be imported; FARMNAVIGATOR G7 – User Manual...
  • Page 86 Figure 5.2.c - Importing fields from KMZ 4. In “FIELD” menu, there is a field for each imported KMZ file. Figure 5.2.d - Preview of a field imported from KMZ FARMNAVIGATOR G7 – User Manual...

  • Page 87: Importing A Map In Shp File Format

    Create a new folder called “Import” and put it in the USB stick. Inside the folder “Import”, copy the KMZ files you want to import. Connect the USB stick to your G7 using the cable supplied. - Tap “DATABASE” > “CAMPI” > “Import”;...
  • Page 88 - Select the file which you need to import; Figure 5.3.b - SHP file Import - Tap “Import” and wait for boundaries to be imported; Figure 5.3.c - Import SHP file – work in progress FARMNAVIGATOR G7 – User Manual...
  • Page 89 - All the field boundaries contained in the SHP file are now visible in “FIELD” menu; Figure 5.3.d - List of fields loaded from SHP file - It is now possible to see a preview of each field; Figure 5.3.e - Example of a field loaded from SHP file FARMNAVIGATOR G7 – User Manual...

  • Page 90: Create A Boundary In Shp File Format

    2. Save the file with “Save place as..”; 3. Use one of the online software available to convert a KMZ file into a SHP format (for example; MyGeodata Cloud); 4. Import the SHP file into G7 following the import procedure (Par 5.2). FARMNAVIGATOR G7 – User Manual...

  • Page 91: Import A File In Isoxml Format

    4. Copy the TASKDATA folder (you can rename it .e.g. TASKDATA_TEST) into the “Import” folder; 5. Connect the USB memory to the G7 ; 6. Select “DATABASE” > “TASKS ISOXML” > “Import” menu; 7. Select the TASKDATA folder (all the TASKDATA folders included in the Import folder will be displayed);...

  • Page 92: Exporting The Task Map To Isoxml

    1. Select “DATABASE” > “TASKS ISOXML” from the menu; 2. Select the folder to export. At this point the export option is available; 3. Make sure you have a USB stick connected to the G7; 4. Tap on “Export” and wait for the export to complete;...
  • Page 93 5. At this point the export is completed. The ISOXML will be available in the “Export” folder with the name “TASKDATA”. Figure 5.5 - Exporting ISOXML to USB stick FARMNAVIGATOR G7 – User Manual...

  • Page 94: Other Functions

    3. Tap on “Satellites info” and wait a valid positions status (3D or DGPS fix). See figure 6.1.1.c Figure 6.1.1.c - Detailed satellites info 6.1.2 NTRIP Configuration 1. In the Main Menu tap on “SETUP” and select “Satellites” 2. Tap on “NTRIP CLIENT (All in One RTK)”. See Figure 6.1.2.a FARMNAVIGATOR G7 – User Manual...

  • Page 95: Ntrip Configuration For Turtle Rtk Or Third-Party Receivers

    6.2 NTRIP Configuration for Turtle RTK or third-party receivers NOTE: NTRIP can be used correctly if the receiver is enabled to accept corrections through the same communication port connected to the G7. in case of third-party receivers, make sure of the correct configuration.

  • Page 96: Ntrip Configuration

    Figure 6.2.1.c - Detailed satellites info 6.2.2 NTRIP Configuration 1. Make sure the G7 is connected to a WiFi network (read to Chapter 2.4.10 for more details on how to connect the G7 to a WiFi network) 2. In the Main Menu tap on “SETUP” button and select “Satellites”...

  • Page 97: G7 Software Updates

    Now your RTK receiver is ready to use. 6.3 G7 software updates The updates for G7 are available every year. Follow the above procedure to update the software of your device. 6.3.1 Software Update via WiFi (G7 Plus, G7 Terminal and G7 Iso) G7 is provided with an automatic search for available updates when the device is connected to a WiFi network.

  • Page 98: Software Update Via Usb

    6.4.2 Connect a video camera It is possible to connect a video camera to G7 via the ‘USB cable/Video in’ (G7 Ezy, P/N: K2CYFS0600) or ‘USB cable / Video in /Ethernet’ (G7 Plus, G7 Iso, G7 Terminal, P/N: K2CYFS1000). The cable is provided with an analog RCA female video input.

  • Page 99: Display Mode For Video Camera

    6.4.3 Display mode for Video camera When the camera is properly connected to G7, the video camera icon will be automatically activated on the main page of your job. - Tap the camera icon displayed on the main page of your job to switch to video mode.

  • Page 100: Activate A Virtual Nmea Output On The "Generic" Port

    Figure 6.5.b - Switch to road navigation confirmation page 6.6 Activate a virtual NMEA output on the “Generic” port Some third-party devices used on the tractor in complementary mode to G7, require the use of GPS antenna for a correct functioning.

  • Page 101: Activate The Demo Mode

    G7 gives the possibility to generate and share a GPS code in NMEA format to be sent to a third-party device, without using a second GPS antenna. 1. Tap “SETUP” > “Satellites” 2. Tap “NMEA on Generic port” and select “ON”.
  • Page 102 Figure 6.7.b - Demo mode To disable Demo mode: 1. Tap “Stop”; Figure 6.7.c - Demo mode stop FARMNAVIGATOR G7 – User Manual...

  • Page 103: Gnss Receiver Firmware Update

    The new software updates also include updates for FARMNAVIGATOR receivers connected to the G7. It is possible that, following the software update, a message will appear at the first start-up that warns about the availability of a new firmware for the receiver. It is always recommended to update it.

  • Page 104: Contacts/Customer Support

    - Replacements, malfunctions - Repairs - Updates - MyFarmnavigator.com web portal Telephone: +39 0585 784044 Mail: support@avmap.it To get second-level assistance regarding: - Auto Steering - RTK systems - Settings Telephone: +39 334 6033178 Mail: support.farm@avmap.it FARMNAVIGATOR G7 – User Manual...
  • Page 105 8. Appendix A List of devices compatible with FARMNAVIGATOR G7: Antenna - FARMNAVIGATOR Turtle Pro - FARMNAVIGATOR Turtle Pro2 - FARMNAVIGATOR Turtle RTK - FARMNAVIGATOR All in One RTK - NMEA0183, GxRMC 5-10Hz, GxVTG 5-10Hz, GxGSA 1Hz, GxGSV 1Hz, GxGST 1 Hz;...
