resideo PROSIXSIREN-EU Installation And Setup Manual

Wireless siren/strobe

Advertisement

Quick Links

The PROSIXSIREN-EU is a wireless siren/strobe intended for
use with Control Panels that support SiX™ series devices.
NOTE: Installation shall be performed in accordance
with local regulations.
OPENING
Gently twist the top of the siren counterclockwise and the
mounting bracket clockwise to separate them.
ENROLLING
You must enroll the device in the Control panel. Set the Control
panel in the Programming Mode, and when prompted:
Note: For detailed programming instructions, refer to the
Installation Instructions for the Control Panel with which this
device is used.
1.
From AlarmNet 360:
• Select "SENSORS"
• Select "ADD SENSOR"
• Select "LEARN" and wait for the Control Panel to be in
learning mode.
2.
Insert four 1.5V AA Lithium batteries (included) to activate
the device and begin the enrollment process.
3.
The green LED flashes rapidly during enrollment (up to
about 20 seconds).
NOTE: Enrollment time varies depending on the signal
strength between the device and the panel.
The device sends data, and the panel enrolls the sensor.
4.
Enrollment is confirmed when the green LED is ON for 3
seconds.
Installation and Setup Guide
The device did not enroll in the system if:
To restart the enrollment process, ensure the system is in
programming mode and activate the tamper switch.
The device can also be manually enrolled.
Wireless Siren/Strobe
The white LED flashes, the system chirps, and the
device powers down.
The green LED flashes rapidly when the device is
removed from the mounting bracket (tamper switch is
triggered).
PROSIXSIREN-EU

Advertisement

loading
Need help?

Need help?

Do you have a question about the PROSIXSIREN-EU and is the answer not in the manual?

Questions and answers

Summary of Contents for resideo PROSIXSIREN-EU

  • Page 1 PROSIXSIREN-EU Wireless Siren/Strobe Installation and Setup Guide The PROSIXSIREN-EU is a wireless siren/strobe intended for use with Control Panels that support SiX™ series devices. NOTE: Installation shall be performed in accordance with local regulations. OPENING Gently twist the top of the siren counterclockwise and the mounting bracket clockwise to separate them.
  • Page 2 RESETTING DEFAULT SETTINGS If the device is enrolled in a Control Panel different than the intended panel, and you are unable to delete it from the unintended panel, reset the device to the factory default settings: Open the cover. Remove the batteries. Press and hold down the tamper switch while reinserting the batteries.
  • Page 3 LEDS AND SOUNDER Refer to the following System Status Indications table for operation of the four bi-colored LEDs and an 95dB sounder. System Status Indications R / W G / W Sounder Status Power Up – Enrollment Green Rapid Flashes for about 12 seconds, then ON for 3 seconds Power Up –...
  • Page 4 WARRANTY Sécurité Communications SAS (SECOM) Ademco 1 Ltd., 200 Berkshire Place 1198, Avenue du Docteur Maurice Donat Winnersh Triangle, Berkshire, RG41 5RD – UNITED KINGDOM 06250 Mougins - FRANCE PROSIXSIREN-EU © 2023 Resideo Technologies, Inc. www.resideo.com R800-26482D 10/21 Rev D...
