Pulsar AWO171EMT Mounting Instructions

1. Destination:
AWO171EMT metal enclosure is designed as components (supplying) in intrusion alarm system, access control systems,
security systems etc.
It is intended for installation:
 control panel and optionally additional modules
 access control controllers with optional modules
 radio or GSM transmitter with optional module PS

other dedicated devices, components etc.

assembly kit PKAZ196, designed for enclosure, includes: tamper of opening and detaching the enclosure,
earthing wires, screws ...

transformers which can be mounted in enclosure: AWT150
2. Specifications:
Table 1. Mechanical parameters.
External dimensions of enclosure
External dimensions of front panel
Recomended battery/batteries
Material
Destination
Net/gross weight
Notes
Warranty
Table 2. Operating parameters.
Protection grade EN60529
Operating temperature
Storage temperature
Relative humidity
Sinusoidal vibrations during operation
Impulse waves during operation
Vibrations and impulse waves during
transport
Table 3. Technical data of the transformers, which can be mounted in enclosure:
Code
Name
Supply voltage
Current consumption
Output power
Power supply output
Fuse in supply circuit 230 V
Overheat protection
Enclosure
MOUNTING ISTRUCTIONS
Code: AWO171EMT
Name: DSC BOX EMPTY
Metal casing for: SSWiN, KD,....
W=280, H=295, D=78+6 [+/-2 mm]
W1=285, H1=300 [+/-2 mm]
DC01 steel plate, thickness: 0,7 mm
corrosion protection,
Assembly kit PKAZ196, designed for enclosure, includes:
tamper of opening and detaching the enclosure, earthing wires, screws ...
Possibility of installing lock: MR008 / MR027
Posibility of mount transformer: AWT150
20%...90%, without condensation
According to PN-83/T-42106
AWT150
TRP 40/16/18
~ 230 V; 50 Hz
U1 = 12 V AC / 1,6 A
U2 = 14 V AC / 1,4 A
T 315 mA/250 V
Fuse o
130 C, non-returnable
PC/ABS class UL94-V0, IP30
v1.0
IM171EMT
Edition
7 Ah / 12 V (SLA)
Color: RAL 9003
Inside
1,65 / 1,71 [kg]
2 years
IP20
-10ºC ...+40ºC
-20ºC ...+60ºC
Unacceptable
0,20 A
40 V A
or
: 1 from 1.09.2023
