Digital display drill press

Advertisement

Quick Links

Digital Display Drill Press
Owner's Manual
80166202
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #5793505
READ & SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5793505 and is the answer not in the manual?

Questions and answers

Summary of Contents for Klutch 5793505

  • Page 1 Digital Display Drill Press Owner’s Manual 80166202 WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #5793505 READ & SAVE THESE INSTRUCTIONS...
  • Page 2 Thank you very much for choosing a Klutch product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 5 Specific Operation Warnings ....................... 7 Grounding .............................. 9 Extension Cords ..........................10 Main Parts of Product ......................... 11 Assembly Instructions ........................12 Operating Instructions ........................
  • Page 4: Intended Use

    Intended Use Great workspace illumination and accuracy thanks to the integrated LED light and laser. Easy-to-read LCD display shows rpm as well as spindle travel for exact drilling depth. Parallel guide and vertical clamp on base. Superior control from two gears giving speed adjustment from 170 to 2600rpm. Convenient quick release.
  • Page 5: Important Safety Information

    Important Safety Information ⚠WARNING • Read and understand all instructions. Failure to follow all instructions may result in serious injury or property damage. The warnings, cautions, and instructions in this manual cannot cover all possible conditions or • situations that could occur. Exercise common sense and caution when using this tool. Always be aware of the environment and ensure that the tool is used in a safe and responsible manner.
  • Page 6 ⚠WARNING WORK AREA SAFETY Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. • Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. Do not use the product where there is a risk of causing a fire or an explosion;...
  • Page 7: Specific Operation Warnings

    ⚠CAUTION PRODUCT USE AND CARE Do not force the product. Products are safer and do a better job when used in the manner for • which they are designed. Plan your work, and use the correct product for the job. Check for damaged parts before each use.
  • Page 8 Let the drill bit reach full speed before contacting the work piece. This will reduce the risk of • the work piece being thrown. If the work piece or drill bit becomes jammed, turn the drill off. Wait for all moving parts to stop •...
  • Page 9: Grounding

    Grounding ⚠WARNING • This machine must be grounded while in use to protect the operator from electrical shock. This unit is equipped with an electrical cord that has an equipment grounding conductor and a grounding plug. The plug MUST be plugged into a matching receptacle that is properly installed and grounded in accordance with ALL local codes and ordinances.
  • Page 10: Extension Cords

    Extension Cords ⚠WARNING USE A PROPER EXTENSION CORD. Make sure your extension cord is in good condition. When • using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage, resulting in loss of power and cause overheating.
  • Page 11: Main Parts Of Product

    Main Parts of Product Subassembly Display Switch Speed Control Chuck Guard Base Plate Handle Gear Selector Switch Column Quick Clamp Page 11 of 24...
  • Page 12: Assembly Instructions

    Assembly Instructions ASSEMBLING THE BASE PLATE AND COLUMN Insert the quick release clamp (2) over the column (3). Locate the column (3) into the base plate (1) so as the guide pins on the bottom end of the column (3) engage with the grooves, on the bottom of the base plate (1).
  • Page 13 FITTING THE DEPTH STOP Insert the depth stop (7) into the hole provided in the housing. (Fig. 5) CLAMPING LEVER FOR DEPTH STOP ASSEMBLY Assemble the clamping lever for depth stop (6) as shown in (Fig. 5) Fig.5 SECURING TO A WORK SURFACE Fasten the device to the work surface by bolting the base plate (1) to the work surface.
  • Page 14: Operating Instructions

    Operating Instructions OPERATION OF THE DISPLAY Switching the display on/off: Press the button one for five seconds until the display (9) switches on or off. The display can be switched between displaying the speed and the drilling depth by pressing (F) button. The zero point for the drilling depth can be set by pressing the (G) button.
  • Page 15 CLAMPING Hold the chuck in place and turn the securing ring (K) in the release direction. Turn the clamping sleeve (L) clockwise until the drill bit (M) can be inserted. Hold the holding ring (J) in place whilst doing Insert the drill bit (M), hold it in place and turn the clamping sleeve (L) counter clockwise by hand.
  • Page 16 CLAMPING LARGER WORK PIECES Use the parallel stop (16) for larger work pieces: Loosen the wing screws for the parallel stop (15) and insert the parallel stop (16) into the grooves of the base plate. Tighten the wing screws for the parallel stop (15).
  • Page 17 DISPLAYING THE DRILLING DEPTH Set the display (Fig 4.9) to the "Drilling depth" indication (button F). Set the tip of the drill bit down lightly on the work piece. Set the zero point by pressing the button (Fig. 6) Drill until the desired depth is shown on the display SWITCHING ON/OFF Make sure that the chuck guard (13) is...
  • Page 18: Maintenance

    Maintenance ⚠WARNING Pull out the mains plug before carrying out any adjustments, maintenance or repair work. Let the • device cool down before all maintenance and cleaning tasks. To transport the device hold it by the base plate • DO NOT oil the motor. •...
  • Page 19: Troubleshooting

    Troubleshooting ⚠WARNING • Pull out the mains plug Failure Possible Cause Corrective Action Check power outlet, mains connection Motor, cable or plug defective, building circuit cable, mains plug. Have repair carried out Breaker tripped. by electrical specialist. Check building circuit Device does not start.
  • Page 20: Parts Diagram

    Parts Diagram Parts List Reference Part Number Part Description Quantity Base plate Quick clamp Column Toothed rack for height adjustment Clamping lever for height adjustment Clamping lever for depth stop Depth stop Handle Display Off switch On switch Speed control Chuck guard Chuck Winged screws for guide / stop...
  • Page 21: Replacement Parts

    Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. • Not all product components are available for replacement. The illustrations provided are a • convenient reference to the location and position of parts in the assembly sequence. •...
  • Page 22: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Klutch product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
  • Page 23 Page 23 of 24...
  • Page 24 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 24 of 24...
