User Manual
Precision Impedance Analyzer
6632
S/W Ver
Firmware Ver
Date
1.38
21.1130
May-2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6632 and is the answer not in the manual?

Questions and answers

Related Manuals for Microtest 6632

Summary of Contents for Microtest 6632

  • Page 1 User Manual Precision Impedance Analyzer 6632 S/W Ver Firmware Ver Date 1.38 21.1130 May-2023...
  • Page 2 All brands and trademark are the properties of Microtest Co., Ltd. Microtest Co., Ltd. and its affiliates shall not be liable for the damage, losses or costs incurred due to the accidental use, misuse or abuse by the product buyer or the third party;...

  • Page 3: Table Of Contents

    CONTENT CHAPTER 1 SAFETY SPECIFICATION AFETY MARKS THE FOLLOWING SAFETY MARKS MAY APPEAR IN THIS ANUAL CHAPTER 2 PREFACE NTRODUCTION EATURE PECIFICATION CHAPTER 3 DESCRIPTION OF INSTALLATION & E ACKAGE QUIPMENT ESCRIPTION OF FUNCTION KEYS ON FRONT PANEL ESCRIPTION OF FUNCTION KEYS ON BACK PANEL ARDWARE NSTALLATION CHAPTER 4 BASIC MEASURING...
  • Page 4 SPOT LOAD CABLE LENGTH FIXTURE COMPENSATION FREQUENNCY LOAD FUNCTION 7.10 EFERENCE 7.11 CHAPTER 8 SYSTEM CONFIG LANGUAGE GPIB ADDRESS RS232 BAUD RATE RS232 EOI LAN PORT HANDLERINTERFACE KEY BEEP BIAS R ESOURCE CHAPTER 9 APPENDIX |Z| A CCURACY HART 9.2 M EASUREMENT ACCURACY CHAPTER 10 CONCEPT OF COMMAND...

  • Page 5: Chapter 1 Safety Specification

    Chapter 1 Safety Specification This instrument is designed according to EN61010-1 Specification. The main purpose of this Specification is to ensure that the instrument will be used in the laboratory or the factory safely; it is not suitable for outdoor applications, especially the moistened or dusty locations.
  • Page 6 1.4 Power Source The scope of power used by this instrument is 88~264Vac. To insert the power source, please check if the power to be connected is identical with the power-shifting sign indicated on the back panel. When changing the fuse, it is required to use specific type of fuse designed in same ampere to prevent the electrical wire from burning.
  • Page 7 1.10 Emergency treatment Upon the occurrence of electrocution, burning of the Test Piece or the burning of Main Unit, please disconnect the Power Switch and remove the power cord plug immediately to avoid causing a hazard. 1.11 General instructions ⚫ Do not place any combustible or heavy object on the instrument.

  • Page 8: Chapter 2 Preface

    Impedance Analyzer have become indispensable tools for the professional measuring technicians. In addition to providing full-range solutions for the testing equipment over the past years, Microtest also developed the new model of “6632 Precision Impedance Analyzer” that has contributed to more perfect precision solutions for the test.
  • Page 9 ⚫ It can be matched with various fixtures, such as: dielectric, liquid dielectric and permeability fixture ⚫ Can be equipped with DC bias current source test system (6243) ⚫ Up to 32 sets of multistep list programs can be stored in the permanent memory and up to 16 test steps can be arranged in each program ⚫...

  • Page 10: Specification

    2.3 Specification 6632 Precision Impedance Analyzer 儀 Meter Equivalent circuit Models Frequency range List mode Sweep mode mode ✓ ✓ ✓ analysis ✓ 6632-50S 10Hz~ 50MHz ✓ ✓ ✓ ✓ 6632-30S 10Hz~ 30MHz ✓ ✓ ✓ ✓ 6632-20S 10Hz~ 20MHz ✓...
  • Page 11 10mV~2Vrms (f ≦ 1 MHz) 10mV~1Vrms (f > 1MHz or f ≦1 MHz and Range RO=25Ω) Resolution Voltage Signal Accuracy Level 4-Terminal test fixture ± [(10 + 0.05 × f) % + 1 mV] Cable length > 0m ± [(15 + 0.1 × f)% + 1 mV] *f: frequency [MHz] 100μA ~ 20mArms (RO=100Ω) Range...
  • Page 12 Weight 3.95kg...

  • Page 13: Chapter 3 Description Of Installation

    Chapter 3 Description of Installation Thank you for using Microtest 6632 Precision Impedance Analyzer as your testing instrument. This Manual contains the detailed installation steps. To ensure personnel safety and to protect your equipment and data, please check if the following accessories are fully supplied before starting the installation.

  • Page 14: Description Of Function Keys On Front Panel

    3.2 Description of function keys on front panel Figure 3.2.1 Front panel Push Key and Port Function 1. Enter Enter key 2. Exit Exit key 3. Number key Input value 4. Menu For selecting Meter, Multi-step, Trace, Trim and System modes, etc.

  • Page 15: Description Of Function Keys On Back Panel

    3.3 Description of function keys on back panel *Rear view (millimeters) PORT FUNCTION Pass/Fail signal (see3.4.3 Hander Interface) 1. Handler For connecting to software port (see3.4.2 RS232 2. RS232 Connecting) Remote control port: 24-pin block (see3.4.1 GPIB 3. GPIB Connecting) For expanding Bias Input/Output port 4.
  • Page 16 Definition Definition Dataline1 Dataline5 Dataline2 Dataline6 Dataline3 Dataline7 Dataline4 Dataline8 Ground NRFD Ground NDAC Ground Ground Ground Ground Shield Signal ground ※ Restrictions of GPIB: ⚫ At most, 15 units of equipment can be connected at the same time. The total length of connecting cable will be 20m, and the connecting cable between each equipment is 2m long.
  • Page 17 3.4.2 RS232 Connecting The computer and the measuring instrument are connected through RS232, and the Test Piece will be tested or trimmed on the computer through RS232. ⚫ Definition of RS232Pin Definition Definition Non-connection Non-connection RXD (receiving data) Non-connection TXD (transmitting data) Non-connection Non-connection Non-connection...
  • Page 18 3.4.3 Handler Interface You may control the test function of your machine with an external signal through the Handler Interface and Handler I/O port in its back panel. Please set the Handler Interface ON in SYSTEM menu to enable remote control and set the dip switch to on (both switches are pull down).
  • Page 19 ⚫ Handler I/O timing diagram: NOTE: 1. PIN1(trigger) + PIN5(GND) Start testing after short circuit, the shorting time must be greater than 100uS. 2. The other output pins are photo coupler circuit, output signal is low level. The output is as a high resistance floating circuit when it without action.
  • Page 20 3.4.4 Fixture Connecting When connecting the fixture, it is required to discharge the power of Test Piece thoroughly. Turn the latches on both sides of the fixture to left until aligning with the small protruding point on the BNC port. Push the fixture down to the end and then rotate the latch rightward for fixing the fixture.
  • Page 21 3.4.5 LAN Port The instrument will be connected to the LAN (Local Area Network) ports. It can be selected as Auto or Manual. ( Manual requires entering of network settings and IP configuration.) MAC ADDRESS: Sets the MAC address. LAN STATUS: Displays the current network connection status.
  • Page 22 3.4.6 Power Cord Connecting Connect the power cord to the power jack of the instrument. Turn on the Power Switch, and the instrument is ready for use. Figure 3.4.6.1 power jack Figure 3.4.6.2 power key Before servicing the instrument, be sure to remove the power cord from the instrument.

  • Page 23: Chapter 4 Basic Measuring

    Chapter 4 Basic Measuring 4.1 Meter Mode Press “Menu” key and then select “Meter” Mode for accessing the Meter Mode page. 4.2 FREQ(Frequency) The frequency range is 10Hz~50MHz, and the resolution is set at 6 digits. Press Input Digit key and then<Enter> to confirm the value or use the function key ↑↑↑, ↑↑, ↑, ↓, ↓↓, ↓↓↓...

  • Page 24: Speed

    4.5 SPEED Select <SPEED> with <Direction> key. The <MAX.>, <FAST>, <MED.>, <SLOW> and <SLOW2> options are provided for the user to select according to their actual need. 4.6 BIAS In setting the dc bias voltage, voltage range is ±12VDC, choose↑↑,↑,↓,↓↓, Adjust it or click the number key (when input is above the instrument voltage range will be displayed outside range) 4.7 RANGE DC...

  • Page 25: Parameters

    4.10 Parameters Press <Menu> key to select <Meter> mode and then move the cursor to the left side for setting the parameters to be measured. Figure 4.10.1 Parameter Parameters Definition DC Resistance Equivalent Series Inductance Equivalent Parallel Inductance Equivalent Series Capacitance Equivalent Parallel Capacitance Quality Factor, (Q = 1/D) Dissipation Factor , Loss coefficient (tanδ)

  • Page 26: Measurer Mode Setup

    4.11 MEASURER MODE SETUP Press the Setup button on the instrument panel to enter the <MEASURE MODE SETUP> screen and perform measurement settings. Figure 4.11.1 Setup button Figure 4.11.2 Setup 4.11.1 TRIGGER DELAY Set the trigger delay time, and such function is normally used by the automated equipment.
  • Page 27 It is preset as <No>. To display Vm/Im, then select <Yes> and the page will display the Vm/Im value of AC and DC. It recommends setting as <No> because it will affect the measuring speed. Figure Vm/Im 4.11.5 BEEP WHEN It is preset as <OFF>.

  • Page 28: Trigger Mode

    4.12 TRIGGER MODE Under the Meter Mode page, select <TRIG> with<Direction>key. It is preset as <REPEAT>, and the instrument will execute the measuring continuously. If selecting <SINGLE> option, then it must be activated by pressing <Trigger> key. The measuring will be repeated with each pressing of <Trigger> key. Figure 4.12.1 Trig mode 4.13 LEVEL/RO/ALC Under the Meter Mode page, select <LEVEL>...

  • Page 29: Set Ε R

    4.13.2 ALC (Auto Level Control) Figure ALC It is preset as <ALC OFF>. If selecting <ALC ON>, it ensures that the voltage applied to both ends of Test Piece or the current flowing through the Test Piece will be consistent with the parameter set value.

  • Page 30: Dielectric Coefficient Measurement Method

    Figure Contacting and Non-contacting Dielectric Coefficient Measurement Method The <Contacting> or <Non-contacting> can be selected according to the tested material. If selecting the <Contact> measuring method, the user needs to set up the <DIAMETER> of polarity plate for the fixture and the <THICKNESS> of the tested material and <fixture correction coefficient>.

  • Page 31: Magnetic Permeability Coefficient Measurement Method

    4.16 Magnetic Permeability Coefficient Measurement Method For setting up the <HEIGHT>, <INNER DIAMETER> and <OUTER DIAMETER> of the tested material and <fixture correction coefficient>. Fixture correction coefficient: This is the compensation parameter used for fixture Fx-0000C8. Figure 4.16.1 Permeability setup 4.17 COMP (Comparison) Under the Meter Mode page, select <COMP>...
  • Page 32 4.17.2 COMP (Comparator) MODE & DISP (Display) Mode ⚫ Value Set the upper and lower limit values to identify the result. △ ⚫ Enter reference values and then set absolute values corresponding to the reference values as the upper limit and lower limit values.

  • Page 33: Bin Setup

    △% ⚫ Enter reference values and then set percentages corresponding to the reference values as the upper limit and lower limit values. The measurement values displayed are displayed in deviations (△ %) from the reference value. 4.17.3 UPPER The nominal value is used for executing the addition of Hi limit. 4.17.4 LOWER The nominal value is used for executing the subtraction of Lo Limit.
  • Page 34 4.18.2 BIN METHOD Equal:Set the upper and lower limit values for parameter, the Equal mode averages each the comparison values automatically. The Limit mode can select <ABS>, <△Abs> and <△%>. Sequential:The Sequential mode specifies comparison limits as the absolute measurement value. The Limit mode can select <ABS>, <△ Abs>...
  • Page 35 Random: Set the upper and lower limit values for each bin. The Limit mode can select <ABS>, <△Abs> and <△%>.
  • Page 36 6632 uses three methods for specifying parameter limits as follows:...

  • Page 37: File

    4.19 FILE The parameter can be saved in the flash Memory of the instrument. The Meter Mode allows the user to access 100 setup groups, and the Multi-step List Test Mode allows the user to access 50 setup groups (with each group containing 15 measuring steps).
  • Page 38 4.19.6 COPY>USB Insert the USB flash drive into the USB port on the front panel of the instrument, select<COPY>USB> to copy 6632 local file to USB flash drive. NOTE: 1. The METER mode setting file is saved to USB flash drive root IA6632-->METER.

  • Page 39: Chapter 5 List Test

    Chapter 5 LIST TEST Press <Menu> key and select <LIST SET> for executing the multi-step setup. The measurement frequency or measurement signal level differs for each panel allows you to simply evaluate the characteristics of the DUT. Such function can be used in the production line or the automation test and, at most, 15 testing steps can be set.

  • Page 40: List Mode Setup

    5.2 LIST MODE SETUP Under the <LIST SET> or <LIST RUN> page, selected <SETUP> function key and you can access the <LIST MODE SETUP> page for executing the measuring setup. 5.2.1 TRIGGER MODE It <REPEAT><SINGLE><AUTO> three different types of trigger can be set.
  • Page 41 Sets the trigger mode as automatic detection; the automatic trigger determination can be set from 0.01uA ~ 20000.00uA as the trigger determination point. When the value is greater than the determination point, it means that the DUT has been connected; when the value is less than the determination point, it means that the DUT has been disconnected.

  • Page 42: Corr.(List Correction)

    Whether to enable the result statistics function located at the bottom- right corner; <Clear> will reset all PASS and FAIL statistics and continuing keeping statistics all over again. 5.2.10 TERMINATED AT NG STEP When TERMINATED AT NG STEP is set as <ON>, the test will be terminated when any NG is detected during testing.

  • Page 43: Chapter 6 Sweep

    Chapter 6 SWEEP Press<Menu> key and select <Sweep> Mode for entering the Sweep Mode page. The Sweep Mode displays the component characteristics by visual method and the user can select voltage, current and frequency sweeping for using as the horizontal coordinates.
  • Page 44 6.1.1 SWEEP DELAY The delay time between each sweeping point can be set according to the user’s need. When set at Sweep Delay Mode, it will affect the entire measuring time. The trigger delay time is set as 0-5000mS. If NOTE: exceeding the high limit value, it will be adjusted back to 5000mS by the system automatically.
  • Page 45 6.1.3 KEEP PREVIOUS TRACE When <KEEP PREVIOUS TRACE> is selected <ON>, the graph drawn for the last sweeping remains and is overwritten with a brighter graph for the most recent measurement results. When<KEEP PREVIOUS TRACE> is selected <OFF>, the graph drawn for the last measurement is deleted and a graph for the most recent sweeping results is drawn.
  • Page 46 6.1.6 CURSOR The <CURSOR> function can easily find the maximum value, minimum value, and self-resonant frequency parallel/serial, then the searching result will be displayed at the lower-middle of LCD panel. <TrA MAX: traceA's maximum value>, <TrA MIN: traceA's minimum value>, <TrB MAX: traceB's maximum value>, <TrB MIN: traceB's minimum value>, <SRF fs: self-resonant frequency serial>, <SRF fp: self- resonant frequency parallel>...
  • Page 47 6.1.9 X-AXIS The <X-AXIS> can be set as <LINEAR> or <LOG>. The Linear Mode is divided into 250 equal portions with starting and ending values, and the Log Mode changes along with the set value. 6.1.10 START/STOP <START>Use the numeric keypad to set the starting value of the sweep. <STOP>Use the numeric keypad to set the ending value of the sweep.
  • Page 48 6.1.13 SPEED The sweep speed is available in “Fast”, “Medium” and “Slow” for option. 6.1.14 FUNC It can select default common parameter sets. 6.1.15 TRACE A/B PARA It sets the parameters to be analyzed...
  • Page 49 6.1.16 TRACE A/B Y-AXIS The Y-AXIS can be set as “Linear” or “Log.” 6.1.17 TRACE A/B REF When <Y-AXIS> is selected <LINEAR> type, it can change values of the reference line by using numeric keypad. 6.1.18 TRACE A/B POS Moving trace A/B up or down by using <move↑> and < move↓>.

  • Page 50: Equivalent Circuit Analysis (Option)

    6.2 Equivalent Circuit Analysis (option) The equivalent circuit analysis function estimates equivalent circuit constants based on measurement results. The 6632 can estimate 3-element model and 4- element model. By using the simulation function, you can display frequency characteristic ideal values using estimation results or user-configured constants.
  • Page 51 Use <mode-> and <mode+> function key to set the equivalent circuit type. Move the cursor to the equivalent circuit values; you can enter the desired value with numeric keypad or use <↑↑>, <↑>, <↓> and <↓↓> to do the fine adjustment, then you can simulate the equivalent circuit.

  • Page 52: Chapter 7 Correction

    Piezoelectric element Resonator Inductor with high Capacitor with high *Typical frequency characteristics graphs For models A, B, C, D, F and G, the horizontal axis is logarithmic, the vertical axis (Z) is logarithmic, and θ is linear. For model E, the horizontal axis is linear or logarithmic, the vertical axis (Z) is logarithmic and θ...

  • Page 53: Open Circuit Correction

    7.1 Open Circuit Correction In CORRECTION page, use <OFF><ON> function key to open the open circuit correction, and use <Open> function key to do the open circuit correction. Before starting the open circuit correction, do not load the Test Piece to avoid correction failure.

  • Page 54: Short Circuit Correction

    ⚫ Check that the test fixture or the test cables are properly connected. ⚫ Check that nothing is connected to the test fixture or the test cables. (Open circuit correction cannot be performed while any test piece is connected to the test fixture or the test cables.) ⚫...

  • Page 55: Hf Load

    ⚫ Check that the test fixture or the test cables are properly connected. ⚫ Check that the test fixture or the test cables are properly shorted together with the shorting bar. (Short circuit correction cannot be performed while any test piece is connected to the test fixture or the test cables.) ⚫...

  • Page 56: Fixture Compensation

    7.6 FIXTURE COMPENSATION Choose the fixture model. There are <F42001>,<FX-000C20>, <FX-000C19>, <FX- 000C12>,<FX-000C10>,<FX-000C8>, <FX-000C7>, and <FX-000C6>. 7.7 Spot. No. Set the fixed frequency point; the range is from 1~16. 7.8 FREQUENNCY Choose the frequency value...

  • Page 57: Load Function

    7.9 LOAD FUNCTION Click the <↑><↓> swap the primary and secondary parameters. (EX:<G-B>、<R-X>、<CP-RP>、<CP-D>、<CS-RS>、<CS-D>、<LP- RP>、<LP-Q>、<LS-RS>、<LS-Q>、<Y-Deg>、<Z-Deg>。 7.10 Reference Insert the known values with measurements as reference values 7.11 Load It is the value that is measured in the beginning to correct the result value.

  • Page 58: Chapter 8 System Config

    Chapter 8 SYSTEM CONFIG Press <Menu> key and then select <SYSTEM> mode for accessing the SYSTEM CONFIG page. The 6632 Precision Impedance Analyzer supports 3 language interfaces, <English>, <Traditional Chinese> and <Simplified Chinese>. The language can be preset with the function key.

  • Page 59: Gpib Address

    8.2 GPIB ADDRESS Under SYSTEM CONFIG page, select <GPIB ADDRESS> and set the GPIB Address within the range of 1~30 with the numeric keypad. 8.3 RS232 BAUD RATE Under SYSTEM CONFIG page, select <RS232 BAUD RATE> and use <14400>, <19200>, <38400>, <56000> and <115200> function key to set the RS232 Baud Rate.
  • Page 60 6220/6240: With single or multiple 6220/40, it is DC Bias Test system. Option items are 6210/ 6220/ 6223/ 6225/ 6240/ 6243 6632 Lcur、Lpot 、Hpot、Hcur with 62xx Lcur、Lpot 、Hpot、 Hcur。(option) Multiple DC Bias source included standard accessories black and red current board to connect each other. (Figure 8.8.1) 62xx other side Lcur、Lpot 、Hpot、Hcur connect F6210...
  • Page 61 Figure 8.8.1 Press “DETAIL” to enter multiple instrument status. (Figure 8.8.2) Figure 8.8.2 Bias source Press “Menu” key to enter meter mode and set the conditions and parameters such as current, frequency, etc. (About Rdc, you should turn on the bias and then you can measure the Rdc.) 10.
  • Page 62 Figure 8.8.3 TEMP 12. We recommend do the short correction in the temperature rise function. 13. Insert the fixture with correction chip and clamp it. Press “SHORT” to initiate the correction. 14. Remove the chip. Insert your DUT and set BIAS, time, alarm at, and stop at.
  • Page 63 Figure 8.8.5 ISAT page ※ All models for DC bias current Model Max unit Max Amp Resonance frequency 6210 100Hz to 3MHz 6220 120A 6223 120A 100Hz to 1MHz 6240 320A 100Hz to 10MHz 6243 320A 100Hz to 30MHz 6225...

  • Page 64: Chapter 9 Appendix

    Chapter 9 Appendix 9.1 |Z| Accuracy Chart...

  • Page 65: Measurement Accuracy

    9.2 Measurement accuracy Conditions of accuracy All specifications apply at 23 ± 5 °C, and 60 minutes after the instrument has been turned on. Impedance measurement accuracy at 4-terminal test fixture (Typical at > 10 MHz) ± Ae [%], Where Relative accuracy Ae = (Ab + Az + Av + Ad + Ac) × Kt [%] |Z|, |Y| accuracy θ...

  • Page 66: Chapter 10 Concept Of Command

    Temperature [°C] 8 - 18°C: 4 18 - 28°C: 1 + (T - 23) ² x 0.0139 28 - 38°C: 4 Measurement Time / Averaging Measurement Speed 1.Max: 2.5ms (>10kHz) 2.Fast: 50ms (>20Hz) 3.Medium: 100ms 4.Slow: 300ms 5.Slow2: 600ms Display Time 1.6 ~ 5.6ms (depend on the contents) Averaging Range 1 to 64...
  • Page 67 Colon (:) When a colon is placed between two command mnemonics, the colon moves the current path down on level on the command tree. When the colon is the first character of a command, it specifies that the following command mnemonics a root-level command.
  • Page 68 ◆ Data Format :MEASure:PARAmeter<NR1> LF 1. Command 2. Space 3. Parameter 4.Program Message Terminator Parameter: There must be a <space> between the last command and the first parameter in a subsystem command. For example: :MEASure:PARAmeter Z If you send more than one parameter with a single command, each parameter must be separated by a comma.
  • Page 69 ◆ Common Commands...
  • Page 70 <Command> :STATus:OPERation:CONDition? Function:It queries the status of Operation Status Register. Description: Return data 0~65535 (Format is in <NR1>) <Command> :STATus:OPERation:EVENt? Function:It queries the status of Operation Event Register. Description: Query syntax : STATus:OPERation:EVENt? Return data 0~65535 (Format is in <NR1>) <Command>...
  • Page 71 Function:It queries the installed in the system interface. Description: Query syntax *OPT? Return data If 6632 MAX test frequency is 1MHz , it returnsF01 If 6632 MAX test frequency is 3MHz, it returns F03 If 6632 MAX test frequency is 5MHz, it returns F05...
  • Page 72 Description: Query syntax *STB? Return data<NR1> <Command> *WAI Function:It makes 6632 waits until all previously sent commands are completed. The 6632 then continues executing the commands that follow the *WAI. <Command> *TST? Function:The response to this query is always 0.
  • Page 73 Set parameter MEASure(meter mode), SWEep(sweep mode), CORRection(correction page), LSET(list mode), LRUN(list run), LCORrection (list correction page), SYSTem(system page). Set syntax :DISPlay:PAGE MEASure Query syntax :DISPlay:PAGE? Return data MEAS (Format is in <disc>)
  • Page 74 ◆ MEASure Subsystem <Command> :MEASure:PARAmeter {OFF|RDC|LS|LP|CS|CP|Q|D|RS|RP|Z|DEG|RAD|R|X|Y|G|B|E|U} :MEASure:PARAmeter? Function:It sets or queries the measurement parameter (max.4 items) at present. Description: Set parameter OFF, RDC(DC Resistance), Ls(Series Inductance), Lp(Parallel Inductance), Cs (Series Capacitance), Cp (Parallel Capacitance), Q (Quality Factor), (Dissipation Factor), (Series Resistance) Rp(Parallel Resistance),...
  • Page 75 Function:It sets or queries the BEEP WHEN. Description: Set parameter OFF, PASS|OK, FAIL|NG Set syntax :MEASure:BEEPer PASS :MEASure:BEEPer NG :MEASure:BEEPer OFF Query syntax :MEASure:BEEPer? Return dataPASS| FAIL| OFF <Command> :MEASure:VOLTage:AC <voltage NR3/disc> :MEASure:VOLTage:AC? Function:It sets or queries the AC measurement voltage (LEVEL). Description: Set parameterWhen RO(output impedance) is setting 100 Ω...
  • Page 76 :MEASure:CURRent:AC 20m :MEASure:CURRent:AC 1E-2 :MEASure:CURRent:AC MAXimum :MEASure:CURRent:AC MINimum Query syntax :MEASure:CURRent:AC? Return data2.000000E-04 (Format is in <NR3>) When the Level setup is voltage mode, the data returns 9.9E37. <Command> :MEASure:ALC {OFF|ON|0|1} :MEASure:ALC? Function:It sets or queries the ALC. Description: Set parameter ON|1, OFF|0 Set syntax : MEASure:ALC ON Query syntax:MEASure:ALC? Return dataWhen the setup is OFF, it returns 0.
  • Page 77 :MEASure:TRIGger:DELay? Function:It sets or queries the TRIGGER DELAY. Description: Set parameterThe value of delay timeis {0.000~5.000| MAXimum|MINimum}. Set syntax :MEASure:TRIGger:DELay 0.5 :MEASure:TRIGger:DELay 100ms :MEASure:TRIGger:DELay 200ms :MEASure:TRIGger:DELay 5E-3 :MEASure:TRIGger:DELay MAXimum :MEASure:TRIGger:DELay MINimum Query syntax :MEASure:TRIGger:DELay? Return data 0.000 (Format is in <NR2>) <Command>...
  • Page 78 <Command> :MEASure:RANGe:DC {1|2|3|4|AUTO|HOLD} :MEASure:RANGe:DC? Function:It sets or queries the DC RANGE. Description: Set parameter{1|2|3|4|AUTO|HOLD} Set syntax :MEASure:RANGe:DC 2 :MEASure:RANGe:DC AUTO Query syntax :MEASure:RANGe:DC Return data 2 (Format is in <NR1>) <Command> :MEASure:RANGe:AC {1|2|3|4|AUTO|HOLD} Function:It sets or queries the AC RANGE. Description: Set parameter{1|2|3|4|AUTO|HOLD} Set syntax :MEASure:RANGe:AC 3...
  • Page 79 Query syntax : MEASure:COMParator:STATe? Return dataWhen the setup is OFF, it returns 0. When the setup is ON, it returns 1. <Command> :MEASure:COMParator:MODE <ABSolute|DEViation|PERCent|0|1|2> :MEASure:COMParator:MODE? Function:It sets or queries the COMP MODE. Description: Set parameter ABSolute,0|DEViation,1|PERCent,2 Set syntax :MEASure:COMParator:MODE PERCent Query syntax :MEASure:COMParator:MODE? Return dataPERC (Format is in <disc>) <Command>...
  • Page 80 Set syntax :MEASure:COMParator:MODE DEViation Query syntax :MEASure:COMParator:MODE? Return dataDEV(Format is in <disc>) <Command> :MEASure:BIN:PARAmeter {OFF|RDC|LS|LP|CS|CP|Q|D|RS|RP|Z|DEG|RAD|R|X|Y|G|B|E|U} :MEASure:BIN:PARAmeter? Function:It sets or queries the BIN Parameter. Description: Set syntax :MEASure:BIN:PARAmeter Z(only allow the parameter which is being used under the meter mode.) Query syntax :MEASure:PARAmeter? Return dataZ(Format is in <disc>) <Command>...
  • Page 81 Return data +1.000000E-03, +1.000000E-01, +1.000000E+03, +1.000000E+06 (Format is in <NR3>) <Command> :MEASure:FILE:LOAD <filename> Function:It opens the meter mode's file. Description: Set syntax :MEASure:FILE:LOAD MICROTEST.( load the file “MICROTEST”) <Command> :MEASure:FILE:LOAD? Function: It queries the meter mode's filename which is being using. Description: Set syntax: MEASure:FILE:LOAD? Return dataMICROTEST <Command>...
  • Page 82 Return data -1.200000E+01 <Command> :MEASure:BIAS:Current<NR3> :MEASure:BIAS:Current? Function: Set or query the DC bias current range. Description: Set syntax :MEASure:BIAS:Current 20 Query syntax :MEASure:BIAS:Current? Return data +2.000000E+01 <Command> :MEASure:BIAS:STATe<ON|OFF|0|1> :MEASure:BIAS:STATe? Function: Set or query. Description: Set syntax :MEASure:BIAS:STATe ON Query syntax :MEASure:BIAS:STATe? Return data 1(ON), 0(OFF) <Command>...
  • Page 83 ◆ FETch Subsystem <Command> :FETCh? Function:It fetches the measurement data currently test mode There are two options for trigger and query: 1. Give command *TRG or :TRIG? and get measuring result (recommend) 2. Give command :TRIG for trigger and give :FETCH? to get measuring result To be sure currently step is under MEAS mode, or give command :DISP:PAGE MEAS to enter MEAS mode.
  • Page 84 Return data 0,"No error" Common error code 0 No error -100 Command error -102 Syntax error -108 Parameter not allowed -109 Missing parameter -113 Undefined header -121 Invalid character in number -128 Numeric data not allowed -131 Invalid suffix -211 Trigger ignored -220 Parameter error -222 Data out of range -224 Illegal parameter...
  • Page 85 Return data When correction fail, it returns 0. When correction passes, it returns 1. <Command> :CORRection:SHORt :CORRection:SHORt? Function:It sets or queries to do short correction. Description: Set syntax : CORRection:SHORt Query syntax :CORRection:SHORt? Return data When correction fail, it returns 0. When correction passes, it returns 1.
  • Page 86 where 0= The result of high frequency load correction is failed 1= The result of high frequency load correction is passed <Command> :CORRection:HF:STATe {ON|OFF|0|1} :CORRection:HF:STATe? Function: It sets or queries the state of high frequency load correction. Description: Set parameter {ON|OFF|0|1} Set syntax: CORRection:HF:STATe ON Query syntax: CORRection:HF:STATe? Return data 0|1...
  • Page 87 Set syntax: CORRection:LOAD:SPOT 1 Query syntax: :CORRection:LOAD:SPOT? Return data 1 <Command> :CORRection:LOAD:FREQuency <frequency in NR3> :CORRection:LOAD:FREQuency? Function: It sets or queries the load frequency for the current load correction spot. Description: Set parameter<frequency> (format is in NR3), where 0= FREQUENCY is OFF. 10HZ~30MHZ = FREQUENCY is ON.
  • Page 88 ◆ LIST Subsystem <Command> :LIST:STEP{1|2|3|4|…|14|15} :LIST:STEP? Function: It sets or queries the step of list mode. Description: Set parameter step number1~15 Set syntax :LIST:STEP 1 Query syntax :LIST:STEP? Return data1(Format is in <NR1>) <Command> :LIST:PARAmeter {OFF|RDC|LS|LP|CS|CP|Q|D|RS|RP|Z|DEG|RAD|R|X|Y|G|B} :LIST:PARAmeter? Function: It sets or queries the measurement parameter of list mode. Description: Set parameterThere is no E(Relative Permittivity) and U(Relative permeability) in the list mode.
  • Page 89 :LIST:VOLTage 10E-3 :LIST:VOLTage MAXimum :LIST:VOLTage MINimum Query syntax :LIST:VOLTage? Return data1.000000E-02 (Format is in <NR3>) When the Level setup is current mode, the data returns 9.9E37. <Command> :LIST:CURRent <current NR3/disc > :LIST:CURRent? Function: It sets or queries the measurement current of list mode. Description: Set parameter When RO(output impedance) is setting 100Ω, the setup range of AC current is {0.0001~0.02|MAXimum|MINimum}.
  • Page 90 <Command> :LIST:COMParator:MODE <ABSolute|DEViation|PERCent|0|1|2> :LIST:COMParator:MODE? Function: It sets or queries the COMP MODE of list mode. Description: Set parameter ABSolute,0|DEViation,1|PERCent,2 Set syntax :MEASure:COMParator:MODE PERCent Query syntax :LIST:COMParator:MODE? Return data PERC (Format is in <disc>) When the setup is 0, it returns ABS , When the setup is 1, it returns DEV , When the setup is 2, it returns PERC.
  • Page 91 Set syntax :LIST:BIN:PARAmeter Z(only allow the parameter which is being used under the list mode.) Query syntax :LIST:PARAmeter? Return data Z (Format is in <disc>) <Command> :LIST:BIN:NUMBer {2|3|4|5|6|7|8|9|MAXium|MINimum} :LIST:BIN:NUMBer? Function: It sets or queries the BIN NUMBER of list mode. Description: Set parameter The value of bin number is {2~9|MAXimum|MINimum}.
  • Page 92 Query syntax :LIST:BIN:BIN:LIMit? Return data +1.000000E-03, +1.000000E-01, +1.000000E+03, +1.000000E+06 (Format is in <NR3>) <Command> :LIST:TRIGger:MODE {REPeat|SINGle|AUTO} :LIST:TRIGger:MODE? Function: It sets or queries the TRIGGER MODE of list mode. Description: Set parameter REPeat、SINGle、AUTO Set syntax :LIST:TRIGger:MODE AUTO Query syntax :LIST:TRIGger:MODE? Return data AUTO (Format is in <disc>) <Command>...
  • Page 93 Return data OFF | STEP |ALL (Format is in <disc>) <Command> :LIST:FILE:LOAD <filename> Function:It opens the list mode's file. Description: Set syntax:MEASure:FILE:LOAD MICROTEST.(open the MICROTEST list mode file) <Command> :LIST:FILE:LOAD? Function:It queries the list mode's filename which is being using.
  • Page 94 Set syntax :LIST:FILE:NEW ABC <Command> :LIST:FILE:SAVE <file name> Function: Save as a new file named <file name>, where the setting will be saved. Description: Set syntax :List :FILE:SAVE ABC <Command> :LIST:FILE:DELEte <file name> Function: Delete the file which named <file name> . Description: Set syntax : LIST:FILE: DELEte ABC <Command>...
  • Page 95 :LIST:STATistic:COUNt? Function: It sets or queries the statistical data in the list mode. Description: Set parameter <pass count, fail count> (format is in NR1) The value of pass count and fail count 0~999999999 Set syntax: :LIST:STATistic:COUNt 0,1 Query syntax :LIST:STATistic:COUNt? Return data n1,n2 where n1= pass count (format is in NR1) n2= fail count (format is in NR1)
  • Page 96 The start value of current AC RO 100Ω is { 0.0001~0.02 |MAXimum|MINimum}. The start value of current AC RO 25Ω is { 0.0004~0.04|MAXimum|MINimum}. The start value of BIAS V RO 100Ω is { -12~+12|MAXimum|MINimum}. The start value of BIAS V RO 25Ω is { -12~+12|MAXimum|MINimum}. Setsyntax :SWEep:STARt 10 :SWEep:STARt 10m...
  • Page 97 Function:It sets or queries the LEVEL to voltage mode, when the TYPE setup is FREQ. Description: Set parameter The value of voltage AC RO 100Ω is {0.01~2|MAXimum|MINimum}. The value of voltage AC RO 25Ω is {0.01~1|MAXimum|MINimum}. Set syntax :SWEep:VOLTage 1 :SWEep:VOLTage 1M :SWEep:VOLTage 1MV :SWEep:VOLTage 1E-3...
  • Page 98 Query syntax :SWEep:SPEEd? Return data FAST |MED | SLOW (Format is in <disc>) <Command> :SWEep:TRACe {A|B} :SWEep:TRACe? Function:It sets or queries which trace is on using. Description: Set syntax :SWEep:TRACe A Querysyntax :SWEep:TRACe? Return data A | B (Format is in <disc>) <Command>...
  • Page 99 14. Light green 15. Light cyan 16. Light red 17. Pale magenta 18. Light yellow <Command> :SWEep:TRACA:COLOR <0|1|2|3|4|5|6> :SWEep:TRACA:COLOR? Function: Change trace a color. Description: Set syntax : :SWEep:TRACA:COLOR 1 Query syntax :SWEep:TRACA:COLOR? Return data 1 19. Light blue 20. Light green 21.
  • Page 100 6. Light yellow 7. Deep blue 8. Deep green 9. Deep cyan-blue 10. Deep red 11. Deep magenta 12. Deep yellow <Command> :SWEep:ANALysis:TRACB:COLor <0|1|2|3|4|5|6|7|8|9|10|11|12> Function: Change trace B analysis line color. Description: Set syntax : :SWEep:ANALysis:TRACB:COLOR 8 Query syntax :SWEep:ANALysis:TRACB:COLOR ? Return data 8 0.
  • Page 101 Query syntax :SWEep:ANALysis:MODel? Return data B(Format is in <disc>) <Command> :SWEep:DELay <delay timeNR3/disc> :SWEep:DELay? Function: It sets or queries the SWEEP DELAY. Description: Set parameter The value of delay time is {0.000~5.000|MAXimum|MINimum}. Set syntax :SWEep:DELay 0.5 :SWEep:DELay 500M :SWEep:DELay 500MS :SWEep:DELay 5E-3 :SWEep:DELay MAXimum :SWEep:DELay MINimum...
  • Page 102 Function: It sets or queries the Y-AXIS of TRACE A. Description: Set parameter LOGarithm | LINear Set syntax :SWEep:TRACA:YAXis LOGarithm Query syntax :SWEep:TRACA:YAXis? Return data LOG | LIN (Format is in <disc>) <Command> :SWEep:TRACA:REFerence <value NR3> :SWEep:TRACA:REFerence? Function: It sets or queries the REF of TRACE A. Description: Set parameterIt can set the value, when Y-AXIS setup is linear mode.
  • Page 103 Return data +9.9E37 ( when Y-axis setup is not LOG mode ) <Command> :SWEep:TRACA:MAXimum? Function: It queries the maximum of TRACE A and corresponding frequency | voltage | current. Description: Query syntax :SWEep:TRACA:MAXimum? Return data +2.230924E+06,+3.221517E-03 (Format is in <NR3>).The first data is the corresponding frequency | voltage | current.
  • Page 104 Function: It sets or queries the REF of TRACE B. Description: Set parameterIt can set the value, when Y-AXIS setup is linear mode. Set syntax :SWEep:TRACB:REFerence 25k Query syntax :SWEep:TRACB:REFerence? Return data 2.500000E+03 (Format is in <NR3>) <Command> :SWEep:TRACB:POSition {-10 ~ 16|MAXimum|MINimum} :SWEep:TRACB:POSition? Function: It sets or queries the POS of TRACE B.
  • Page 105 Function: It queries the minimum of TRACE B and corresponding frequency | voltage | current. Description: Query syntax :SWEep:TRACB:MINimum? Return data +2.310130E+06,-3.446227E-03 (Format is in <NR3>).The first data is the corresponding frequency | voltage | current. The second data is the minimum. <Command>...
  • Page 106 Return data +2.310130E+06 (Format is in <NR3>). <Command> :SWEep:SRF:PARallel? Function: It queries the SRF fp (self-resonant frequency parallel). Description: Query syntax :SWEep:SRF:PARallel? Return data +2.310130E+06 (Format is in <NR3>). <Command> :SWEep:BIAS:Voltage <value NR3> :SWEep:BIAS:Voltage? Function: It sets or queries the BIAS Voltage of sweep mode. Description: Set parameter: The value of BIAS Voltage on sweep mode -12.000~12.000 Set syntax: :SWEep:BIAS:Voltage 6...
  • Page 107 bin number – Categorization result, and such value will not be displayed when closing the bin function. -1 – bin out, not in the categorization number 1 – 9 – bin number, the categorization result is 1-9. para compare status 1-4 Measuring comparison result: If any parameter comparison function is opened, then the comparison result will be displayed for all of the opened parameters.
  • Page 108 ◆ Basic measurement principle To measure capacitance, inductance and resistance user can select series or parallel mode. C (Capacitance) : Series mode: Parallel mode: Parallel mode Equations: Series mode Equations: D = dissipation factor D = dissipation factor L (Inductance) : Series mode: Parallel mode: Series mode Equations:...
  • Page 109 ◆ Resistance (R) and Conductance (G) The resistance is a measure of the difficulty to pass an electric current through that conductor. The SI unit of resistance is the “ohm” (Ω). The inverse quantity is electrical conductance, and this is the ease with which an electric current passes through a circuit.
  • Page 110 ◆ Capacitance (C) Capacitance (denoted by the letter C) is the ability of a body to store an electrical charge at a given potential difference between its plates. The SI unit of capacitance is the farad (symbol: F). Measure Type:Series mode→Cs / Parallel mode→Cp Relevant Equations: ...
  • Page 111 ◆ Inductance (L) Inductance is the property of an electrical conductor by which a change in current through it induces an electromotive force (EMF) in both the conductor itself and in any nearby conductors by mutual inductance. In the SI system, the measurement unit for inductance is the Henry (with the unit symbol H).
  • Page 112 ◆ Reactance (X) and Susceptance (B) In AC circuit analysis, reactance is represented by the capital letter “X” which is the imaginary a part of complex impedance. Reactance is the opposition of a circuit element to a change in the current or voltage, due to that element's inductance or capacitance which is similar to the opposition of resistance to current in a DC circuit.
  • Page 113 ◆ Impedance (Z) and Admittance (Y) The impedance covers oppositions in AC circuits including resistance, inductance, and capacitance and is measured in units of Ohm (Ω). In electrical engineering, admittance covers both conductance and susceptance and is the reciprocal of impedance. It is measured in units of Siemens (S).
  • Page 114 ◆ Quality factor (Q) and Dissipation factor (D) The quality factor measures energies consumed by relative frequency. In general, the better a circuit's quality factor the better its selectivity. The dissipation factor is the reciprocal of quality factor. It is the signal angle loss by a capacitor (or inductor) and acting frequency at a fixed temperature.
  • Page 115 ⚫ Dissipation factor （D） Relevant Equations:  ◆ Phase angle (θ) This is the shift angle when measuring impedance (Z), admittance (Y), quality factor (Q) and dissipation factor (D). Relevant equations:  −   ...
  • Page 116 ◆ Overall Impedance Measurement Theory The simplified model of the 6630 impedance measurement, Vs is the test signal voltage and RO is source resistance. If the current across the DUT is I when a test signal voltage V is applied, the DUT's impedance, Z, is expressed by Z = Impedance, Z, contains real and imaginary parts.
  • Page 117 Impedance, Z, can also be expressed as admittance, Y. Admittance is expressed in terms of impedance, Z, by Y = − j R+jX = | Y | ∠(−θ) | Z | ∠θ For parallel connected circuits, it is better to use admittance, Y. G : Conductance B : Susceptance |Y|: Admittance...
  • Page 118 The 6630 measures a DUT's impedance, Z, which is a vector value, and gives the result using the following equivalent circuits. Lp : Parallel Inductance Cp : Parallel Capacitance Ls : Series Inductance Cs : Series Capacitance Q : Quality factor D : Dissipation factor...
  • Page 119 ◆ Characteristics Example As can be seen in the following figure, a component can have different effective parameter values dependent upon its operating condition. The measured values most useful in actual applications are obtained from precise measurement under the actual operating conditions.
  • Page 120 Measurement Characteristics Example Functions Cp-G Large R Y-∠θ Ls-Rs Small R |Z|-∠θ ◆ High and low impedance criteria The following criteria can be used to roughly discriminate between low, middle, and high impedances by following figure. The medium Z range may be covered with an extension of either the low Z or high Z range.
